Protocol: TCP/IP, DHCP, DNS, NTP, UPnP - Incoming Bandwith: 80 Mbps - Outgoing Bandwidth: 60 Mbps - Decoding Format: H.265+/H.265/ H.264+/H.264 - x1 SATA Interface - Capacity: Up to 10TB - Network Interface: x1 RJ-45 10/100 Mbps Self-Adaptive Ethernet Interface - USB Interface: 2× USB 2.0 - Video Input: 8-Channel 5MP - Video Output: Up to 1920×1080p/60Hz 5MP
| Performance | |
| Video input channels The number of channels for video input that the device features. | 8 channels |
| Number of simultaneously playbacked channels | 4 channels |
| Video recording modes | 1080p |
| Maximum resolution The maximum number of pixels that can be displayed in the image. It is usually quoted as width × height,: for example, "1024 × 768" means the width is 1024 pixels and the height is 768 pixels. | 1920 x 1080 pixels |
| Supported resolutions | 1920 x 1080, 1280 x 720, 1440 x 900, 1280 x 1024 |
| Input bandwidth | 80 Mbit/s |
| Output bandwidth | 60 Mbit/s |
| Wireless LAN features | |
| Wi-Fi Popular technology that allows an electronic device to exchange data or connect to the internet wirelessly using radio waves. |
 |
| Storage | |
| Number of HDDs supported The total number of hard drives that can be used in/with this product. | 1 |
| HDD interface The way that a hard disk drive (HDD) is connected to the rest of the computer through a 'bus' such as ATA or SCSI. | Serial ATA |
| Ports & interfaces | |
| Ethernet LAN (RJ-45) ports Number of Ethernet LAN (RJ-45) ports (connecting interfaces) in the device. Ethernet LAN (RJ-45) ports allow a computer to connect to the ethernet. | 1 |
| HDMI ports quantity The number of sockets (ports) for HDMI connections. HDMI (High-Definition Multimedia Interface) is a compact audio/video interface for transferring uncompressed video data and compressed/uncompressed digital audio data from a HDMI-compliant device ("the source device") to a compatible computer monitor, video projector, digital television, or digital audio device. HDMI is a digital replacement for existing analog video standards. | 1 |
| USB 2.0 ports quantity Number of USB 2.0 ports (connecting interfaces) in the device. USB 2.0 was released in April 2000 (now called "Hi-Speed"), adding higher maximum signaling rate of 480 Mbit/s (effective throughput up to 35 MB/s or 280 Mbit/s), USB 2.0 ports are usually black. | 2 |
| Audio RCA inputs | 1 |
| Audio RCA outputs | 1 |
| DC-in jack The socket/plug where the DC electricity supply connects to the device. |
 |
| Features | |
| Rack mounting The type of mounting that can position devices in a shelving system (rack). |
|
| Rack capacity The spase that device fill in rack. | 1U |
| Product colour The colour e.g. red, blue, green, black, white. | Black |
| Power | |
| Output voltage | 12 V |
| Power supply The way in which the product is powered e.g. rechargeable battery, mains electricity connected via a plug and cable. | 18 W |
| Operational conditions | |
| Operating temperature (T-T) The minimum and maximum temperatures at which the product can be safely operated. | -10 - 55 °C |
| Weight & dimensions | |
| Width The measurement or extent of something from side to side. | 246.2 mm |
| Depth The distance from the front to the back of something. | 148.2 mm |
| Height The measurement of the product from head to foot or from base to top. | 42.6 mm |
| Weight Weight of the product without packaging (net weight). If possible, the net weight is given including standard accessories and supplies. Please note that sometimes the manufacturer leaves out the weight of accessories and/or supplies. | 578.5 g |
| SKU | 616196 |
| MPN | NVR1008H |
| Brand | TP-Link |
| Product Condition | Brand New/Unused |
| Warranty Period | 2 Years Warranty |
| Warranty Contact | https://www.tp-link.com/ |
