ThinkSystem 3.5" 5300 1.92TB Entry SATA 6Gb Hot Swap SSD
Item No:
540464
MPN:
4XB7A17084
$5,706.87
Payment options
Shipping Information
- Unavailable for shipping
- This product is not currently available for purchase
Store Availability
- Unavailable at Bankstown Store
- Unavailable at Castle Hill Store
- Unavailable at Northmead Store
Lenovo ThinkSystem 5300, 1920 GB, 3.5", 540 MB/s, 6 Gbit/s
The 5300 Entry SATA solid-state drives (SSDs) are new SSDs for ThinkSystem servers. The drives use Micron 96-layer 3D NAND flash memory technology with a SATA 6Gbps interface and provide an affordable solution for read-intensive applications such as boot, web servers, lower data rate operational databases and analytics.
| Features | |
| SSD form factor The size of the solid-state drive, given in inches | 3.5" |
| SSD capacity The Solid State Drive's data storage capacity. | 1920 GB |
| Interface Interface ports to connect pieces of equipment. USB (Universal Serial Bus) has become the most popular wired interface to connect peripherals. USB 2.0 supports speeds up to 480 Mbit/s (USB 1: 12 Mbit/s). The interface FireWire is also known as the IEEE 1394 standard. Enhanced IDE (EIDE)is sometimes referred to as Fast ATA, Fast IDE or ATA-2. | Serial ATA III |
| Memory type Type of memory in the device e.g. DDR3, SRAM (Static RAM). | 3D TLC NAND |
| Component for What this product is used as a part of (component for). | Server/workstation |
| Data transfer rate Rate at which data can be transferred. Usually expressed in units per second. May vary with network configurations. | 6 Gbit/s |
| Read speed The speed at which a device can read data. | 540 MB/s |
| Write speed The speed at which a device can write data. | 520 MB/s |
| Random read (4KB) | 95000 IOPS |
| Random write (4KB) | 30000 IOPS |
| Read latency | 175 µs |
| Write latency | 300 µs |
| Hot-swap |
 |
| Mean time between failures (MTBF) Statistical model used to indicate product/mechanism reliability; expressed in hours and percentage of duty cycle. This number (in hours) does not indicate the mean time before failure for a single unit/mechanism. | 3000000 h |
| Power | |
| Power consumption (read) | 2.8 W |
| Power consumption (write) | 3.8 W |
| Operational conditions | |
| Non-operating shock Environmental requirements for optimal protection from impact in non-operating mode | 1.5 G |
| SKU | 540464 |
| MPN | 4XB7A17084 |
| Brand | Lenovo |
| Product Condition | Brand New/Unused |
| Stock Availability | Available for Shipping |
| Product Use | General |
