PCIe NVMe; 22110 / 2280; M-key, 2 Slots; 10 Gbps; DSM version requirement: 6.2.3-25426 or later version
| Ports & interfaces | |
| Host interface Interface that enables a host controller to communicate with a driver. | PCIe |
| Output interface The socket (port) where the output connectors are connected. | PCIe |
| Expansion card form factor | Full-height / Low-profile |
| Expansion card standard | PCIe 3.0 |
| NVMe NVM Express (NVMe) or Non-Volatile Memory Host Controller Interface Specification (NVMHCIS) is an open logical device interface specification for accessing non-volatile storage media attached via a PCI Express (PCIe) bus. NVM Express, as a logical device interface, has been designed to capitalize on the low latency and internal parallelism of solid-state storage devices. |
 |
| Design | |
| Internal The product is built in. |
|
| Product colour The colour e.g. red, blue, green, black, white. | Black |
| Purpose What the product is used for. | NAS / Storage server |
| Cooling type The method used to cool the device or to cool the air around the device. | Passive |
| Features | |
| Data transfer rate (max) | 10 Gbit/s |
| Operational conditions | |
| Operating temperature (T-T) The minimum and maximum temperatures at which the product can be safely operated. | 0 - 40 °C |
| Storage temperature (T-T) The minimum and maximum temperatures at which the product can be safely stored. | -20 - 60 °C |
| Operating relative humidity (H-H) | 5 - 95% |
| Storage relative humidity (H-H) | 5 - 95% |
| Weight & dimensions | |
| Width The measurement or extent of something from side to side. | 200.1 mm |
| Depth The distance from the front to the back of something. | 17.7 mm |
| Height The measurement of the product from head to foot or from base to top. | 71.8 mm |
| Packaging data | |
| Quantity The number of products there are. | 1 |
| Quick installation guide |
|
| SKU | 394002 |
| MPN | E10M20-T1 |
| Brand | Synology |
| Product Condition | Brand New/Unused |
| Stock Availability | Available for Shipping |
| Product Use | General |
| Warranty Period | 5 Years Warranty |
| Warranty Contact | https://www.synology.com/ |
