LENOVO ThinkSystem 2.5' PM1643a 960GB Entry SAS 12Gb Hot Swap SS HDD for SR250/SR530/SR550/SR570/SR590/SR630/SR650/SR635/SR645/SR655/SR665/ST250/ST550
'Lenovo HDDs provide outstanding performance, high capacity and reliability.
- Outstanding performance for all mission critical applications
- Enterprise HDDs with enhanced sequential and random read/write performance, designed for critical business applications
- Offering highest capacity HDDs from industry leaders
- Lenovo offers a wide range of HDDs from storage industry leaders to ensure the best technology and highest capacity points are available to our customers
- Excellent reliability and performance in 24x7 operational environments
- Lenovo uses comprehensive validation and quality control measures to ensure best reliability and performance for all application workloads under 24x7 operation
- Protect data with Self-Encrypting drives
- Lenovo offers Self-encrypting drives to protect customer data against loss or theft as well as secure drive retirement, disposal, or repurposing
- Helium-filled drive assemblies for drives 12TB and larger (Helium provides a more stable environment and less turbulence and resistance to the flying heads. This enables a larger number of platters which results in larger storage capacity. The use of Helium also results in lower power consumption compared to air-filled drives.)
Workload limit: All 7200 RPM NL SAS and NL SATA drives have a workload limit of 550TB/year. 10K and 15K SAS drives do not have a workload limit.
| Features | |
| SSD form factor The size of the solid-state drive, given in inches | 2.5" |
| SSD capacity The Solid State Drive's data storage capacity. | 960 GB |
| Interface Interface ports to connect pieces of equipment. USB (Universal Serial Bus) has become the most popular wired interface to connect peripherals. USB 2.0 supports speeds up to 480 Mbit/s (USB 1: 12 Mbit/s). The interface FireWire is also known as the IEEE 1394 standard. Enhanced IDE (EIDE)is sometimes referred to as Fast ATA, Fast IDE or ATA-2. | SAS |
| Memory type Type of memory in the device e.g. DDR3, SRAM (Static RAM). | V-NAND TLC |
| Component for What this product is used as a part of (component for). | Server/workstation |
| Data transfer rate Rate at which data can be transferred. Usually expressed in units per second. May vary with network configurations. | 12 Gbit/s |
| Read speed The speed at which a device can read data. | 1000 MB/s |
| Write speed The speed at which a device can write data. | 1000 MB/s |
| Random read (4KB) | 230 IOPS |
| Random write (4KB) | 40 IOPS |
| Read latency | 240 µs |
| Write latency | 220 µs |
| S.M.A.R.T. support |
 |
| Hot-swap |
|
| Uncorrectable Bit Error Rate (UBER) | < 1 per 10^17 bits read |
| Mean time between failures (MTBF) Statistical model used to indicate product/mechanism reliability; expressed in hours and percentage of duty cycle. This number (in hours) does not indicate the mean time before failure for a single unit/mechanism. | 2000000 h |
| Power | |
| Power consumption (read) | 9 W |
| Power consumption (write) | 12 W |
| Operational conditions | |
| Operating temperature (T-T) The minimum and maximum temperatures at which the product can be safely operated. | 0 - 70 °C |
| Storage temperature (T-T) The minimum and maximum temperatures at which the product can be safely stored. | -40 - 85 °C |
| Operating relative humidity (H-H) | 5 - 95% |
| Technical details | |
| Sustainability certificates | RoHS |
| SKU | 561862 |
| MPN | 4XB7A38175 |
| Brand | Lenovo |
| Product Condition | Brand New/Unused |
| Stock Availability | Available for Shipping |
| Product Use | General |
| Warranty Period | 1 Year Warranty |
| Warranty Contact | https://www.lenovo.com/ |
