ViewSonic IFP8652-1C 86" 4K Interactive Touchscreen Display
Item No:
806183
MPN:
IFP8652-1C
$9,999.00
Payment options
Shipping Information
- Unavailable for shipping
- This product is not currently available for purchase
Store Availability
- Unavailable at Bankstown Store
- Unavailable at Castle Hill Store
- Unavailable at Northmead Store
Viewsonic 86' 4K Interactive Touchscreen Display, ViewBoard IFP8652-1C Business Education, 33 point Touch with Naturally Smooth 5 Years On site Wty
IFP8652-1C
ULTRA HD RESOLUTION: 86 Inch 4K Ultra HD (3840x2160p) Display
ADVANCED TOUCH: 33-point Multi-touch lets users write or draw on the panel with their fingers and styluses
MEANINGFUL COLLABORATION: Incredible capabilities for conference rooms, classrooms, and hybrid environments
FLEXIBLE CONNECTIVITY: Powerful quad-core processor and versatile connectivity options (HDMI,VGA, RJ45, and USB-C ports)
INTEGRATED SOFTWARE: The myViewBoard suite includes Whiteboard, ViewBoard Cast, and more for better engagement
REMOTE MANAGEMENT: Schedule updates and monitor device status with the built-in myViewBoard® Manager software
PEACE OF MIND: Industry-leading 3-year standard warranty with optional extensions and robust support services
Upgradable to Android 11
Device Agnostic and Software Compatible
Designed to use the software you know, the ViewBoard 52 Series operates on Android and is compatible with Windows, Mac, Chrome and Linux with full touch input functionality for all connected devices.
DIMENSIONS (W x H x D)
Physical (inch / mm): 1966.4 (W) x 1204.4 (H) x 118.4 (D) mm, 77.42 (W) x 47.42 (H) x 4.66 (D) inch
Packaging (inch / mm): 2140 (W) x 1340 (H) x 280 (D) mm, 84.25 (W) x 52.76 (H) x 11.02 (D) inch
WEIGHT
Net (lb / kg): 156.53 lb / 71.0 kg
Gross (lb / kg): 196.43 lb / 89.1 kg
ULTRA HD RESOLUTION: 86 Inch 4K Ultra HD (3840x2160p) Display
ADVANCED TOUCH: 33-point Multi-touch lets users write or draw on the panel with their fingers and styluses
MEANINGFUL COLLABORATION: Incredible capabilities for conference rooms, classrooms, and hybrid environments
FLEXIBLE CONNECTIVITY: Powerful quad-core processor and versatile connectivity options (HDMI,VGA, RJ45, and USB-C ports)
INTEGRATED SOFTWARE: The myViewBoard suite includes Whiteboard, ViewBoard Cast, and more for better engagement
REMOTE MANAGEMENT: Schedule updates and monitor device status with the built-in myViewBoard® Manager software
PEACE OF MIND: Industry-leading 3-year standard warranty with optional extensions and robust support services
Upgradable to Android 11
Device Agnostic and Software Compatible
Designed to use the software you know, the ViewBoard 52 Series operates on Android and is compatible with Windows, Mac, Chrome and Linux with full touch input functionality for all connected devices.
DIMENSIONS (W x H x D)
Physical (inch / mm): 1966.4 (W) x 1204.4 (H) x 118.4 (D) mm, 77.42 (W) x 47.42 (H) x 4.66 (D) inch
Packaging (inch / mm): 2140 (W) x 1340 (H) x 280 (D) mm, 84.25 (W) x 52.76 (H) x 11.02 (D) inch
WEIGHT
Net (lb / kg): 156.53 lb / 71.0 kg
Gross (lb / kg): 196.43 lb / 89.1 kg
| Display | |
| Display diagonal Size of the display for this product, measured diagonally, usually in inches. | 2.17 m (85.6") |
| Display brightness Brightness is the amount of radiating light emitted from the screen. The brightness rating is measured in candellas per square meter, commonly known as 'nits'. | 350 cd/m² |
| Display resolution The number of distinct pixels in each dimension that can be displayed. It is usually quoted as width × height, with the units in pixels: for example, "1024 × 768" means the width is 1024 pixels and the height is 768 pixels. The higher the number of pixels, the sharper the image. | 3840 x 2160 pixels |
| HD type Type of supported High Definition (e.g. Full HD, 4K Ultra HD). | 4K Ultra HD |
| Contrast ratio (typical) The difference in light intensity between the brightest white and the darkest black. | 1100:1 |
| Contrast ratio (dynamic) A property of a display system, defined as the ratio of the luminance of the brightest color (white) to that of the darkest color (black) that the system is capable of producing. | 2500:1 |
| Response time The response time is the time difference between the moment that a source (for example a video card) sends a signal and that equipment (for example a monitor) receives or display the signal. (Used abbreviations: R/F = Rise and Fall.) | 8 ms |
| Maximum refresh rate | 60 Hz |
| Touchscreen A screen of a laptop, smartphone, etc., that responds to touch so you can control the interface using your fingers. |
 |
| Touch technology Technology of touch sensetive screen e.g. dual-touch. | Multi-touch |
| Touchscreen type There are a variety of touchscreen technologies that have different methods of sensing touch, including resistive and capacitive. | Infrared |
| Number of simultaneous touchpoints | 33 |
| Viewing angle, horizontal Maximum horizontal angle at which a display can be viewed with acceptable visual performance. | 178° |
| Viewing angle, vertical Maximum vertical angle at which a display can be viewed with acceptable visual performance. | 178° |
| Screen glass thickness | 3.2 mm |
| Computer system | |
| Operating system installed Type of operating system on a device e.g. IOS on Apple devices, Android for mobile devices. | Android 9 |
| Built-in processor Whether or not a processor is built into the device. |
|
| Processor architecture | ARM Cortex-A73 |
| Processor frequency The speed that the microprocessor executes each instruction or each vibration of the clock. The CPU requires a fixed number of clock ticks, or cycles, to execute each instruction. The faster the clocks rate, the faster the CPU, or the faster it can execute instructions. Clock Speeds are usually determined in MHz, 1 MHz representing 1 million cycles per second, or in GHz, 1 GHz representing 1 thousand million cycles per second. The higher the CPU speed, the better a computer will perform. | 1.8 GHz |
| Processor cores The number of central processing units ('cores') in a processor. Some processors have 1 core, others have 2 (e.g. Intel Core Duo) or more (e.g. the Intel Xeon E7-2850 has 10 cores). | 4 |
| User memory | 32 GB |
| RAM capacity | 4 GB |
| RAM type The type of RAM (random access memory) inside the device e.g. DDR3. | LPDDR4 |
| Audio | |
| Built-in speaker(s) The device contains speaker(s) to produce sound. |
|
| Number of built-in speakers | 2 |
| Speaker power | 15 W |
| Built-in subwoofer The product has built-in subwoofer, which is a loudspeaker component designed to reproduce very low bass frequencies. |
|
| Subwoofer RMS power This is a measure of the continuous power (RMS power) produced by a subwoofer. | 15 W |
| Built-in microphone Microphone that is found inside the product. |
|
| Number of microphone arrays | 8 |
| Projector | |
| Built-in projector The device has an internal projector, to show images. |
 |
| Network | |
| Ethernet LAN An Ethernet LAN (Local Area Network) interface is present, for a wired conection via a cable. |
|
| Ethernet LAN data rates The different speed levels of the Ethernet LAN connection. | 10,100,1000 Mbit/s |
| Ports & interfaces | |
| USB connector type The type of USB connector/port that this product has. | USB Type-A, USB Type-B |
| USB 2.0 Type-A hub ports quantity | 2 |
| USB 2.0 Type-B Touch ports quantity | 2 |
| HDMI ports quantity The number of sockets (ports) for HDMI connections. HDMI (High-Definition Multimedia Interface) is a compact audio/video interface for transferring uncompressed video data and compressed/uncompressed digital audio data from a HDMI-compliant device ("the source device") to a compatible computer monitor, video projector, digital television, or digital audio device. HDMI is a digital replacement for existing analog video standards. | 3 |
| USB Type-C ports quantity | 1 |
| HDMI version | 2.0 |
| Ethernet LAN (RJ-45) ports Number of Ethernet LAN (RJ-45) ports (connecting interfaces) in the device. Ethernet LAN (RJ-45) ports allow a computer to connect to the ethernet. | 1 |
| VGA (D-Sub) ports quantity Number of VGA (D-Sub) ports (connecting interfaces) in the device. The VGA (D-Sub) connector is a 15 pin connector between a computer and a monitor. It was first introduced in 1987 by IBM. | 1 |
| S/PDIF out port S/PDIF (Sony/Philips Digital Interconnect Format) is a digital audio interconnect used in consumer audio equipment over relatively short distances. The signal is transmitted over either a coaxial cable with RCA connectors or a fibre optic cable with TOSLINK connectors. |
|
| RS-232 ports The number of sockets (ports) for RS-232. An RS-232 serial port was once a standard feature of a personal computer, used for connections to modems, printers, mice, data storage, uninterruptible power supplies, and other peripheral devices. Now it has been largely replaced by USB and other ports. | 1 |
| Ergonomics | |
| Product colour The colour e.g. red, blue, green, black, white. | Black |
| VESA mounting |
|
| Panel mounting interface The product can be used wih VESA mounting interfaces. | 800 x 600 mm |
| Certification | cTUVus, FCC, ENERGY STAR, EPEAT Silver, Mexico Energy, CE, CB, RoHS, ErP, WEEE |
| Power | |
| Power consumption (typical) Amount of power consumed by this model, often expressed in watts (W). Typical values that manufacturers give are power consumption when off, standby/suspended mode, typical use, maximum usage. | 286.4 W |
| Power consumption (standby) The amount of electricity that is consumed when the product is on standby. | 0.5 W |
| AC input voltage The voltage of the AC electricity that is inputted into the product. | 100 - 240 V |
| Operational conditions | |
| Operating temperature (T-T) The minimum and maximum temperatures at which the product can be safely operated. | 0 - 40 °C |
| Operating relative humidity (H-H) | 10 - 90% |
| Weight & dimensions | |
| Width The measurement or extent of something from side to side. | 1957 mm |
| Depth The distance from the front to the back of something. | 120 mm |
| Height The measurement of the product from head to foot or from base to top. | 1211 mm |
| Weight Weight of the product without packaging (net weight). If possible, the net weight is given including standard accessories and supplies. Please note that sometimes the manufacturer leaves out the weight of accessories and/or supplies. | 68.7 kg |
| Packaging data | |
| Package width The distance from one side of the packaging to the other. | 2102 mm |
| Package depth The distance from the front to the back of the packaging. | 270 mm |
| Package height The distance from the top to the bottom of the packaging. | 1330 mm |
| Package weight Weight of the packaged product. | 81.4 kg |
| Quantity per pack | 1 pc(s) |
| Packaging content | |
| Cables included | AC, AV, HDMI, USB |
| Remote control included Component of an electronics device, most commonly a television set, DVD player and home theater systems originally used for operating the device wirelessly from a short line-of-sight distance. |
|
| Batteries included |
|
| Quick start guide Instructions, either online, as a computer program or in paper form, to allow you to set up and start using the product quickly. |
|
| SKU | 806183 |
| MPN | IFP8652-1C |
| Brand | ViewSonic |
| Product Condition | Brand New/Unused |
| Screen Size (Inches) | 86.00 Inch |
| Refresh Rate (Hz) | 60Hz |
| Screen Resolution | 3840x2160 (UHD/4K) |
| Input | HDMI, VGA / D-SUB |
| Product Use | General |
| Warranty Period | 5 Years Warranty |
| Warranty Contact | https://www.viewsonic.com/ |
