Vertiv AVOCENT HMX8000R 4KVideo IP KVM Receiver
Item No:
726233
MPN:
HMX8000R-400
$6,111.87
Payment options
Shipping Information
- Unavailable for shipping
- This product is not currently available for purchase
Store Availability
- Unavailable at Bankstown Store
- Unavailable at Castle Hill Store
- Unavailable at Northmead Store
Vertiv Avocent DH 4K,audio,USB2.0, 10GB Tx, Transmitter, Wired, Fiber, 4K @ 60 Hz (4096*2160), Black, Metal
The Vertiv Avocent HMX 8000 Series are an IP based high performance KVM (Keyboard, Video and Mouse) extender that can be part of a fully matrixed KVM solution when an HMX Advanced manager is added. The extender allows you the flexibility to locate your critical computing hardware in a secure and temperature controlled environment away from the user work station, while maintaining a pixel perfect desktop experience.
The Vertiv Avocent HMX8000 provides 4K video capability giving users access and control to computers over any distance without compromise to video and mouse performance.
The Avocent HMX8000 is an IP based, high performance KVM that eliminates distance limitations.
With less than a second switching between target computers and a fully redundant system with auto failover, the HMX8000 is ideal for the broadcasting, post production and control room environments where a many to many configuration is required.
The Vertiv Avocent HMX8000 provides 4K video capability giving users access and control to computers over any distance without compromise to video and mouse performance.
The Avocent HMX8000 is an IP based, high performance KVM that eliminates distance limitations.
With less than a second switching between target computers and a fully redundant system with auto failover, the HMX8000 is ideal for the broadcasting, post production and control room environments where a many to many configuration is required.
| Features | |
| Type Characteristics of the device. | Transmitter |
| Connectivity technology The technology that enables connectivity of the device, e.g. wired or wireless. | Wired |
| Cable types supported | Fiber |
| Rack mounting The type of mounting that can position devices in a shelving system (rack). |
 |
| Supported resolutions | 4K @ 60 Hz (4096*2160) |
| Firmware upgradeable |
|
| Product colour The colour e.g. red, blue, green, black, white. | Black |
| Material The material from which a thing is or can be made e.g. wood, plastic. | Metal |
| Easy to install |
|
| Plug and Play Indicates whether this product supports is "plug and play". Plug and play is hardware or software that, after being installed ("plugged in"), can immediately be used ("played with"), as opposed to hardware or software which requires configuration. |
|
| USB 2.0 ports quantity Number of USB 2.0 ports (connecting interfaces) in the device. USB 2.0 was released in April 2000 (now called "Hi-Speed"), adding higher maximum signaling rate of 480 Mbit/s (effective throughput up to 35 MB/s or 280 Mbit/s), USB 2.0 ports are usually black. | 2 |
| Transmitter | |
| Transmitter video port type | DisplayPort |
| Transmitter local video port type | DisplayPort |
| Number of displays supported The number of displays that can be used with this product. | 2 |
| Power | |
| AC input voltage The voltage of the AC electricity that is inputted into the product. | 100-240 V |
| AC input frequency | 50 - 60 Hz |
| AC adapter output voltage | 12 V |
| AC adapter output current | 5 A |
| Operational conditions | |
| Operating temperature (T-T) The minimum and maximum temperatures at which the product can be safely operated. | 0 - 50 °C |
| Operating relative humidity (H-H) | 10 - 90% |
| Weight & dimensions | |
| Transmitter width | 21.5 cm |
| Transmitter depth | 4.06 cm |
| Transmitter height | 21 cm |
| Transmitter weight | 1.81 kg |
| Packaging content | |
| AC adapter included |
|
| Quick installation guide |
|
| Ports & interfaces | |
| USB port type | USB Type-B |
| PC Audio in The socket (port) for the PC audio input. |
|
| Logistics data | |
| Harmonized System (HS) code | 84733080 |
| SKU | 726233 |
| MPN | HMX8000R-400 |
| Brand | Vertiv |
| Product Condition | Brand New/Unused |
| Product Use | General |
