Transcend TS512GMTE712A-I, 512 GB, M.2, 3800 MB/s, 64 Gbit/s
Transcend's M.2 SSD MTE712A is a self-encrypting drive (SED) that complies with the TCG Opal 2.0 standards. Data is protected using the hardware-based AES 256-bit encryption and LBA (Logical Block Address)sector-specific permissions.
The MTE712A features the 112-layer 3D NAND flash and the PCI Express (PCIe) Gen4 x4 interface, achieving never-before-seen transfer speeds. Its built-in DRAM cache allows faster random speeds while the 30" gold finger PCB, Corner Bond technology, and anti-sulfur resistor guarantee its reliability in harsh conditions. The MTE712A is fully tested in-house, operating stably in an extended operating temperature range (-20?75?).
Transcend also offers the MTE712A-I with wide temperature (-40? 85?) capabilities to ensure sustained functionality, enhanced endurance and optimal reliability in mission-critical applications.
The MTE712A features the 112-layer 3D NAND flash and the PCI Express (PCIe) Gen4 x4 interface, achieving never-before-seen transfer speeds. Its built-in DRAM cache allows faster random speeds while the 30" gold finger PCB, Corner Bond technology, and anti-sulfur resistor guarantee its reliability in harsh conditions. The MTE712A is fully tested in-house, operating stably in an extended operating temperature range (-20?75?).
Transcend also offers the MTE712A-I with wide temperature (-40? 85?) capabilities to ensure sustained functionality, enhanced endurance and optimal reliability in mission-critical applications.
| Features | |
| Security algorithms Security algorithms are used to provide authentication, cipher key generation, integrity and radio link privacy to users on mobile networks. The security algorithms supported are the ones that can be used with this product. | 192-bit AES, TCG Opal 2.0 |
| SSD capacity The Solid State Drive's data storage capacity. | 512 GB |
| SSD form factor The size of the solid-state drive, given in inches | M.2 |
| Interface Interface ports to connect pieces of equipment. USB (Universal Serial Bus) has become the most popular wired interface to connect peripherals. USB 2.0 supports speeds up to 480 Mbit/s (USB 1: 12 Mbit/s). The interface FireWire is also known as the IEEE 1394 standard. Enhanced IDE (EIDE)is sometimes referred to as Fast ATA, Fast IDE or ATA-2. | PCI Express 4.0 |
| NVMe NVM Express (NVMe) or Non-Volatile Memory Host Controller Interface Specification (NVMHCIS) is an open logical device interface specification for accessing non-volatile storage media attached via a PCI Express (PCIe) bus. NVM Express, as a logical device interface, has been designed to capitalize on the low latency and internal parallelism of solid-state storage devices. |
 |
| Memory type Type of memory in the device e.g. DDR3, SRAM (Static RAM). | 3D NAND |
| Component for What this product is used as a part of (component for). | PC/Laptop |
| Hardware encryption |
|
| M.2 SSD size | 2280 (22 x 80 mm) |
| Data transfer rate Rate at which data can be transferred. Usually expressed in units per second. May vary with network configurations. | 64 Gbit/s |
| Read speed The speed at which a device can read data. | 3800 MB/s |
| Write speed The speed at which a device can write data. | 3200 MB/s |
| Random read (4KB) | 350000 IOPS |
| Random write (4KB) | 330000 IOPS |
| Mean time between failures (MTBF) Statistical model used to indicate product/mechanism reliability; expressed in hours and percentage of duty cycle. This number (in hours) does not indicate the mean time before failure for a single unit/mechanism. | 3000000 h |
| Operational conditions | |
| Operating temperature (T-T) The minimum and maximum temperatures at which the product can be safely operated. | -20 - 75 °C |
| Storage temperature (T-T) The minimum and maximum temperatures at which the product can be safely stored. | -40 - 85 °C |
| Operating relative humidity (H-H) | 5 - 95% |
| Operating vibration Environmental requirements for vibration in operating mode | 20 G |
| Operating shock Environmental requirements for optimal protection from impact in operating mode | 15 G |
| SKU | 820674 |
| MPN | TS512GMTE712A-I |
| Brand | Transcend |
| Product Condition | Brand New/Unused |
| Product Use | General |
