Transcend 256GB PCIe M.2 2280 SSD

Item No:
Payment options

This product is currently not available!

Shipping Information
  • Unavailable for shipping
  • This product is not currently available for purchase
Store Availability
  • Unavailable at Bankstown
  • Unavailable at Blacktown
  • Unavailable at Castle Hill

NAND flash type TLC (Triple Level Cell)
SSD form factor The size of the solid-state drive, given in inches M.2
SSD capacity The Solid State Drive's data storage capacity. 256 GB
Interface Interface ports to connect pieces of equipment. USB (Universal Serial Bus) has become the most popular wired interface to connect peripherals. USB 2.0 supports speeds up to 480 Mbit/s (USB 1: 12 Mbit/s). The interface FireWire is also known as the IEEE 1394 standard. Enhanced IDE (EIDE)is sometimes referred to as Fast ATA, Fast IDE or ATA-2. PCI Express 3.0
Memory type Type of memory in the device e.g. DDR3, SRAM (Static RAM). 3D NAND
NVMe NVM Express (NVMe) or Non-Volatile Memory Host Controller Interface Specification (NVMHCIS) is an open logical device interface specification for accessing non-volatile storage media attached via a PCI Express (PCIe) bus. NVM Express, as a logical device interface, has been designed to capitalize on the low latency and internal parallelism of solid-state storage devices.
Component for What this product is used as a part of (component for). PC/notebook
Read speed The speed at which a device can read data. 1600 MB/s
Write speed The speed at which a device can write data. 800 MB/s
Random read (4KB) 110000 IOPS
Random write (4KB) 95000 IOPS
S.M.A.R.T. support
TRIM support
Low-density parity-check (LDPC)
Mean time between failures (MTBF) Statistical model used to indicate product/mechanism reliability; expressed in hours and percentage of duty cycle. This number (in hours) does not indicate the mean time before failure for a single unit/mechanism. 1000000 h
Windows operating systems supported Windows vesions wich can be used with the device. Windows 10,Windows 7,Windows 8
Mac operating systems supported Mac operating systems e.g. OS X can be used with the device.
Linux operating systems supported 8 RT. Linux (9.4, 9.5), Red Hat Enterprise Linux 5.0 (supported with a pre-built package); SUSE Linux (10.3, 11.0, 11, 11.1, 11.2), Fedora (9, 9.0, 10, 10.0, 11.0, 11, 12, 12.0), Ubuntu (8.04, 8.04.1, 8.04.2, 8.10, 9.04, 9.10, 10.04), Debian (5.0, 5.0.1, 5.0.2, 5.0.3) Kernel 2.6.31
Operating voltage Defines the range of operating voltages available 3.3 V
Operational conditions
Operating temperature (T-T) The minimum and maximum temperatures at which the product can be safely operated. 0 - 70 °C
Weight & dimensions
Width The measurement or extent of something from side to side. 22 mm
Depth The distance from the front to the back of something. 80 mm
Height The measurement of the product from head to foot or from base to top. 3.58 mm
Weight Weight of the product without packaging (net weight). If possible, the net weight is given including standard accessories and supplies. Please note that sometimes the manufacturer leaves out the weight of accessories and/or supplies. 8 g
Packaging data
Package type The type of product package e.g. box. Hanging box
More Information
SKU 319249
Brand Transcend
Product Condition Brand New/Unused
Drive Form Factor PCIe
Storage Technology SSD
Connection Interface PCIe Gen 3 NVMe M.2
Product Use Gaming
Warranty Period 2 Years Warranty
