Multi-mode SFP+/SFP28 LC Transceiver; Hot-Pluggable with maximum flexibility; Supports Digital Diagnostic Monitoring (DDM)
Low Power Consumption no more than 1W; Compatible with 10G/25G Small Form Pluggable Multi-Source Agreement (SFP+/SFP28 MSA); Compatible with switches with 25G ports like SX6632YF; and 10G ports like SG3428X and SG3452X.
| Performance | |
| SFP transceiver type | Fiber optic |
| Maximum data transfer rate The maximum speed with which data can be transmitted from one device to another. | 10000 Mbit/s |
| Interface type | SFP+ |
| Fiber optic connector This terminates the end of an optical fiber, and enables quicker connection and disconnection than splicing. The connectors mechanically couple and align the cores of fibers so light can pass. Better connectors lose very little light due to reflection or misalignment of the fibers. In all there have been about 100 types of optic fiber connectors produced. | LC (UPC) |
| SFP transceiver standard | SR |
| Wavelength The distance over which a wave repeats itself. The wavelength determines the characteristics of the wave e.g. red light has a different wavelength to blue light. | 850 nm |
| Digital Diagnostics Monitoring (DDM) |
 |
| Features | |
| Hot-swap |
|
| Certification | FCC, CE |
| Power | |
| Input voltage The voltage (V) which is required to power the product. | 3.3 V |
| Operational conditions | |
| Maximum operating temperature | 70 °C |
| Storage temperature (T-T) The minimum and maximum temperatures at which the product can be safely stored. | -40 - 80 °C |
| Operating relative humidity (H-H) | 10 - 90% |
| Storage relative humidity (H-H) | 5 - 90% |
| Weight & dimensions | |
| Width The measurement or extent of something from side to side. | 61.3 mm |
| Depth The distance from the front to the back of something. | 14.5 mm |
| Height The measurement of the product from head to foot or from base to top. | 12.2 mm |
| Packaging data | |
| Number of products included The number of products that are included in the package. | 1 pc(s) |
| SKU | 778331 |
| MPN | SM6110-SR |
| Brand | TP-Link |
| Product Condition | Brand New/Unused |
| Product Use | General |
| Warranty Period | 3 Years Warranty |
| Warranty Contact | https://www.tp-link.com/ |
| Stock Availability | Available for Shipping |
