4G+ Cat6 up to 300 Mbps; AX3000 Wi-Fi 6 with 2402 Mbps on 5GHz and 574 Mbps on 2.4GHz†; 3 × Gigabit WAN/LAN Ports (2 × PoE Out, 1 × PoE In); Nano SIM Card Slot; 802.3at/bt PoE or 12V/2A DC Power Supply; 4G and Ethernet WAN Auto Backup with Load Balancing; IPSec/L2TP/PPTP/OpenVPN/GRE/WireGuard/SSL VPN; Centralised Management; IP55 Weatherproofing
| Design | |
| Product colour The colour e.g. red, blue, green, black, white. | White |
| Mounting type Type of mounting e.g. wall mounting. | Wall mounting |
| LED indicators | Status |
| Features | |
| Antenna type Type of antenna, also known an aerial, e.g. external, internal. | External |
| Antenna gain level (max) Antenna gain is the measurement of an antenna's ability to amplify the incoming microwave signals in a particular direction, compared with the sensitivity of an isotropic antenna in any direction, or a dipole antenna in the equatorial direction. | 4 dBi |
| Antennas quantity | 2 |
| Short Message Service (SMS) |
 |
| Performance | |
| Control display unit |
 |
| Internal memory The amount of memory, usually measured in bytes (e.g. MB, GB), which is installed in the system's hardware. | 512 MB |
| Internal memory type The type of internal memory such as RAM, GDDR5. | DDR4 |
| Flash memory | 256 MB |
| Protocols | |
| DHCP server A server is a system which that responds to requests across a computer network to provide, or help to provide, a network service. DCHP servers uses the DCHP (Dynamic Host Configuration Protocol), which is a standardized networking protocol used by servers on an IP network to allocate IP addresses to computers. The purpose of DHCP is to automate the IP address configuration of a computer without a network administrator. IP addresses are typically selected from a range of assigned IP addresses stored in a database on the server and issued to a computer which requests a new IP address. An IP address is assigned to a computer for a set interval, after which, the computer must renew the IP address or acquire a new one. |
|
| Network | |
| Ethernet LAN data rates The different speed levels of the Ethernet LAN connection. | 10,100,1000 Mbit/s |
| Forwarding rate | 1453489 Mpps |
| Networking standards The way in which the network is working, e.g. IEEE 802.11a, IEEE 802.11b, IEEE 802.11g. | IEEE 802.3at, IEEE 802.3bt |
| Wi-Fi Popular technology that allows an electronic device to exchange data or connect to the internet wirelessly using radio waves. |
|
| Mobile network generation | 4G |
| Data network Telecommunications network that allows computers to exchange data. | LTE |
| Downlink/uplink speed | 300/50 Mbit/s |
| GSM bands supported | 850,900,1800,2100 MHz |
| Frequency band A small section of the spectrum of radio communication frequencies, in which channels are usually used or set aside for the same purpose e.g.for a channel on FM radio; for mobile networks to communicate with mobile phones. | 2.4/5 GHz |
| All services ready time | 3.8 s |
| SSL VPN throughput | 0.0866 Gbit/s |
| PPTP/L2TP VPN tunnels (max) | 50 |
| SSL VPN tunnels (max) | 50 |
| Security | |
| MAC address filtering Security access control method whereby the 48-bit address assigned to each network card is used to determine access to the network. MAC addresses are uniquely assigned to each card, so using MAC filtering on a network permits and denies network access to specific devices through the use of blacklists and whitelists. |
|
| Security algorithms Security algorithms are used to provide authentication, cipher key generation, integrity and radio link privacy to users on mobile networks. The security algorithms supported are the ones that can be used with this product. | SSID, WPA2, WPA3 |
| Ports & interfaces | |
| SIM card slot Whether the device features a SIM card slot. |
|
| SIM card type | NanoSIM |
| DC-in jack The socket/plug where the DC electricity supply connects to the device. |
|
| Management features | |
| Web-based management Using a website/web application to manage something. |
|
| Power | |
| Power consumption (max) The maximum amount of power used by the device. | 16.6 W |
| Power over Ethernet (PoE) The device supports Power over Ethernet (PoE), which is one of several standardized or ad-hoc systems which pass electrical power along with data on Ethernet cabling. This allows a single cable to provide both data connection and electrical power to devices such as wireless access points or IP cameras. |
|
| Weight & dimensions | |
| Width The measurement or extent of something from side to side. | 174 mm |
| Depth The distance from the front to the back of something. | 100.4 mm |
| Height The measurement of the product from head to foot or from base to top. | 38.7 mm |
| Operational conditions | |
| Operating temperature (T-T) The minimum and maximum temperatures at which the product can be safely operated. | -30 - 60 °C |
| Storage temperature (T-T) The minimum and maximum temperatures at which the product can be safely stored. | -40 - 70 °C |
| Operating relative humidity (H-H) | 5 - 95% |
| Storage relative humidity (H-H) | 5 - 90% |
| Certificates | |
| Certification | CE, FCC, RoHS |
| SKU | 813863 |
| MPN | ER703WP-4G-Outdoor |
| Brand | TP-Link |
| Product Condition | Brand New/Unused |
| Modem Type | 4G |
| Wired/Wireless | Wireless |
| Stock Availability | Available for Shipping |
| Warranty Period | 3 Years Warranty |
| Warranty Contact | https://www.tp-link.com/ |
