Standards: 5GHz 802.11ax/ac/n/a, 2.4GHz 802.11ax/n/b/g - WiFi 6 Speeds (Mbps): AX1800: 5GHz: 1201, 2.4GHz: 574 - Antennas: 2x Internal - Modes: Router or Access Point mode - CPU: 1.5GHz Quad Core - Microphone: Quad Array - Speaker: 5W - I/O: 2x Gigabit RJ45 - Includes: 1x Deco Voice X20, RJ45 Cable, 1x Power Adapter, Quick Installation Guide
| Design | |
| Product type The sub-category of the product. | Mesh router |
| Product colour The colour e.g. red, blue, green, black, white. | White |
| LED indicators | Power |
| Antenna type Type of antenna, also known an aerial, e.g. external, internal. | Internal |
| Antennas quantity | 2 |
| Reset button |
 |
| Wireless LAN features | |
| Wi-Fi band The frequency bands the product features. | Dual-band (2.4 GHz / 5 GHz) |
| Top Wi-Fi standard Connection of this device is done via Wi-Fi in a high standard. | Wi-Fi 6 (802.11ax) |
| Wi-Fi standards The type of wireless local area network (LAN). It can be ad-hoc, where units in a network communicate peer-to-peer, or Infrastructure, where units communicate with each other via an access point A LAN interconnects computers in a small area e.g. home, school or office. | 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax) |
| WLAN data transfer rate (first band) | 574 Mbit/s |
| WLAN data transfer rate (second band) | 1201 Mbit/s |
| Networking standards The way in which the network is working, e.g. IEEE 802.11a, IEEE 802.11b, IEEE 802.11g. | IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11k, IEEE 802.11n, IEEE 802.11r, IEEE 802.11v |
| Security algorithms Security algorithms are used to provide authentication, cipher key generation, integrity and radio link privacy to users on mobile networks. The security algorithms supported are the ones that can be used with this product. | WPA, WPA2-PSK, WPA3 |
| Number of guest networks (5 GHz) | 1 |
| Number of guest networks (2.4 GHz) | 1 |
| Point-to-point protocol over Ethernet (PPPoE) The Point-to-Point Protocol over Ethernet (PPPoE) is a network protocol for encapsulating PPP frames inside Ethernet frames. It appeared in 1999, in the context of the boom of DSL as the solution for tunneling packets over the DSL connection to the ISP's IP network, and from there to the rest of the Internet. A 2005 networking book noted that "Most DSL providers use PPPoE, which provides authentication, encryption, and compression." Typical use of PPPoE involves leveraging the PPP facilities for authenticating the user with a username and password, predominately via the PAP protocol and less often via CHAP. |
|
| Dynamic IP |
|
| Static IP |
|
| IGMP proxy |
|
| IGMP snooping |
|
| Tagged VLAN |
|
| Dynamic DNS (DDNS) |
|
| Guest access |
|
| Apps supported | TP-Link Deco |
| Features | |
| Built-in processor Whether or not a processor is built into the device. |
|
| Processor cores The number of central processing units ('cores') in a processor. Some processors have 1 core, others have 2 (e.g. Intel Core Duo) or more (e.g. the Intel Xeon E7-2850 has 10 cores). | 4 |
| Processor frequency The speed that the microprocessor executes each instruction or each vibration of the clock. The CPU requires a fixed number of clock ticks, or cycles, to execute each instruction. The faster the clocks rate, the faster the CPU, or the faster it can execute instructions. Clock Speeds are usually determined in MHz, 1 MHz representing 1 million cycles per second, or in GHz, 1 GHz representing 1 thousand million cycles per second. The higher the CPU speed, the better a computer will perform. | 1.5 GHz |
| Built-in microphone Microphone that is found inside the product. |
|
| Built-in speaker(s) The device contains speaker(s) to produce sound. |
|
| Speaker power | 5 W |
| Virtual assistant Depending on the make of the device, a different application is pre-installed that can understand voice commands and complete tasks for a user, e.g. Apple Siri, Amazon Alexa. | Amazon Alexa |
| Port forwarding |
|
| BeamForming |
|
| Transmitting power (CE) | <20 dBm (2.4 GHz) <23 dBm (5 GHz) |
| Transmitting power (FCC) | <30 dBm(2.4 GHz) <30 dBm(5 GHz) |
| NAT functionality | Port Forwarding UPnP |
| DHCP server A server is a system which that responds to requests across a computer network to provide, or help to provide, a network service. DCHP servers uses the DCHP (Dynamic Host Configuration Protocol), which is a standardized networking protocol used by servers on an IP network to allocate IP addresses to computers. The purpose of DHCP is to automate the IP address configuration of a computer without a network administrator. IP addresses are typically selected from a range of assigned IP addresses stored in a database on the server and issued to a computer which requests a new IP address. An IP address is assigned to a computer for a set interval, after which, the computer must renew the IP address or acquire a new one. |
|
| Parental control |
|
| Firmware upgradeable via | Network |
| Supported WAN type | Dynamic IP Static IP PPPoE PPTP L2TP |
| MU-MIMO technology |
|
| MIMO |
|
| Operating modes | Router, Access Point |
| Ports & interfaces | |
| Ethernet LAN (RJ-45) ports Number of Ethernet LAN (RJ-45) ports (connecting interfaces) in the device. Ethernet LAN (RJ-45) ports allow a computer to connect to the ethernet. | 2 |
| DC-in jack The socket/plug where the DC electricity supply connects to the device. |
|
| Power | |
| AC input voltage The voltage of the AC electricity that is inputted into the product. | 100 - 240 V |
| AC adapter input current | 0.6 A |
| AC input frequency | 50/60 Hz |
| AC adapter output voltage | 12 V |
| AC adapter output current | 1.5 A |
| Certificates | |
| Certification | CE, EAC, FCC, IC, RoHS, RCM |
| Operational conditions | |
| Operating temperature (T-T) The minimum and maximum temperatures at which the product can be safely operated. | 0 - 40 °C |
| Storage temperature (T-T) The minimum and maximum temperatures at which the product can be safely stored. | -40 - 60 °C |
| Operating relative humidity (H-H) | 10 - 90% |
| Storage relative humidity (H-H) | 5 - 90% |
| Weight & dimensions | |
| Width The measurement or extent of something from side to side. | 105 mm |
| Depth The distance from the front to the back of something. | 105 mm |
| Height The measurement of the product from head to foot or from base to top. | 170 mm |
| Packaging content | |
| Number of products included The number of products that are included in the package. | 1 pc(s) |
| AC adapter included |
|
| Number of units included | 1 pc(s) |
| Ethernet cable |
|
| Packaging data | |
| Package width The distance from one side of the packaging to the other. | 276.5 mm |
| Package depth The distance from the front to the back of the packaging. | 151 mm |
| Package height The distance from the top to the bottom of the packaging. | 151 mm |
| Package weight Weight of the packaged product. | 1.03 kg |
| Logistics data | |
| Harmonized System (HS) code | 85171800 |
| SKU | 569331 |
| MPN | DECOVOICEX20 |
| Brand | TP-Link |
| Product Condition | Brand New/Unused |
| Stock Availability | Available for Shipping |
| Warranty Period | 3 Years Warranty |
| Warranty Contact | https://www.tp-link.com/ |
