Unparalleled Tri-Band Speed — Boost your overall speeds up to 2402 Mbps (6 GHz) + 2402 Mbps (5 GHz) + 574 Mbps (2.4 GHz); WiFi 6E Standard — Expand to the clearer, broader 6 GHz band for more bandwidth and faster speeds. Currently 6 GHz Band only supported on Windows 11; Wider Signal Coverage — Two multi-directional antennas are designed for optimal signal reception; Bluetooth 5.3 — Security and reliability improvement than last-gen high-speed Bluetooth 5.2; Improved Security — The latest security enhancement, WPA3, provides enhanced protection in personal password safety; Reliably Engineered — The gold plating improve stability and performance even at high CPU temps; Backward Compatibility — Full support for 802.11ax/ac/a/b/g/n standards
| Ports & interfaces | |
| Connectivity technology The technology that enables connectivity of the device, e.g. wired or wireless. | Wired |
| Host interface Interface that enables a host controller to communicate with a driver. | PCI Express |
| Interface Interface ports to connect pieces of equipment. USB (Universal Serial Bus) has become the most popular wired interface to connect peripherals. USB 2.0 supports speeds up to 480 Mbit/s (USB 1: 12 Mbit/s). The interface FireWire is also known as the IEEE 1394 standard. Enhanced IDE (EIDE)is sometimes referred to as Fast ATA, Fast IDE or ATA-2. | WLAN / Bluetooth |
| Network | |
| Maximum data transfer rate The maximum speed with which data can be transmitted from one device to another. | 2402 Mbit/s |
| Networking standards The way in which the network is working, e.g. IEEE 802.11a, IEEE 802.11b, IEEE 802.11g. | IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n |
| Wi-Fi Popular technology that allows an electronic device to exchange data or connect to the internet wirelessly using radio waves. |
 |
| Wi-Fi band The frequency bands the product features. | Tri-band (2.4 GHz / 5 GHz / 6 GHz) |
| Top Wi-Fi standard Connection of this device is done via Wi-Fi in a high standard. | Wi-Fi 6E (802.11ax) |
| Wi-Fi standards The type of wireless local area network (LAN). It can be ad-hoc, where units in a network communicate peer-to-peer, or Infrastructure, where units communicate with each other via an access point A LAN interconnects computers in a small area e.g. home, school or office. | 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6E (802.11ax) |
| WLAN data transfer rates supported | 54,300,1732,2402 Mbit/s |
| Security algorithms Security algorithms are used to provide authentication, cipher key generation, integrity and radio link privacy to users on mobile networks. The security algorithms supported are the ones that can be used with this product. | WEP, WPA, WPA-PSK, WPA2, WPA2-PSK, WPA3 |
| Bluetooth Bluetooth is a low-power radio technology developed to replace the cables and wires currently used to link or connect electronic devices such as personal computers, printers, and a wide variety of handheld devices including mobile phones. Because it uses radio-wave connectivity, a Bluetooth-enabled device has a constant, established connection to whatever browser it uses. This saves the user the trouble of logging on to check for emails or news updates, for example. |
|
| Bluetooth version The type of bluetooth technology in the product e.g. Bluetooth Smart (v4.0). | 5.3 |
| Design | |
| Component for What this product is used as a part of (component for). | PC |
| Product colour The colour e.g. red, blue, green, black, white. | Black |
| Internal The product is built in. |
|
| Antenna |
|
| Antenna design | External |
| Antenna type Type of antenna, also known an aerial, e.g. external, internal. | 2x2 |
| Transmitting power (CE) | 5 GHz: 15, 2.4 GHz: 16 |
| Transmitting power (FCC) | 5 GHz: 20, 2.4 GHz: 20, 6 GHz: 12 |
| Operating modes | Infrastructure mode |
| System requirements | |
| Windows operating systems supported Windows vesions wich can be used with the device. | Windows 10 Education x64, Windows 10 Enterprise x64, Windows 10 Home x64, Windows 10 x64, Windows 11, Windows 11 Enterprise x64, Windows 11 x64 |
| Operational conditions | |
| Operating temperature (T-T) The minimum and maximum temperatures at which the product can be safely operated. | 0 - 40 °C |
| Operating relative humidity (H-H) | 10 - 90% |
| Storage relative humidity (H-H) | 5 - 95% |
| Sustainability | |
| Sustainability compliance |
|
| Weight & dimensions | |
| Width The measurement or extent of something from side to side. | 78.5 mm |
| Depth The distance from the front to the back of something. | 21 mm |
| Height The measurement of the product from head to foot or from base to top. | 120 mm |
| Packaging data | |
| Package width The distance from one side of the packaging to the other. | 201.5 mm |
| Package depth The distance from the front to the back of the packaging. | 152.5 mm |
| Package height The distance from the top to the bottom of the packaging. | 41.5 mm |
| Package weight Weight of the packaged product. | 240 g |
| Packaging content | |
| Mounting brackets included |
|
| Resource CD |
|
| Bluetooth header cable |
|
| Quick installation guide |
|
| Technical details | |
| Compliance certificates | CE, Federal Communications Commission (FCC), RoHS |
| SKU | 808793 |
| MPN | Archer TXE72E |
| Brand | TP-Link |
| Product Condition | Brand New/Unused |
| Adapter Type | Networking Adapter, Universal Adapter |
| Stock Availability | Available for Shipping |
| Warranty Period | 3 Years Warranty |
| Warranty Contact | https://www.tp-link.com/ |
