Faster Dual-Band AX3000 WiFi: Up to 3.0 Gbps (2402 Mbps + 574 Mbps) WiFi for faster browsing, streaming and downloading, all at the same time.
2.5G Multi-Gigabit Port: 1× 2.5 Gbps WAN/LAN port + 1× 1 Gbps WAN/LAN port + 3× Gigabit LAN ports + 1× USB 3.0 port ensure max flexibility and boosted throughput.
Maximised Coverage: Four high-gain antennas equipped with Beamforming ensure vast coverage.
Connect More Devices: OFDMA technology increases capacity by 4 times to enable simultaneous transmission to more devices.‡
VPN Client Supported: Allow devices in your home network to access remote VPN servers without needing to install VPN software on every device.
TP-Link HomeShield: Enhanced security defends against the latest cyber threats.△
TP-Link OneMesh Supported: Flexibly Create Whole Home WiFi with Archer AX55 Pro by adding a OneMesh supported Range Extender.
Compatible with Alexa: Control your router via voice commands and make your life smarter and easier with Amazon Alexa.
| WAN connection | |
| Ethernet WAN |
 |
| DSL WAN Whether or not the product features a DSL WAN (Wide Area Network) connection option. |
 |
| SIM card slot Whether the device features a SIM card slot. |
|
| 3G/4G USB modem compatibility |
|
| WAN connection type | RJ-45 |
| Wireless LAN features | |
| Wi-Fi band The frequency bands the product features. | Dual-band (2.4 GHz / 5 GHz) |
| Top Wi-Fi standard Connection of this device is done via Wi-Fi in a high standard. | Wi-Fi 6 (802.11ax) |
| WLAN data transfer rate (max) | 2402 Mbit/s |
| Wi-Fi standards The type of wireless local area network (LAN). It can be ad-hoc, where units in a network communicate peer-to-peer, or Infrastructure, where units communicate with each other via an access point A LAN interconnects computers in a small area e.g. home, school or office. | Wi-Fi 6 (802.11ax) |
| WLAN data transfer rate (first band) | 2402 Mbit/s |
| WLAN data transfer rate (second band) | 574 Mbit/s |
| Network | |
| Ethernet LAN An Ethernet LAN (Local Area Network) interface is present, for a wired conection via a cable. |
|
| Ethernet LAN interface type The characteristics of the Ethernet LAN interface. | Gigabit Ethernet |
| Networking standards The way in which the network is working, e.g. IEEE 802.11a, IEEE 802.11b, IEEE 802.11g. | IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n |
| Port forwarding |
|
| Port triggering |
|
| Dynamic DNS (DDNS) |
|
| Number of guest networks (2.4 GHz) | 1 |
| Number of guest networks (5 GHz) | 1 |
| USB sharing |
|
| Support Samba (storage) |
|
| Built-in FTP server |
|
| VPN server | OpenVPN, PPTP, L2TP |
| Media server |
|
| VPN support | OpenVPN, PPTP, L2TP |
| Ports & interfaces | |
| Ethernet LAN (RJ-45) ports Number of Ethernet LAN (RJ-45) ports (connecting interfaces) in the device. Ethernet LAN (RJ-45) ports allow a computer to connect to the ethernet. | 5 |
| USB port The device features a socket into which a USB cable can be plugged. |
|
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 1 |
| Management features | |
| Quality of Service (QoS) support |
|
| Reset button |
|
| WPS push button |
|
| Security | |
| Security algorithms Security algorithms are used to provide authentication, cipher key generation, integrity and radio link privacy to users on mobile networks. The security algorithms supported are the ones that can be used with this product. | WPA, WPA2, WPA3 |
| Firewall |
|
| Firewall security Part of a computer system or network which is designed to block unauthorized access while permitting outward communication. | SPI Firewall |
| Guest access |
|
| Stateful Packet Inspection (SPI) |
|
| DoS attack prevention |
|
| Parental control |
|
| DMZ support |
|
| Network address translation (NAT) |
|
| NAT functionality | • Port Forwarding • Port Triggering • DMZ • UPnP |
| Protocols | |
| DHCP client Whether the product features a DHCP (Dynamic Host Configuration Protocol) to obtain IP addresses within a network. |
|
| DHCP server A server is a system which that responds to requests across a computer network to provide, or help to provide, a network service. DCHP servers uses the DCHP (Dynamic Host Configuration Protocol), which is a standardized networking protocol used by servers on an IP network to allocate IP addresses to computers. The purpose of DHCP is to automate the IP address configuration of a computer without a network administrator. IP addresses are typically selected from a range of assigned IP addresses stored in a database on the server and issued to a computer which requests a new IP address. An IP address is assigned to a computer for a set interval, after which, the computer must renew the IP address or acquire a new one. |
|
| Universal Plug and Play (UPnP) |
|
| Design | |
| Product colour The colour e.g. red, blue, green, black, white. | Black |
| Indication light |
|
| On/off switch The button which is pressed to switch the device on or off. |
|
| Product type The sub-category of the product. | Desktop/pole router |
| Certificates | |
| Certification | FCC, CE, RoHS |
| Packaging content | |
| Cables included | LAN (RJ-45) |
| AC adapter included |
|
| Antenna included An antenna (aerial) is built into the product or comes with it. |
|
| Quick installation guide |
|
| Antenna | |
| Antenna design | External |
| Antenna type Type of antenna, also known an aerial, e.g. external, internal. | 2x2 |
| Antennas quantity | 4 |
| Power | |
| Power source type What the power source is. | DC |
| Operational conditions | |
| Operating temperature (T-T) The minimum and maximum temperatures at which the product can be safely operated. | 0 - 40 °C |
| Storage temperature (T-T) The minimum and maximum temperatures at which the product can be safely stored. | -40 - 70 °C |
| Operating relative humidity (H-H) | 10 - 90% |
| Storage relative humidity (H-H) | 5 - 90% |
| Weight & dimensions | |
| Width The measurement or extent of something from side to side. | 261.1 mm |
| Depth The distance from the front to the back of something. | 134.5 mm |
| Height The measurement of the product from head to foot or from base to top. | 41 mm |
| Packaging data | |
| Number of products included The number of products that are included in the package. | 1 pc(s) |
| SKU | 707126 |
| MPN | ARCHER AX55 PRO |
| Brand | TP-Link |
| Product Condition | Brand New/Unused |
| Modem Type | 5G |
| Wired/Wireless | Wireless |
| Stock Availability | Available for Shipping, In Stock at Bankstown, In Stock at Castle Hill, In Stock at Warehouse |
| Warranty Period | 3 Years Warranty |
| Warranty Contact | https://www.tp-link.com/ |
