Teltonika RUT241 LTE CAT 4 Router

Design
Device type Type or category of the device.	Cellular network router
Product colour The colour e.g. red, blue, green, black, white.	Black
Housing material What the casing of the product is made of.	Aluminium, Plastic
Mounting What size the mounting head of the product is, to couple it with a camera.	DIN-rail
Market positioning Under which category can the device be positioned in the market, e.g. camera phone.	Industrial
Built-in display A display which is part of the product, so you do not need to attach another display.
Reset button
LED indicators

Ethernet LAN features
Ethernet LAN An Ethernet LAN (Local Area Network) interface is present, for a wired conection via a cable.
Ethernet LAN interface type The characteristics of the Ethernet LAN interface.	Fast Ethernet
Ethernet LAN data rates The different speed levels of the Ethernet LAN connection.	10,100 Mbit/s
Networking standards The way in which the network is working, e.g. IEEE 802.11a, IEEE 802.11b, IEEE 802.11g.	IEEE 802.3, IEEE 802.3u
Auto MDI/MDI-X A Medium Dependent Interface (MDI) describes the interface (both physical and electrical) in a computer network from a physical layer implementation to the physical medium used to carry the transmission. Ethernet over twisted pair also defines a medium dependent interface crossover (MDIX) interface. Auto-MDIX ports on newer network interfaces detect if the connection would require a crossover, and automatically chooses the MDI or MDIX configuration to properly match the other end of the link.

Wireless LAN features
Wi-Fi Popular technology that allows an electronic device to exchange data or connect to the internet wirelessly using radio waves.
Wi-Fi standards The type of wireless local area network (LAN). It can be ad-hoc, where units in a network communicate peer-to-peer, or Infrastructure, where units communicate with each other via an access point A LAN interconnects computers in a small area e.g. home, school or office.	802.11b, 802.11g, Wi-Fi 4 (802.11n)

Mobile network
Data network Telecommunications network that allows computers to exchange data.	2G, 3G, 4G
4G standard	LTE
2G bands supported	900,1800 MHz
3G bands supported	850,900,2100 MHz
4G bands supported	2300,2500,2600 MHz
Number of SIM cards	1
Short Message Service (SMS)

Ports & interfaces
Ethernet LAN (RJ-45) ports Number of Ethernet LAN (RJ-45) ports (connecting interfaces) in the device. Ethernet LAN (RJ-45) ports allow a computer to connect to the ethernet.	1

Security
Security algorithms Security algorithms are used to provide authentication, cipher key generation, integrity and radio link privacy to users on mobile networks. The security algorithms supported are the ones that can be used with this product.	HTTPS, SSH, SSL/TLS, WEP, WPA-EAP, WPA-PSK, WPA2-Enterprise, WPA2-PSK
Network address translation (NAT)
Firewall
DMZ support
Port forwarding

Performance
Built-in processor Whether or not a processor is built into the device.
Processor frequency The speed that the microprocessor executes each instruction or each vibration of the clock. The CPU requires a fixed number of clock ticks, or cycles, to execute each instruction. The faster the clocks rate, the faster the CPU, or the faster it can execute instructions. Clock Speeds are usually determined in MHz, 1 MHz representing 1 million cycles per second, or in GHz, 1 GHz representing 1 thousand million cycles per second. The higher the CPU speed, the better a computer will perform.	0.58 GHz
RAM capacity	0.128 GB

Management features
Web-based management Using a website/web application to manage something.

Antenna
Antenna type Type of antenna, also known an aerial, e.g. external, internal.	External
Antenna connector type The way in which the antenna is connected to the device e.g. coaxial.	SMA
Antennas quantity	3

Power
Power source type What the power source is.	DC
Output voltage	9 - 30 V

Operational conditions
Operating temperature (T-T) The minimum and maximum temperatures at which the product can be safely operated.	-40 - 75 °C
Operating relative humidity (H-H)	10 - 90%

Weight & dimensions
Width The measurement or extent of something from side to side.	83 mm
Depth The distance from the front to the back of something.	74 mm
Height The measurement of the product from head to foot or from base to top.	25 mm
Weight Weight of the product without packaging (net weight). If possible, the net weight is given including standard accessories and supplies. Please note that sometimes the manufacturer leaves out the weight of accessories and/or supplies.	125 g

Logistics data
Harmonized System (HS) code	85176990
