Synology SAT5200-480G, 480 GB, 2.5", 530 MB/s, 6 Gbit/s
Enterprise-grade SSD built for Synology systems
Synology SAT5200 SATA SSD offers stable I/O performance while reducing the latency of critical services and applications. It is built to handle mixed and intensive 24/7 workloads without compromising on endurance, providing a streamlined storage experience on Synology systems with minimal service disruptions.
Stable high performance for demanding environments
Engineered for demanding environments such as online transaction processing (OLTP) databases and virtualization deployments, Synology SAT5200 delivers stable high performance at up to 67,000 4K random write IOPS, allowing firms to modernize existing storage infrastructure effortlessly.
Enterprise-grade endurance and reliability
1.3 DWPD
Provides 1.3 DWPD within the 5-year warranty period to withstand 24/7 intensive workloads.
End-to-end data protection
Safeguards data integrity and consistency over the entire data transfer path.
Power loss protection circuit design
Dedicated capacitors provide sufficient power to flush data-in-flight into NAND flash during a power loss event, further preventing data corruption.
Lifetime analytics based on actual workload
Full integration with Synologys DiskStation Manager (DSM) enables lifetime analytics for each SAT5200 unit based on actual workloads3:
Timely Notifications
Plan further ahead for uninterrupted system performance and longevity with timely notifications.
Optimal Use
Easy monitoring allows you to make optimal use of each SSD.
Purpose-built for Synology systems
Synology SAT5200 is thoroughly tested for compatibility with our systems following each engineering change, while firmware and component changes are strictly managed. Intensive I/O stress, power cycling, and temperature
Synology SAT5200 SATA SSD offers stable I/O performance while reducing the latency of critical services and applications. It is built to handle mixed and intensive 24/7 workloads without compromising on endurance, providing a streamlined storage experience on Synology systems with minimal service disruptions.
Stable high performance for demanding environments
Engineered for demanding environments such as online transaction processing (OLTP) databases and virtualization deployments, Synology SAT5200 delivers stable high performance at up to 67,000 4K random write IOPS, allowing firms to modernize existing storage infrastructure effortlessly.
Enterprise-grade endurance and reliability
1.3 DWPD
Provides 1.3 DWPD within the 5-year warranty period to withstand 24/7 intensive workloads.
End-to-end data protection
Safeguards data integrity and consistency over the entire data transfer path.
Power loss protection circuit design
Dedicated capacitors provide sufficient power to flush data-in-flight into NAND flash during a power loss event, further preventing data corruption.
Lifetime analytics based on actual workload
Full integration with Synologys DiskStation Manager (DSM) enables lifetime analytics for each SAT5200 unit based on actual workloads3:
Timely Notifications
Plan further ahead for uninterrupted system performance and longevity with timely notifications.
Optimal Use
Easy monitoring allows you to make optimal use of each SSD.
Purpose-built for Synology systems
Synology SAT5200 is thoroughly tested for compatibility with our systems following each engineering change, while firmware and component changes are strictly managed. Intensive I/O stress, power cycling, and temperature
| Features | |
| SSD form factor The size of the solid-state drive, given in inches | 2.5" |
| SSD capacity The Solid State Drive's data storage capacity. | 480 GB |
| Interface Interface ports to connect pieces of equipment. USB (Universal Serial Bus) has become the most popular wired interface to connect peripherals. USB 2.0 supports speeds up to 480 Mbit/s (USB 1: 12 Mbit/s). The interface FireWire is also known as the IEEE 1394 standard. Enhanced IDE (EIDE)is sometimes referred to as Fast ATA, Fast IDE or ATA-2. | Serial ATA III |
| NVMe NVM Express (NVMe) or Non-Volatile Memory Host Controller Interface Specification (NVMHCIS) is an open logical device interface specification for accessing non-volatile storage media attached via a PCI Express (PCIe) bus. NVM Express, as a logical device interface, has been designed to capitalize on the low latency and internal parallelism of solid-state storage devices. |
 |
| Component for What this product is used as a part of (component for). | NAS |
| Data transfer rate Rate at which data can be transferred. Usually expressed in units per second. May vary with network configurations. | 6 Gbit/s |
| Read speed The speed at which a device can read data. | 530 MB/s |
| Write speed The speed at which a device can write data. | 500 MB/s |
| Random read (4KB) | 95000 IOPS |
| Random write (4KB) | 55000 IOPS |
| Mean time between failures (MTBF) Statistical model used to indicate product/mechanism reliability; expressed in hours and percentage of duty cycle. This number (in hours) does not indicate the mean time before failure for a single unit/mechanism. | 1500000 h |
| TBW rating | 1145 |
| RoHS compliance The Restriction of Hazardous Substances (RoHS) Directive aims to restrict certain dangerous substances commonly used in electrical and electronic equipment. Any RoHS compliant product is tested for the presence of Lead (Pb), Cadmium (Cd), Mercury (Hg), Hexavalent chromium (Hex-Cr), Polybrominated biphenyls (PBB), and Polybrominated diphenyl ethers (PBDE). PBB and PBDE are flame retardants used in several plastics. For Cadmium and Hexavalent chromium, there must be less than 0.01% of the substance by weight at raw homogeneous materials level. For Lead, PBB, and PBDE, there must be no more than 0.1% of the material, when calculated by weight at raw homogeneous materials. Any RoHS compliant component must have 100 ppm or less of mercury and the mercury must not have been intentionally added to the component. In the EU, some military and medical equipment are exempt from RoHS compliance. |
 |
| Certification | FCC CE BSMI VCCI RCM KC |
| Power | |
| Operating voltage Defines the range of operating voltages available | 5 V |
| Power consumption (read) | 2.6 W |
| Power consumption (write) | 4.2 W |
| Power consumption (idle) | 1.4 W |
| Operational conditions | |
| Operating temperature (T-T) The minimum and maximum temperatures at which the product can be safely operated. | 0 - 70 °C |
| Storage temperature (T-T) The minimum and maximum temperatures at which the product can be safely stored. | -40 - 85 °C |
| Weight & dimensions | |
| Width The measurement or extent of something from side to side. | 69.8 mm |
| Depth The distance from the front to the back of something. | 100 mm |
| Height The measurement of the product from head to foot or from base to top. | 7 mm |
| SKU | 440000 |
| MPN | SAT5200-480G |
| Brand | Synology |
| Product Condition | Brand New/Unused |
| Drive Form Factor | 2.5" |
| Connection Interface | SATA |
| Stock Availability | Available for Shipping |
| Product Use | General |
| Warranty Period | 5 Years Warranty |
| Warranty Contact | https://www.synology.com/ |
