Swann SWNVK-876804D-AU, Wired, Bullet, RJ-45, Outdoor, 80Deg, 80Deg
With the latest surveillance tech such as night vision, motion detection recording and smartphone integration, the Swann Master-Series NVR security system is packed with features. See fine details essential for evidence with upscaling cameras that cleverly create a 4K display resolution with powerful digital zoom to watch over entrances, yards, driveways, parking lots, shop floors, storerooms and more. It
| Camera | |
| Connectivity technology The technology that enables connectivity of the device, e.g. wired or wireless. | Wired |
| Camera included This product includes a camera. |
 |
| Colour The main colour of the product. |
|
| Surveillance camera form factor Design of the surveillance (security) camera. | Bullet |
| Built-in microphone Microphone that is found inside the product. |
|
| Camera interface The place where the camera connects to other devices e.g. USB port. | RJ-45 |
| Heat function This product has a mode to produce heat. |
|
| Placement supported Where the product can be placed e.g. indoor/outdoor, horizontal/vertical. | Indoor/outdoor |
| Viewing angle, horizontal Maximum horizontal angle at which a display can be viewed with acceptable visual performance. | 80° |
| Viewing angle, vertical Maximum vertical angle at which a display can be viewed with acceptable visual performance. | 80° |
| Night vision distance | 40 m |
| Supported resolutions | Up to 4K |
| International Protection (IP) code The IP code classifies and rates the degree of protection provided against the intrusion (including body parts such as hands and fingers), dust, accidental contact, and water by mechanical casings and electrical enclosures. It is published by the International Electrotechnical Commission (IEC). The digits (characteristic numerals) indicate conformity with the conditions summarized in the tables below. Where there is no protection rating with regard to one of the criteria, the digit is replaced with the letter X. an electrical socket rated IP22 is protected against insertion of fingers and will not be damaged or become unsafe during a specified test in which it is exposed to vertically or nearly vertically dripping water. Another example is the Sony Xperia Z Ultra, one of the first cellular phones to be IP-rated; it is rated at IP58 and marketed as "dust resistant" and can be "immersed in 1.5 meter of freshwater for up to 30 minutes". | IP66 |
| Recorder | |
| Recorder included The product includes a recorder. |
|
| Channels quantity The number of channels the device has. There can be an individual input or output for each channel. | 8 channels |
| Storage media type Type of storage medium, like flash, hard disk drive, etc. | HDD |
| Maximum storage capacity The maximum amount of data that can be stored in the device. | 6 TB |
| VGA (D-Sub) ports quantity Number of VGA (D-Sub) ports (connecting interfaces) in the device. The VGA (D-Sub) connector is a 15 pin connector between a computer and a monitor. It was first introduced in 1987 by IBM. | 1 |
| Audio input The type of audio input that the device requires, and the connection needed. | 8 x via PoE Ports |
| Audio output The type of audio output that the device produces, and the connector(s). | 1 x RCA, 1 x HDMI |
| USB 2.0 ports quantity Number of USB 2.0 ports (connecting interfaces) in the device. USB 2.0 was released in April 2000 (now called "Hi-Speed"), adding higher maximum signaling rate of 480 Mbit/s (effective throughput up to 35 MB/s or 280 Mbit/s), USB 2.0 ports are usually black. | 3 |
| Number of HDDs installed The number of hard drives built into the device. | 1 |
| HDD capacity The maximum storage capacity of the hard disk, usually measured in bytes e.g. GB. | 2 GB |
| Voice recording If the device is geared up for voice recording. |
|
| Line inputs (RCA) | 1 |
| HDMI ports quantity The number of sockets (ports) for HDMI connections. HDMI (High-Definition Multimedia Interface) is a compact audio/video interface for transferring uncompressed video data and compressed/uncompressed digital audio data from a HDMI-compliant device ("the source device") to a compatible computer monitor, video projector, digital television, or digital audio device. HDMI is a digital replacement for existing analog video standards. | 1 |
| Ethernet LAN (RJ-45) ports Number of Ethernet LAN (RJ-45) ports (connecting interfaces) in the device. Ethernet LAN (RJ-45) ports allow a computer to connect to the ethernet. | 1 |
| Motion sensor Device that detects moving objects, particularly people. A motion detector is often integrated as a component of a system that automatically performs a task or alerts a user of motion in an area. Motion detectors form a vital component of security, automated lighting control, home control, energy efficiency, and other useful systems. |
|
| Power over Ethernet (PoE) ports quantity | 8 |
| Network | |
| Ethernet LAN An Ethernet LAN (Local Area Network) interface is present, for a wired conection via a cable. |
|
| Power | |
| Power source type What the power source is. | AC, PoE |
| System requirements | |
| Mac operating systems supported Mac operating systems e.g. OS X can be used with the device. | MacOS |
| Mobile operating systems supported The operating systems e.g. Android, iOS, that can be used with the mobile device. | Android |
| Windows operating systems supported Windows vesions wich can be used with the device. |
|
| Technical details | |
| Video compression formats | H.264, H.265 |
| Audio system System used to play music or speech. | 1-way |
| Weight & dimensions | |
| Camera width | 10 cm |
| Camera height | 10 cm |
| Recorder width | 31 cm |
| Recorder depth | 23.5 cm |
| Recorder height | 5.3 cm |
| Packaging content | |
| Mouse included A mouse is included with this product. |
|
| Cables included | HDMI, UTP |
| Quick installation guide |
|
| SKU | 704903 |
| MPN | SWNVK-876804D-AU |
| Brand | Swann |
| Product Condition | Brand New/Unused |
| Product Use | General |
