StarTech Universal USB 3.0 Laptop Docking Station for Hot Desks - DVI

Item No:
247324
MPN:
USB3VDOCKD
$180.87
Payment options

This product is currently not available!

Shipping Information
  • Unavailable for shipping
  • This product is not currently available for purchase
Store Availability
  • Unavailable at Bankstown
  • Unavailable at Blacktown
  • Unavailable at Castle Hill

This DVI docking station for laptops offers a cost-effective way to create a simpler but highly functional workstation that can be used in permanent workspaces, or by multiple people in guest or hoteling (hot desk) environments.

If you don?t need all the connections and features of a traditional laptop docking station, you can use this dock to add the most essential connections (such as an extra display) to your laptop.

DVI laptop docking station being used at multiple hot desks in an office setting

Now you or your colleagues can be more productive and create an efficient and comfortable workspace, even in an area with minimal desk space.

Essential connections that are ideal for simple workstations

This laptop dock features basic device connections that are integrated into a small foot-print housing. Now you can create a permanent or hoteling (hot desking) workstation in a location with limited space. The dock offers an efficient solution for adding an extra display, a Gigabit network connection, and multiple USB devices without having to connect several individual adapters. And, with hotel desks or hot desks, laptop users aren?t tied to one specific workstation, so they can come and go easily.

The DVI dock offers simpler connectivity, so you can save money by avoiding a docking station that has connections you might never use. It?s perfect for anyone who needs to expand their connectivity in virtually any environment or application.

It?s a cost-effective docking station that still provides all the fundamental ports of a full-size workstation, such as DVI output, and when paired with your laptop display, you can easily set up dual monitors.

Diagram of the DVI laptop docking station connected to a laptop, monitor, keyboard, and network switch

Compact design maximizes your available space

If you?re running out of physical workspace, this USB 3.0 (also known as USB 3.1 Gen 1 - 5Gbps) docking station can help. Its compact design occupies minimal surface area, so you can integrate it into smaller areas than traditional docking stations or desktop computers would require.

By maximizing your available space, the compact dock can help eliminate the added cost and hassle of purchasing more offices, cubicles, or desks.

With fewer ports integrated into a small foot-print housing, the dock is a perfect fit for short-term work areas (hot desks). It?s ideal for mass deployment in business, classroom, computer lab, and government settings. Plus, it integrates nicely into home-office or office hoteling workspaces that have limited space.

The DVI docking station is about the size of one's hand, the image highlights the dock's compact and palm-sized design

Always-on fast-charge port makes charging easier

You can avoid the aggravation of a dead battery and make sure your mobile device is always ready to go, using the dock?s USB fast-charge and sync port. Plus, the always-on USB port supports device charging even when your laptop isn?t connected to the dock.

When you?re in a hurry, the easily accessible USB port charges your smartphone or tablet faster than traditional USB ports. This front-panel port ensures your mobile device is always within arm?s reach, so you can simultaneously get your work done while enjoying convenient device charging at your workstation.

Tablet shown connected to the dock's easy-access fast charge port

Universally supported

Unlike some proprietary docking stations designed only to work with specific laptop models, this universal laptop dock works with multiple brands. All you need is your laptop?s USB 3.0 port and you can be up and running quickly. With universal support, you can use this dock with different laptops now, or in the future.

The USB3VDOCKD is backed by a StarTech.com 3-year warranty and free lifetime technical support.

Connector(s)
Connector Type(s)3.5 mm Mini-Jack (4 Position) Female
DVI-I (29 pin) Female
RJ-45 Female
Security Lock Slot Female
USB 3.0 A (Fast-Charge, 9 pin, SuperSpeed) Female
USB Type-A (9 pin) USB 3.0 Female
USB Type-B (9 pin) USB 3.0 Female
Environmental
Humidity20~80% RH
Operating Temperature5?C to 50?C (41?F to 122?F)
Storage Temperature-20?C to 60?C (-4?F to 140?F)
Hardware
4K SupportNo
Bus TypeUSB 3.0
Chipset IDDisplayLink - DL-3700 (Display, LAN, Audio)
VLI - VL812 (USB 3.0 w/ Charge)
Displays Supported1
Fast-Charge Port(s)Yes
Industry StandardsUSB Battery Charging Specification Rev. 1.2
IEEE 802.3, IEEE 802.3u, IEEE 802.3ab
USB 3.0 - Backward compatible with USB 2.0/1.1
Indicators
LED IndicatorsActivity (Amber)
Link (Green)
Packaging Information
Shipping (Package) Weight540 g [19.1 oz]
Performance
Auto MDIXYes
Compatible Networks10/100/1000 Mbps
Full Duplex SupportYes
Maximum Data Transfer Rate5 Gbps (USB 3.0)
2 Gbps (Ethernet; Full-Duplex)
Maximum Digital Resolutions2048 x 1152 (DVI - Single Display)
Lower resolutions are also supported
Type and RateUSB 3.0 - 5 Gbit/s
UASP SupportYes
Physical Characteristics
ColorBlack & Silver
Enclosure TypePlastic
Product Height26 mm [1 in]
Product Length139 mm [5.5 in]
Product Weight154 g [5.4 oz]
Product Width79 mm [3.1 in]
Power
Center Tip PolarityPositive
Input Current0.8 A
Input Voltage100 ~ 240 AC
Output Current4 A
Output Voltage5 DC
Plug TypeM
Power Consumption (In Watts)20
Power SourceAC Adapter Included
Software
OS CompatibilityWindows? 7, 8, 8.1, 10
Mac OS? 10.8 to 10.12
Chrome OS?
Special Notes / Requirements
NoteIf connected to a USB 2.0 host port, or if using a USB 2.0 host connection cable, performance may be limited (USB 3.0 host cable included)
The DVI-I connector supports DVI-I signaling (digital and analog)
USB 3.0 is also known as USB 3.1 Gen 1; this connectivity standard offers speeds up to 5 Gbps
System and Cable RequirementsUSB-enabled computer with an available USB 3.0 port
What's in the Box
Included in Packageinstruction manual
laptop docking station
universal power adapter (NA/JP, EU, UK, ANZ)
USB 3.0 host cable
Ports & interfaces
Connectivity technology The technology that enables connectivity of the device, e.g. wired or wireless. Wired
Host interface Interface that enables a host controller to communicate with a driver. USB 3.2 Gen 1 (3.1 Gen 1) Type-B
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity 3
DVI-I ports quantity This is the amount of DVI-I interfaces. Digital Visual Interface (DVI) is a video display interface developed by the Digital Display Working Group (DDWG). The digital interface is used to connect a video source to a display device, such as a computer monitor. DVI-I is DVI integrated, which means it can support digital and analog. 1
Combo headphone/mic port
Headphone outputs Number of sockets /ports where headphones are connected. 1
Headphone connectivity How headphones connect to a device e.g. wirelessly or via a cable and connector. 3.5 mm
Network
Ethernet LAN An Ethernet LAN (Local Area Network) interface is present, for a wired conection via a cable.
Ethernet LAN (RJ-45) ports Number of Ethernet LAN (RJ-45) ports (connecting interfaces) in the device. Ethernet LAN (RJ-45) ports allow a computer to connect to the ethernet. 1
Ethernet LAN data rates The different speed levels of the Ethernet LAN connection. 10,100,1000 Mbit/s
Networking standards The way in which the network is working, e.g. IEEE 802.11a, IEEE 802.11b, IEEE 802.11g. IEEE 802.3,IEEE 802.3ab,IEEE 802.3u
Auto MDI/MDI-X A Medium Dependent Interface (MDI) describes the interface (both physical and electrical) in a computer network from a physical layer implementation to the physical medium used to carry the transmission. Ethernet over twisted pair also defines a medium dependent interface crossover (MDIX) interface. Auto-MDIX ports on newer network interfaces detect if the connection would require a crossover, and automatically chooses the MDI or MDIX configuration to properly match the other end of the link.
Full duplex A full-duplex system allows communication in both directions, and unlike half-duplex, allows this to happen simultaneously.
Performance
Card reader integrated The device includes a card reader e.g. a card reader in the disk bay of a computer or thin client to permit log-on using smart/pin cards.
Maximum digital resolution 2048 x 1152 pixels
Cable lock slot Holes on the edge of devices through which a cable lock can be passed, so the device can be locked to a desk etc.
Product colour The colour e.g. red, blue, green, black, white. Black,Silver
LED indicators
UASP support
Housing material What the casing of the product is made of. Plastic
Brand compatibility What other brands this brand can be used with. Universal
RoHS compliance The Restriction of Hazardous Substances (RoHS) Directive aims to restrict certain dangerous substances commonly used in electrical and electronic equipment. Any RoHS compliant product is tested for the presence of Lead (Pb), Cadmium (Cd), Mercury (Hg), Hexavalent chromium (Hex-Cr), Polybrominated biphenyls (PBB), and Polybrominated diphenyl ethers (PBDE). PBB and PBDE are flame retardants used in several plastics. For Cadmium and Hexavalent chromium, there must be less than 0.01% of the substance by weight at raw homogeneous materials level. For Lead, PBB, and PBDE, there must be no more than 0.1% of the material, when calculated by weight at raw homogeneous materials. Any RoHS compliant component must have 100 ppm or less of mercury and the mercury must not have been intentionally added to the component. In the EU, some military and medical equipment are exempt from RoHS compliance.
Certification CE, FCC
Power
AC input voltage The voltage of the AC electricity that is inputted into the product. 100-240 V
Input current 0.8 A
Output voltage 5 V
Output current 4 A
Power consumption (typical) Amount of power consumed by this model, often expressed in watts (W). Typical values that manufacturers give are power consumption when off, standby/suspended mode, typical use, maximum usage. 20 W
Power plug type Type M
Compatible power plug types AU,EU,UK,US
Software
Windows operating systems supported Windows vesions wich can be used with the device. Windows 10,Windows 10 Education,Windows 10 Education x64,Windows 10 Enterprise,Windows 10 Enterprise x64,Windows 10 Home,Windows 10 Home x64,Windows 10 IOT Core,Windows 10 Pro,Windows 10 Pro x64,Windows 7,Windows 7 Enterprise,Windows 7 Enterprise x64,Windows 7 Home Basic,Windows 7 Home Basic x64,Windows 7 Home Premium,Windows 7 Home Premium x64,Windows 7 Professional,Windows 7 Professional x64,Windows 7 Starter,Windows 7 Starter x64,Windows 7 Ultimate,Windows 7 Ultimate x64,Windows 7 x64,Windows 8,Windows 8 Enterprise,Windows 8 Enterprise x64,Windows 8 Pro,Windows 8 Pro x64,Windows 8 x64,Windows 8.1,Windows 8.1 Enterprise,Windows 8.1 Enterprise x64,Windows 8.1 Pro,Windows 8.1 Pro x64,Windows 8.1 x64
Mac compatibility Product can be used with Apple Mac software and/or hardware.
Mac operating systems supported Mac operating systems e.g. OS X can be used with the device. Mac OS X 10.10 Yosemite,Mac OS X 10.11 El Capitan,Mac OS X 10.12 Sierra,Mac OS X 10.13 High Sierra,Mac OS X 10.8 Mountain Lion,Mac OS X 10.9 Mavericks
Other operating systems supported Chrome
Weight & dimensions
Width The measurement or extent of something from side to side. 79 mm
Depth The distance from the front to the back of something. 139 mm
Height The measurement of the product from head to foot or from base to top. 26 mm
Weight Weight of the product without packaging (net weight). If possible, the net weight is given including standard accessories and supplies. Please note that sometimes the manufacturer leaves out the weight of accessories and/or supplies. 154 g
Packaging data
Package width The distance from one side of the packaging to the other. 215 mm
Package depth The distance from the front to the back of the packaging. 151 mm
Package height The distance from the top to the bottom of the packaging. 53 mm
Package weight Weight of the packaged product. 550 g
Packaging content
Cables included USB
AC adapter included
Manual
Operational conditions
Operating temperature (T-T) The minimum and maximum temperatures at which the product can be safely operated. 5 - 50 °C
Storage temperature (T-T) The minimum and maximum temperatures at which the product can be safely stored. -20 - 60 °C
Operating relative humidity (H-H) 20 - 80%
Other features
Chipset Set of electronic components in an integrated circuit that manages the data flow between the processor, memory and peripherals. It is usually found in the motherboard of a computer. Chipsets are usually designed to work with a specific family of microprocessors. Because it controls communications between the processor and external devices, the chipset plays a crucial role in determining system performance. DisplayLink - DL-3700, VLI - VL812
USB data transfer rates 5000 Mbit/s
More Information
SKU 247324
MPN USB3VDOCKD
Brand Startech
Product Condition Brand New/Unused
Warranty Period 3 Years Warranty
Warranty Contact https://www.startech.com/
