The HDMI2VGA HDMI® to VGA converter converts digital HDMI or DVI video signals to analog VGA, taking the input resolution from your device and converting it into an analog signal at the same resolution.
The converter also separates the audio stream from the HDMI signal (HDMI LPCM 2-Channel) and converts it to analog stereo audio that can be used with the VGA display.
With support for resolutions of up to 1080p, the HDMI2VGA converter is a perfect solution for connecting video cards (desktop or laptop) or consumer electronics devices such as game consoles or home theater receivers that offer an HDMI output to a VGA display.
The HDMI2VGA adapter/converter is simple to use, with no complicated settings, and is backed by a 2-year warranty and free, lifetime technical support.
| Connector(s) | |
| Connector A | HDMI (19 pin) Female Input |
| Connector B | 3.5 mm Mini-Jack (3 Position) Female Output |
| VGA (15 pin, High Density D-Sub) Female Output | |
| Environmental | |
| Humidity | 0~60% RH |
| Operating Temperature | 0?C to 40?C (32?F to 104°F) |
| Storage Temperature | -10?C to 60?C (14?F to 140°F) |
| Hardware | |
| Audio | Yes |
| Converter Type | Format Converter |
| Indicators | |
| LED Indicators | Power (Red) |
| Packaging Information | |
| Shipping (Package) Weight | 520 g [18.4 oz] |
| Performance | |
| Audio Specifications | HDMI? LPCM 2-channel Input |
| Supported Resolutions | PC: 1920x1200, 1600x1200, 1680x1050, 1440x900, 1280x1024, 1280x800, 1152x864, 1024x768, 800x600, 640x480 HD: 1080p/1080i (50, 60Hz), 720p (50, 60Hz), 576i/576p (50Hz), 480i/480p (60Hz) |
| Physical Characteristics | |
| Color | Black |
| Product Height | 92 mm [3.6 in] |
| Product Length | 76 mm [3 in] |
| Product Weight | 172 g [6.1 oz] |
| Product Width | 76 mm [3 in] |
| Power | |
| Center Tip Polarity | Positive |
| Input Current | 0.3A |
| Input Voltage | 100 ~ 240 AC |
| Output Current | 1.2A |
| Output Voltage | 5 DC |
| Plug Type | N |
| Power Consumption (In Watts) | 6 |
| Power Source | AC Adapter Included |
| Special Notes / Requirements | |
| Note | PC resolutions below 1280x1024 may support multiple refresh rates; 60Hz supported across all |
| What's in the Box | |
| Included in Package | HDMI to VGA Converter w/ Audio |
| Instruction Manual | |
| Universal Power Adapter (US/UK/EU/AUS) | |
| VGA to Component Breakout Cable | |
| Video | |
| Maximum video resolution This is the maximum resolution of video images. Resolution is a measure of the degree of detail visible. | 1920 x 1200 pixels |
| Supported video modes The video modes that can be displayed by the device. | 480i,480p,576i,576p,720p,1080i,1080p |
| Other features | |
| Product colour The colour e.g. red, blue, green, black, white. | Black |
| Dimensions (WxDxH) Dimensions of the product (Width x Depth x Height). | 76 x 76 x 92 mm |
| Ports & interfaces | |
| Host interface Interface that enables a host controller to communicate with a driver. | HDMI |
| Output interface The ports (sockets) where the device is connected via connectors and cables to external devices. | VGA |
| Power | |
| Power requirements | AC 115 - 230 V |
| Weight & dimensions | |
| Weight Weight of the product without packaging (net weight). If possible, the net weight is given including standard accessories and supplies. Please note that sometimes the manufacturer leaves out the weight of accessories and/or supplies. | 172 g |
| Packaging data | |
| Package width The distance from one side of the packaging to the other. | 210 mm |
| Package depth The distance from the front to the back of the packaging. | 118 mm |
| Package height The distance from the top to the bottom of the packaging. | 60 mm |
| Package weight Weight of the packaged product. | 536 g |
| SKU | 241927 |
| MPN | HDMI2VGA |
| Brand | Startech |
| Product Condition | Brand New/Unused |
| Stock Availability | Available for Shipping |
| Warranty Period | 2 Years Warranty |
| Warranty Contact | https://www.startech.com/ |
