Converts SPDIF Optical or Coaxial digital PCM audio input to analog stereo L/R RCA outputs - Supports uncompressed 2-channel LPCM digital audio signal output - Sampling rate at 32kHZ, 44.1kHZ, 48kHZ, and 96KHz24-bit - Low power, lightweight size, portable and easy to carry and operate - Powered by USB, USB Power Cable and Wall Changer - Converting from digital to analog only
| Inputs | |
| Digital audio optical in The socket in the device for the digital audio input. The signal is inputted via an optical cable with an TOSLINK connector. | 1 |
| Digital audio coaxial in The socket in the device for the digital audio input. The signal is broight into the device via a coaxial cable with an RCA connector. | 1 |
| USB 1.1 ports quantity Number of USB 1.1 ports (connecting interfaces) in the device. USB 1.1 was released in August 1998, fixing problems identified in 1.0, mostly related to using hubs. USB 1.1 was the earliest revision that was widely adopted. Usually coloured white. | 1 |
| Fiber ports quantity The number of sockets (ports) for fibers (cables). | 1 |
| DC-in jack The socket/plug where the DC electricity supply connects to the device. |
 |
| Outputs | |
| Audio (L/R) out The two sockets (ports) for transmitting left audio signal (white cable) and right audio signal (red cable). | 1 |
| Technical details | |
| Product colour The colour e.g. red, blue, green, black, white. | Black |
| Audio playback formats | LPCM, PCM |
| Power | |
| Operating voltage Defines the range of operating voltages available | 5 V |
| Power consumption | 500 mA |
| External power adapter |
|
| Input voltage The voltage (V) which is required to power the product. | 100 - 240 V |
| Input frequency The frequency (Hz) which is required to power the product. | 50 - 60 Hz |
| Weight & dimensions | |
| Width The measurement or extent of something from side to side. | 60 mm |
| Depth The distance from the front to the back of something. | 55 mm |
| Height The measurement of the product from head to foot or from base to top. | 20 mm |
| Weight Weight of the product without packaging (net weight). If possible, the net weight is given including standard accessories and supplies. Please note that sometimes the manufacturer leaves out the weight of accessories and/or supplies. | 78 g |
| Packaging data | |
| Quantity The number of products there are. | 1 |
| Cables included | DC to USB Type-A |
| Manual |
|
| SKU | 387912 |
| MPN | CM121 |
| Brand | Simplecom |
| Product Condition | Brand New/Unused |
| Stock Availability | Available for Shipping |
| Warranty Period | 1 Year Warranty |
| Warranty Contact | https://www.simplecom.com.au/ |
