The 1320W Intel ATX 12V power supply is engineered for high-performance gaming rigs, workstations, and professional computing environments. With 80 PLUS Gold certification, it ensures energy efficiency, reducing power waste while maintaining stable power delivery. Featuring a 135mm Fluid Dynamic Bearing (FDB) fan with Premium Hybrid Fan Control, it provides superior cooling while maintaining quiet operation. The PSU is fully modular, allowing for clean cable management and improved airflow within the system. Designed with a high-output +12V rail delivering up to 1296W, it ensures reliable power distribution for high-performance components. It supports multiple PCIe, SATA, and peripheral connectors, making it compatible with a wide range of hardware configurations. Built with high-quality components, including webbed cables for the motherboard, CPU, and PCIe, and flat black cables for other connections, it maximizes reliability and efficiency. Certified by global safety and environmental standards such as cTUVus, TUV, CB, and Energy Star, it meets RoHS, WEEE, and ErP Lot 6 compliance requirements. With an MTBF of 150,000 hours and backed by an industry-leading 12-year warranty, this PSU provides long-term reliability and performance for demanding system builds.
Key Features:
- 1320W Power Output for High-Performance Systems
- 80 PLUS Gold Certification for Energy Efficiency
- 135mm Fluid Dynamic Bearing (FDB) Fan with Premium Hybrid Fan Control
- Fully Modular Design for Clean Cable Management
- High +12V Rail Output (1296W) for Reliable Power Distribution
- Comprehensive Protection: OPP, OVP, UVP, OCP, OTP, SCP
- MTBF of 150,000 Hours for Exceptional Long-Term Reliability
- Full-Range AC Input (100-240V) with Active PFC
- Certified for cTUVus, TUV, CB, CCC, BSMI, EAC, Energy Star, RoHS, WEEE
- 12-Year Warranty for Ultimate Peace of Mind
| Power | |
| Total power The total power that is needed by the device, or the total power produced by the device. | 1300 W |
| AC input voltage The voltage of the AC electricity that is inputted into the product. | 100 - 240 V |
| AC input frequency | 50 - 60 Hz |
| Input current | 15 - 7.5 A |
| Combined power (+3.3V) | 125 W |
| Combined power (+12V) | 1296 W |
| Combined power (+5V) | 125 W |
| Combined power (-12V) | 3.6 W |
| Combined power (+5Vsb) | 15 W |
| Max output current (+3.3V) | 25 A |
| Max output current (+12V) | 108 A |
| Max output current (+5V) | 25 A |
| Max output current (-12V) | 0.3 A |
| Max output current (+5Vsb) | 3 A |
| Power protection features Features that protect the device against power problems e.g. overload. | Over current, Over power, Over voltage, Overheating, Short circuit, Under voltage |
| Ports & interfaces | |
| Motherboard power connector The way in which the motherboard is connected to the power supply. | 20+4 pin ATX |
| Motherboard power cable length | 61 cm |
| Number of SATA power connectors | 12 |
| SATA power cable length | 300,350,400,450 mm |
| Peripheral (Molex) power connectors (4-pin) White 4-pinned connector used to connect a peripheral to the power supply. | 5 |
| Peripheral (Molex) power cable length | 350,450 mm |
| PCI Express power connectors (6+2 pin) | 12 |
| CPU power connector (4+4 pin) |
 |
| CPU power cable length | 65 cm |
| ATX power connector (20+4 pin) |
|
| Floppy drive power connector | 1 |
| Floppy disk drive connector |
|
| Floppy disk drive cable length | 10.1 cm |
| Cabling type | Fully-Modular |
| Performance | |
| 80 PLUS certification | 80 PLUS Gold |
| Purpose What the product is used for. | PC |
| Power supply unit (PSU) form factor | ATX |
| Bearing technology | FDB |
| Mean time between failures (MTBF) Statistical model used to indicate product/mechanism reliability; expressed in hours and percentage of duty cycle. This number (in hours) does not indicate the mean time before failure for a single unit/mechanism. | 150000 h |
| Design | |
| Product colour The colour e.g. red, blue, green, black, white. | Black |
| Fan diameter The size of the fan, measured by the distance from one side of the fan to the other, via a straight line going through the middle of the fan. | 13.5 cm |
| Number of fans The quantity of fans (apparatus with rotating blades that creates a current of air for cooling or ventilation). | 1 fan(s) |
| Fan location | Top |
| On/off switch The button which is pressed to switch the device on or off. |
|
| Operational conditions | |
| Operating temperature (T-T) The minimum and maximum temperatures at which the product can be safely operated. | 0 - 50 °C |
| Certificates | |
| Compliance certificates | RoHS |
| Certification | WEEE, ErP Lot 6, REACH |
| Safety regulation & standards | |
| Safety List of regulatory safety standards for all countries in which this product has been certified. | cTUVus, TUV, CB, CCC, BSMI, EAC |
| Weight & dimensions | |
| Width The measurement or extent of something from side to side. | 150 mm |
| Depth The distance from the front to the back of something. | 170 mm |
| Height The measurement of the product from head to foot or from base to top. | 86 mm |
| Packaging data | |
| Package type The type of product package e.g. box. | Box |
| Technical details | |
| Sustainability certificates | ENERGY STAR |
| Logistics data | |
| Harmonized System (HS) code | 84733020 |
| SKU | 821744 |
| MPN | SSR-1300GD Active PFC F3 |
| Brand | Seasonic |
| Product Condition | Brand New/Unused |
| Stock Availability | Available for Shipping |
| Warranty Period | 12 Years Warranty |
| Warranty Contact | https://seasonic.com/ |
