The 80 PLUS Gold-certified Intel ATX 12V power supply is designed for efficiency, stability, and long-term reliability, making it an excellent choice for gaming PCs, workstations, and high-performance systems. With compact dimensions of 140mm x 150mm x 86mm, it offers a space-efficient design without compromising on power output. The PSU features a 120mm Fluid Dynamic Bearing (FDB) fan with S2FC Smart and Silent Fan Control, ensuring quiet operation while maintaining optimal cooling performance. The fan has a life expectancy of 50,000 hours at 40°C, making it a durable and reliable solution. Built with a semi-modular design, this PSU combines webbed attached cables with modular flat black cables for clean cable management and improved airflow. It supports full-range AC input and incorporates multiple safety features, including OPP, OVP, UVP, OCP, OTP, and SCP, safeguarding your system from power fluctuations. The power supply also features Active PFC with 99% typical power factor correction, ensuring stable power delivery. Designed with a DC-to-DC converter for improved efficiency and stability, this PSU meets global safety and environmental standards, including Energy Star, RoHS, WEEE, and ErP Lot 6 compliance. High-quality 105°C Japanese capacitors ensure enhanced durability and power reliability. With an MTBF of over 100,000 hours and a 7-year warranty, this PSU guarantees exceptional performance and peace of mind.
Key Features:
- 80 PLUS Gold Certification for High Energy Efficiency
- Intel ATX 12V Form Factor with a Compact Design
- 120mm Fluid Dynamic Bearing (FDB) Fan with S2FC Smart and Silent Fan Control
- Quieter Operation with a 50,000-Hour Fan Life Expectancy
- Semi-Modular Design with Webbed and Flat Black Cables
- Comprehensive Protection: OPP, OVP, UVP, OCP, OTP, SCP
- Active PFC with 99% Power Factor Correction for Enhanced Stability
- MTBF of 100,000 Hours for Long-Term Reliability
- 105°C Japanese Capacitors for Enhanced Durability
- Certified for CE, FCC, TUV, CB, CCC, and Energy Star Compliance
- 7-Year Warranty for Ultimate Peace of Mind
| Power | |
| Total power The total power that is needed by the device, or the total power produced by the device. | 500 W |
| AC input voltage The voltage of the AC electricity that is inputted into the product. | 100 - 240 V |
| AC input frequency | 50 - 60 Hz |
| Combined power (+3.3V) | 100 W |
| Combined power (+12V) | 492 W |
| Combined power (+5V) | 100 W |
| Combined power (-12V) | 3.6 W |
| Combined power (+5Vsb) | 15 W |
| Max output current (+3.3V) | 20 A |
| Max output current (+12V) | 41 A |
| Max output current (+5V) | 20 A |
| Max output current (-12V) | 0.3 A |
| Max output current (+5Vsb) | 3 A |
| Power protection features Features that protect the device against power problems e.g. overload. | Over current, Over power, Over voltage, Overheating, Short circuit, Under voltage |
| Ports & interfaces | |
| Motherboard power connector The way in which the motherboard is connected to the power supply. | 20+4 pin ATX |
| Motherboard power cable length | 61 cm |
| Number of SATA power connectors | 4 |
| SATA power cable length | 810 mm |
| Peripheral (Molex) power connectors (4-pin) White 4-pinned connector used to connect a peripheral to the power supply. | 3 |
| Peripheral (Molex) power cable length | 690 mm |
| PCI Express power connectors (6+2 pin) | 2 |
| PCI Express power cable length | 75 cm |
| CPU power connector (4+4 pin) |
 |
| CPU power cable length | 65 cm |
| ATX power connector (20+4 pin) |
|
| Cabling type | Semi-Modular |
| Performance | |
| 80 PLUS certification | 80 PLUS Gold |
| Supported motherboard form factors Design of the supported motherboards. | ATX |
| Purpose What the product is used for. | PC |
| Power supply unit (PSU) form factor | ATX |
| Bearing technology | Sleeve |
| Design | |
| Product colour The colour e.g. red, blue, green, black, white. | Black |
| Cooling type The method used to cool the device or to cool the air around the device. | Active |
| Fan diameter The size of the fan, measured by the distance from one side of the fan to the other, via a straight line going through the middle of the fan. | 12 cm |
| Number of fans The quantity of fans (apparatus with rotating blades that creates a current of air for cooling or ventilation). | 1 fan(s) |
| On/off switch The button which is pressed to switch the device on or off. |
|
| Operational conditions | |
| Operating temperature (T-T) The minimum and maximum temperatures at which the product can be safely operated. | 0 - 50 °C |
| Certificates | |
| Compliance certificates | RoHS |
| Certification | WEEE, ErP Lot 6, REACH |
| Weight & dimensions | |
| Width The measurement or extent of something from side to side. | 150 mm |
| Depth The distance from the front to the back of something. | 140 mm |
| Height The measurement of the product from head to foot or from base to top. | 86 mm |
| Packaging data | |
| Manual |
|
| Package type The type of product package e.g. box. | Box |
| Technical details | |
| Sustainability certificates | ENERGY STAR |
| Other features | |
| Warranty card |
|
| SKU | 821748 |
| MPN | SSR-500LM |
| Brand | Seasonic |
| Product Condition | Brand New/Unused |
| Stock Availability | Available for Shipping |
| Warranty Period | 7 Years Warranty |
| Warranty Contact | https://seasonic.com/ |
