Samsung VH55R-R 55" FHD IPS 24/7 700 Nits Video Wall Display
Item No:
710417
MPN:
LH55VHRRBGBXXY
$5,799.00
Payment options
Shipping Information
- Unavailable for shipping
- This product is not currently available for purchase
Store Availability
- Unavailable at Bankstown Store
- Unavailable at Castle Hill Store
- Unavailable at Northmead Store
Samsung VH55R R, Digital signage flat panel, 139.7 cm (55"), LED, 1920 x 1080 pixels, 24/7
Seamless video walls with razor thin bezels
With an exceptionally narrow bezel measuring just 0.44 mm and equipped with Samsung s advanced picture enhancement technology along with wide viewing angles, the VHR R delivers an impactful and seamless experience. Its modern, slim design allows the display to blend into any business environment.
Nearly invisible 0.44 mm bezel
An exceptionally thin 0.44mm even bezel " a 0.88 mm bezel to bezel depth " enables content to be delivered as one seamless image. Additionally, the display helps to eliminate any potential image distortion and provides a more immersive viewing experience.
View content from virtually any angle
The display s wide viewing angles mean content is easily visible even if viewers aren t standing directly in front of the display. Audiences can get clear and accurate information regardless of video wall layout or location.
Image enhancement technology
Samsung s powerful picture enhancement technology ensures all content is vibrant and clear. With Picture Enhancer mode, colour saturation and contrast are improved by adjusting the gamma curve. Using Black Equaliser mode, dark images are lightened, so details are easier to see.
Modern, slim design
VHR R displays feature an elevated design aesthetic with an ultra slim depth of less than 70 mm. This allows the display to save space and create a clean, modern look for retail or other public spaces.
Vibrant images 24/7
Experience brilliant image presentation with an impressive 700 nit brightness allowing businesses to deliver clear information 24/7. The display s non glare panels provide better visibility regardless of ambient light, ensuring critical information is always visible.
Convenient mobile calibration
Samsung s Colour Expert Pro Mobile solution provides a quick and easy video wall calibration through a mobile camera. With the solution s intuitive UI, even non expert users can adjust up to 5x5 video wall s white balance simultaneously without the need for additional equipment.
Comprehensive calibration
Samsung s multi step factory calibration process tunes video walls to uniform brightness and colour throughout multiple displays. In addition to rigorous factory calibration, users can also manage brightness and colour uniformity with Samsung s Colour Expert Pro, a powerful free software program.
Advanced UHD presentation
Samsung video walls provide an impressive UHD viewing experience with minimal effort. With daisy chain design utilising DisplayPort 1.2 and HDMI ports, the VHR R display can project UHD content across multiple screens up " to 5 x 5 " without requiring an external graphic card or UHD splitters.
Industry standard certified
The VHR R series is EMC class B compliant, ensuring a safe viewing environment by meeting strict standards of electromagnetic wave emission. The display packaging also passed a rigorous 4 step test in an ISTA certified laboratory designed minimizes possible damage during delivery.
Intuitive all in one operations
The UHD Signage Player Box combines information processing and content management tools into a single platform, for added operational simplicity. Weighing just 0.6 kg, even with embedded MagicINFO S Player 6 and SSSP 6, the compact design of the box makes it an ideal solution.
With an exceptionally narrow bezel measuring just 0.44 mm and equipped with Samsung s advanced picture enhancement technology along with wide viewing angles, the VHR R delivers an impactful and seamless experience. Its modern, slim design allows the display to blend into any business environment.
Nearly invisible 0.44 mm bezel
An exceptionally thin 0.44mm even bezel " a 0.88 mm bezel to bezel depth " enables content to be delivered as one seamless image. Additionally, the display helps to eliminate any potential image distortion and provides a more immersive viewing experience.
View content from virtually any angle
The display s wide viewing angles mean content is easily visible even if viewers aren t standing directly in front of the display. Audiences can get clear and accurate information regardless of video wall layout or location.
Image enhancement technology
Samsung s powerful picture enhancement technology ensures all content is vibrant and clear. With Picture Enhancer mode, colour saturation and contrast are improved by adjusting the gamma curve. Using Black Equaliser mode, dark images are lightened, so details are easier to see.
Modern, slim design
VHR R displays feature an elevated design aesthetic with an ultra slim depth of less than 70 mm. This allows the display to save space and create a clean, modern look for retail or other public spaces.
Vibrant images 24/7
Experience brilliant image presentation with an impressive 700 nit brightness allowing businesses to deliver clear information 24/7. The display s non glare panels provide better visibility regardless of ambient light, ensuring critical information is always visible.
Convenient mobile calibration
Samsung s Colour Expert Pro Mobile solution provides a quick and easy video wall calibration through a mobile camera. With the solution s intuitive UI, even non expert users can adjust up to 5x5 video wall s white balance simultaneously without the need for additional equipment.
Comprehensive calibration
Samsung s multi step factory calibration process tunes video walls to uniform brightness and colour throughout multiple displays. In addition to rigorous factory calibration, users can also manage brightness and colour uniformity with Samsung s Colour Expert Pro, a powerful free software program.
Advanced UHD presentation
Samsung video walls provide an impressive UHD viewing experience with minimal effort. With daisy chain design utilising DisplayPort 1.2 and HDMI ports, the VHR R display can project UHD content across multiple screens up " to 5 x 5 " without requiring an external graphic card or UHD splitters.
Industry standard certified
The VHR R series is EMC class B compliant, ensuring a safe viewing environment by meeting strict standards of electromagnetic wave emission. The display packaging also passed a rigorous 4 step test in an ISTA certified laboratory designed minimizes possible damage during delivery.
Intuitive all in one operations
The UHD Signage Player Box combines information processing and content management tools into a single platform, for added operational simplicity. Weighing just 0.6 kg, even with embedded MagicINFO S Player 6 and SSSP 6, the compact design of the box makes it an ideal solution.
| Display | |
| LED backlighting type Backlighting is the illumination of a screen e.g. LCD (liquid crystal display). There are several types of backlighting with LEDs, e.g. full array, edge lit. | Direct-LED |
| Display diagonal Size of the display for this product, measured diagonally, usually in inches. | 139.7 cm (55") |
| Display technology The technology used in the display e.g. plasma, LED. | LED |
| Display resolution The number of distinct pixels in each dimension that can be displayed. It is usually quoted as width × height, with the units in pixels: for example, "1024 × 768" means the width is 1024 pixels and the height is 768 pixels. The higher the number of pixels, the sharper the image. | 1920 x 1080 pixels |
| Display brightness Brightness is the amount of radiating light emitted from the screen. The brightness rating is measured in candellas per square meter, commonly known as 'nits'. | 700 cd/m² |
| HD type Type of supported High Definition (e.g. Full HD, 4K Ultra HD). | Full HD |
| Native aspect ratio The aspect ratio is the ratio of the width of an image to its height. The native aspect ratio is the one which the projector/display is particularly designed for. Images shown in native aspect ratio will utilize the entire resolution of the display and achieve maximum brightness. Images shown in other than native aspect ratio will always have less resolution and less brightness than images shown in native aspect ratio. | 16:9 |
| Response time The response time is the time difference between the moment that a source (for example a video card) sends a signal and that equipment (for example a monitor) receives or display the signal. (Used abbreviations: R/F = Rise and Fall.) | 8 ms |
| Contrast ratio (typical) The difference in light intensity between the brightest white and the darkest black. | 1100:1 |
| Contrast ratio (dynamic) A property of a display system, defined as the ratio of the luminance of the brightest color (white) to that of the darkest color (black) that the system is capable of producing. | 30000:1 |
| Viewing angle, horizontal Maximum horizontal angle at which a display can be viewed with acceptable visual performance. | 178° |
| Viewing angle, vertical Maximum vertical angle at which a display can be viewed with acceptable visual performance. | 178° |
| Pixel pitch This is the parameter of a picture tube, which specifies the shortest distance between two dots of the same colour. The principle is: the smaller the dot pitch, the better sharpness of image. | 0.63 x 0.63 mm |
| Display diagonal (metric) This is the size of the display screen, measured diagonally. | 138 cm |
| Horizontal scan range | 57.3 - 70 kHz |
| Vertical scan range | 47 - 63 Hz |
| Ports & interfaces | |
| HDMI ports quantity The number of sockets (ports) for HDMI connections. HDMI (High-Definition Multimedia Interface) is a compact audio/video interface for transferring uncompressed video data and compressed/uncompressed digital audio data from a HDMI-compliant device ("the source device") to a compatible computer monitor, video projector, digital television, or digital audio device. HDMI is a digital replacement for existing analog video standards. | 2 |
| HDMI input ports quantity | 2 |
| DVI port Digital Visual Interface (DVI) is a video display interface to connect a video source to a display device, such as a computer monitor. |
 |
| DisplayPorts quantity Number of DisplayPorts. A DisplayPort is a digital display interface developed by the Video Electronics Standards Association (VESA). The interface is primarily used to connect a video source to a display device such as a computer monitor, though it can also be used to carry audio, USB, and other forms of data. | 2 |
| USB port The device features a socket into which a USB cable can be plugged. |
|
| USB ports quantity | 1 |
| Ethernet LAN An Ethernet LAN (Local Area Network) interface is present, for a wired conection via a cable. |
|
| Ethernet LAN (RJ-45) ports Number of Ethernet LAN (RJ-45) ports (connecting interfaces) in the device. Ethernet LAN (RJ-45) ports allow a computer to connect to the ethernet. | 1 |
| RS-232 interface |
|
| Design | |
| Product design The creation of a plan or convention for the construction of an object or a system. | Digital signage flat panel |
| Placement supported Where the product can be placed e.g. indoor/outdoor, horizontal/vertical. | Indoor |
| Orientation | Horizontal |
| Product colour The colour e.g. red, blue, green, black, white. | Black |
| VESA mounting |
|
| Panel mounting interface The product can be used wih VESA mounting interfaces. | 600 x 400 mm |
| Performance | |
| Operating hours (hours/days) | 24/7 |
| Power | |
| Power consumption (typical) Amount of power consumed by this model, often expressed in watts (W). Typical values that manufacturers give are power consumption when off, standby/suspended mode, typical use, maximum usage. | 270 W |
| Power consumption (standby) The amount of electricity that is consumed when the product is on standby. | 0.5 W |
| AC input voltage The voltage of the AC electricity that is inputted into the product. | 100 - 240 V |
| AC input frequency | 50 - 60 Hz |
| Energy efficiency scale | A++ to E |
| Weight & dimensions | |
| Width The measurement or extent of something from side to side. | 1211 mm |
| Depth The distance from the front to the back of something. | 69.9 mm |
| Height The measurement of the product from head to foot or from base to top. | 681.7 mm |
| Weight Weight of the product without packaging (net weight). If possible, the net weight is given including standard accessories and supplies. Please note that sometimes the manufacturer leaves out the weight of accessories and/or supplies. | 16.8 kg |
| Packaging data | |
| Package width The distance from one side of the packaging to the other. | 1414 mm |
| Package depth The distance from the front to the back of the packaging. | 257 mm |
| Package height The distance from the top to the bottom of the packaging. | 844 mm |
| Package weight Weight of the packaged product. | 25.1 kg |
| Operational conditions | |
| Operating temperature (T-T) The minimum and maximum temperatures at which the product can be safely operated. | 0 - 40 °C |
| Operating relative humidity (H-H) | 10 - 90% |
| SKU | 710417 |
| MPN | LH55VHRRBGBXXY |
| Brand | Samsung |
| Product Condition | Brand New/Unused |
| Screen Size (Inches) | 55.00 Inch |
| Refresh Rate (Hz) | 60Hz |
| Screen Resolution | 1920x1080 (FHD/1080p) |
| Input | DisplayPort / DP, HDMI |
| Stock Availability | Available for Shipping |
| Product Use | General |
| Warranty Period | 3 Years Warranty |
| Warranty Contact | https://www.samsung.com/ |
