Samsung OH46B-S 46" FHD 24/7 Outdoor Display
Item No:
750308
MPN:
LH46OHBESGBXXY
$5,799.00
Payment options
Shipping Information
- Unavailable for shipping
- This product is not currently available for purchase
Store Availability
- Unavailable at Bankstown Store
- Unavailable at Castle Hill Store
- Unavailable at Northmead Store
Samsung LH46OHBESGB, Digital signage flat panel, 116.8 cm (46"), LED, 1920 x 1080 pixels, 24/7
Deliver bright and brilliant messages, built for the outdoors
When it comes to providing concise communication for customers, Samsung
When it comes to providing concise communication for customers, Samsung
| Display | |
| Panel type | VA |
| Display diagonal Size of the display for this product, measured diagonally, usually in inches. | 116.8 cm (46") |
| Display technology The technology used in the display e.g. plasma, LED. | LED |
| Display resolution The number of distinct pixels in each dimension that can be displayed. It is usually quoted as width × height, with the units in pixels: for example, "1024 × 768" means the width is 1024 pixels and the height is 768 pixels. The higher the number of pixels, the sharper the image. | 1920 x 1080 pixels |
| Display brightness Brightness is the amount of radiating light emitted from the screen. The brightness rating is measured in candellas per square meter, commonly known as 'nits'. | 3500 cd/m² |
| HD type Type of supported High Definition (e.g. Full HD, 4K Ultra HD). | Full HD |
| Touchscreen A screen of a laptop, smartphone, etc., that responds to touch so you can control the interface using your fingers. |
 |
| Response time The response time is the time difference between the moment that a source (for example a video card) sends a signal and that equipment (for example a monitor) receives or display the signal. (Used abbreviations: R/F = Rise and Fall.) | 6 ms |
| Contrast ratio (typical) The difference in light intensity between the brightest white and the darkest black. | 6000:1 |
| Viewing angle, horizontal Maximum horizontal angle at which a display can be viewed with acceptable visual performance. | 178° |
| Viewing angle, vertical Maximum vertical angle at which a display can be viewed with acceptable visual performance. | 178° |
| Pixel pitch This is the parameter of a picture tube, which specifies the shortest distance between two dots of the same colour. The principle is: the smaller the dot pitch, the better sharpness of image. | 0.53 x 0.53 mm |
| Horizontal scan range | 15 - 135 kHz |
| Vertical scan range | 24 - 75 Hz |
| Ports & interfaces | |
| HDMI ports quantity The number of sockets (ports) for HDMI connections. HDMI (High-Definition Multimedia Interface) is a compact audio/video interface for transferring uncompressed video data and compressed/uncompressed digital audio data from a HDMI-compliant device ("the source device") to a compatible computer monitor, video projector, digital television, or digital audio device. HDMI is a digital replacement for existing analog video standards. | 2 |
| HDMI version | 2.0 |
| HDMI input ports quantity | 2 |
| DVI port Digital Visual Interface (DVI) is a video display interface to connect a video source to a display device, such as a computer monitor. |
|
| USB port The device features a socket into which a USB cable can be plugged. |
 |
| USB ports quantity | 1 |
| Ethernet LAN An Ethernet LAN (Local Area Network) interface is present, for a wired conection via a cable. |
|
| Ethernet LAN (RJ-45) ports Number of Ethernet LAN (RJ-45) ports (connecting interfaces) in the device. Ethernet LAN (RJ-45) ports allow a computer to connect to the ethernet. | 1 |
| Wi-Fi Popular technology that allows an electronic device to exchange data or connect to the internet wirelessly using radio waves. |
|
| RS-232 interface |
|
| Remote (IR) input | 1 |
| PC Audio out |
|
| Audio | |
| Built-in speaker(s) The device contains speaker(s) to produce sound. |
|
| Design | |
| Product design The creation of a plan or convention for the construction of an object or a system. | Digital signage flat panel |
| Placement supported Where the product can be placed e.g. indoor/outdoor, horizontal/vertical. | Outdoor |
| Product colour The colour e.g. red, blue, green, black, white. | Black |
| Screen shape | Flat |
| VESA mounting |
|
| Panel mounting interface The product can be used wih VESA mounting interfaces. | 995 x 500 mm |
| Bezel width (bottom) | 2.49 cm |
| Bezel width (side) | 2.49 cm |
| Bezel width (top) | 2.49 cm |
| Mounting type Type of mounting e.g. wall mounting. | Wall |
| Performance | |
| Purpose What the product is used for. | Universal |
| Operating hours (hours/days) | 24/7 |
| HDCP High-bandwidth Digital Content Protection (HDCP) is a form of digital copy protection to prevent copying of digital audio and video content as it travels across connections. |
|
| International Protection (IP) code The IP code classifies and rates the degree of protection provided against the intrusion (including body parts such as hands and fingers), dust, accidental contact, and water by mechanical casings and electrical enclosures. It is published by the International Electrotechnical Commission (IEC). The digits (characteristic numerals) indicate conformity with the conditions summarized in the tables below. Where there is no protection rating with regard to one of the criteria, the digit is replaced with the letter X. an electrical socket rated IP22 is protected against insertion of fingers and will not be damaged or become unsafe during a specified test in which it is exposed to vertically or nearly vertically dripping water. Another example is the Sony Xperia Z Ultra, one of the first cellular phones to be IP-rated; it is rated at IP58 and marketed as "dust resistant" and can be "immersed in 1.5 meter of freshwater for up to 30 minutes". | IP56 |
| HDCP version | 2.2 |
| Power | |
| Power consumption (typical) Amount of power consumed by this model, often expressed in watts (W). Typical values that manufacturers give are power consumption when off, standby/suspended mode, typical use, maximum usage. | 430 W |
| Power consumption (sleep) | 0.5 W |
| AC input voltage The voltage of the AC electricity that is inputted into the product. | 100-240 V |
| AC input frequency | 50/60 Hz |
| Computer system | |
| Computer system |
|
| Built-in processor Whether or not a processor is built into the device. |
|
| Operating system installed Type of operating system on a device e.g. IOS on Apple devices, Android for mobile devices. | Tizen 6.5 |
| Weight & dimensions | |
| Display width | 1069 mm |
| Display depth | 85 mm |
| Display height | 623.6 mm |
| Display weight | 36 kg |
| Packaging data | |
| Package width The distance from one side of the packaging to the other. | 713 mm |
| Package depth The distance from the front to the back of the packaging. | 200 mm |
| Package height The distance from the top to the bottom of the packaging. | 1156 mm |
| Package weight Weight of the packaged product. | 40.5 kg |
| Operational conditions | |
| Operating temperature (T-T) The minimum and maximum temperatures at which the product can be safely operated. | -30 - 50 °C |
| Operating relative humidity (H-H) | 10 - 80% |
| Certificates | |
| Certification | EMC Class A Safety 60950-1, 62368-1 |
| Features | |
| Wall mountable The product can be mounted on (attached to ) a wall. |
|
| SKU | 750308 |
| MPN | LH46OHBESGBXXY |
| Brand | Samsung |
| Product Condition | Brand New/Unused |
| Screen Size (Inches) | 46.00 Inch |
| Refresh Rate (Hz) | 60Hz |
| Screen Resolution | 1920x1080 (FHD/1080p) |
| Input | HDMI |
| Stock Availability | Available for Shipping |
| Product Use | General |
| Warranty Period | 3 Years Warranty |
| Warranty Contact | https://www.samsung.com/ |
