Shipping Information
- Unavailable for shipping
- This product is not currently available for purchase
Store Availability
- Unavailable at Bankstown Store
- Unavailable at Castle Hill Store
- Unavailable at Northmead Store
Specifications Download Product Manual
-
Screen Size
23.6"
-
Resolution
1920x1080
-
Dynamic Contrast Ratio
Mega ∞ DCR
-
Product Dimensions Without Stand
22.40" x 13.46" x 2.12"
-
Cabinet Style
Black High Glossy
Full Specifications
Display
-
Model Number
LS24D300HL/ZA
-
Screen Size
23.6"
-
Resolution
1920x1080
-
Aspect Ratio
16:9
-
Brightness
200cd/m2
-
Static Contrast Ratio
700:1
-
Dynamic Contrast Ratio
Mega ∞ DCR
-
Viewing Angle (Horizontal/Vertical)
90°/65°
-
Response Time
5ms (GTG)
-
Color Support
16.7M
Power
-
Type
External Adaptor
-
Power Supply Type
AC100-240V (50/60Hz)
-
Power Consumption (Typical)
20W
-
Power Consumption (Stand-by)
0.3W
-
Max Stand By Power (DPMS)
0.3W
Features
-
Special
Embedded function: Game Mode, Magic Upscale, Eco Saving, Samsung MagicBright3, Off Timer, Image Size
-
VGA
Yes
-
HDMI
1
-
Stand
Round
-
Cabinet Design
LED TN
-
Mac Compatible
Yes
-
Windows Compatible
Yes
Dimensions (W x H x D)
-
Product Dimensions With Stand
22.40" x 16.42" x 7.75"
-
Product Dimensions Without Stand
22.40" x 13.46" x 2.12"
-
Shipping Dimensions
25.00" x 16.06" x 4.37"
Accessories
-
Other
Quick Setup Guide
-
VGA Cable
Yes
Green Management
-
ENERGY STAR® Certified
Yes
-
EPEAT Rating
Gold
Inputs
-
VGA
1 ea
-
HDMI
1 ea
Design
-
Cabinet Style
Black High Glossy
| Display | |
| Display diagonal Size of the display for this product, measured diagonally, usually in inches. | 59.9 cm (23.6") |
| Display brightness (typical) Display brightness, measured by its Luminance, presented as a figure in candela per square meter (cd/m2). Typical brightness ratings for monitors range from 250 to 350 cd/m2 with a target value of between 80 to 120 cd/m2 being suitable for most displays in a normal viewing environment. | 200 cd/m² |
| Display resolution The number of distinct pixels in each dimension that can be displayed. It is usually quoted as width × height, with the units in pixels: for example, "1024 × 768" means the width is 1024 pixels and the height is 768 pixels. The higher the number of pixels, the sharper the image. | 1920 x 1080 pixels |
| Native aspect ratio The aspect ratio is the ratio of the width of an image to its height. The native aspect ratio is the one which the projector/display is particularly designed for. Images shown in native aspect ratio will utilize the entire resolution of the display and achieve maximum brightness. Images shown in other than native aspect ratio will always have less resolution and less brightness than images shown in native aspect ratio. | 16:9 |
| Response time The response time is the time difference between the moment that a source (for example a video card) sends a signal and that equipment (for example a monitor) receives or display the signal. (Used abbreviations: R/F = Rise and Fall.) | 5 ms |
| HD type Type of supported High Definition (e.g. Full HD, 4K Ultra HD). | Full HD |
| Display technology The technology used in the display e.g. plasma, LED. | LED |
| Screen shape | Flat |
| Supported graphics resolutions The graphic resolutions that can be displayed by the device. The graphic resolution describes the width and height dimensions of a display, such as a computer monitor, measured in pixels. | 1920 x 1080 (HD 1080) |
| Contrast ratio (typical) The difference in light intensity between the brightest white and the darkest black. | 700:1 |
| Dynamic contrast ratio marketing name | Mega Contrast |
| Viewing angle, horizontal Maximum horizontal angle at which a display can be viewed with acceptable visual performance. | 90° |
| Viewing angle, vertical Maximum vertical angle at which a display can be viewed with acceptable visual performance. | 65° |
| Display number of colours | 16.78 million colors |
| Panel type | TN |
| Design | |
| Product colour The colour e.g. red, blue, green, black, white. | Black |
| Ports & interfaces | |
| Built-in USB hub Whether or not the device features a USB hub to connect more than one other device via USB. |
 |
| VGA (D-Sub) ports quantity Number of VGA (D-Sub) ports (connecting interfaces) in the device. The VGA (D-Sub) connector is a 15 pin connector between a computer and a monitor. It was first introduced in 1987 by IBM. | 1 |
| DVI port Digital Visual Interface (DVI) is a video display interface to connect a video source to a display device, such as a computer monitor. |
|
| HDMI ports quantity The number of sockets (ports) for HDMI connections. HDMI (High-Definition Multimedia Interface) is a compact audio/video interface for transferring uncompressed video data and compressed/uncompressed digital audio data from a HDMI-compliant device ("the source device") to a compatible computer monitor, video projector, digital television, or digital audio device. HDMI is a digital replacement for existing analog video standards. | 1 |
| Wi-Fi Popular technology that allows an electronic device to exchange data or connect to the internet wirelessly using radio waves. |
|
| Ergonomics | |
| Cable lock slot Holes on the edge of devices through which a cable lock can be passed, so the device can be locked to a desk etc. |
|
| Plug and Play Indicates whether this product supports is "plug and play". Plug and play is hardware or software that, after being installed ("plugged in"), can immediately be used ("played with"), as opposed to hardware or software which requires configuration. |
 |
| LED indicators | Power |
| Thin Client | |
| Thin client installed The product includes a thin client, which is a computer or a computer program which depends heavily on some other computer (its server) to fulfill its computational roles. This is different from the traditional fat client, which is a computer designed to take on these roles by itself. The specific roles assumed by the server may vary, from providing data persistence (for example, for diskless nodes) to actual information processing on the client's behalf. |
|
| Power | |
| Energy efficiency class The energy efficiency of the appliance is rated in terms of a set of energy efficiency classes from A+++ to G on the label, A+++ being the most energy efficient, G the least efficient. | B |
| Annual energy consumption The amount of energy used by the product per year. | 39 kWh |
| Power consumption (typical) Amount of power consumed by this model, often expressed in watts (W). Typical values that manufacturers give are power consumption when off, standby/suspended mode, typical use, maximum usage. | 27 W |
| Power consumption (standby) The amount of electricity that is consumed when the product is on standby. | 0.3 W |
| AC input voltage The voltage of the AC electricity that is inputted into the product. | 100 - 240 V |
| AC input frequency | 50 - 60 Hz |
| Weight & dimensions | |
| Width The measurement or extent of something from side to side. | 569 mm |
| Depth The distance from the front to the back of something. | 54 mm |
| Height The measurement of the product from head to foot or from base to top. | 342 mm |
| Weight Weight of the product without packaging (net weight). If possible, the net weight is given including standard accessories and supplies. Please note that sometimes the manufacturer leaves out the weight of accessories and/or supplies. | 3.19 kg |
| Width (with stand) | 569 mm |
| Depth (with stand) | 197 mm |
| Height (with stand) | 417 mm |
| Weight (with stand) | 3.54 kg |
| Packaging data | |
| Cables included | VGA |
| Package width The distance from one side of the packaging to the other. | 635 mm |
| Package depth The distance from the front to the back of the packaging. | 111 mm |
| Package height The distance from the top to the bottom of the packaging. | 408 mm |
| Package weight Weight of the packaged product. | 4.79 kg |
| Other features | |
| Display The description of display that can includes display type, resolution, size etc. | LED |
| On/off switch The button which is pressed to switch the device on or off. |
|
| Quick start guide Instructions, either online, as a computer program or in paper form, to allow you to set up and start using the product quickly. |
|
| Game mode |
|
| On/Off timer There is a timer for when to turn the device on or off. |
|
| Ethernet LAN An Ethernet LAN (Local Area Network) interface is present, for a wired conection via a cable. |
|
| Bluetooth Bluetooth is a low-power radio technology developed to replace the cables and wires currently used to link or connect electronic devices such as personal computers, printers, and a wide variety of handheld devices including mobile phones. Because it uses radio-wave connectivity, a Bluetooth-enabled device has a constant, established connection to whatever browser it uses. This saves the user the trouble of logging on to check for emails or news updates, for example. |
|
| SKU | 215831 |
| MPN | LS24D300HLR/XY |
| Brand | Samsung |
| Product Condition | Brand New/Unused |
