QNAP QXP-W6-AX200, Wireless, PCI Express, WLAN / Bluetooth, Wi-Fi 6 (802.11ax), 2400 Mbit/s
The QXP-W6-AX200 is a PCIe Gen 2x1 Wi-Fi 6 wireless adapter with an Intel Wi-Fi 6 AX200 module that supports the IEEE 802.11ax standard (backwards compatible with 802.11a/b/g/n/ac), MIMO 2Tx2R, MU-MIMO TX/RX and Bluetooth 5.0. The QXP-W6-AX200 can be installed in a QNAP NAS, or Windows/Linux PC to provide fast Wi-Fi 6 connection speeds The QXP-W6-AX200 can also be used with Wi-Fi 6 router to deploy Wi-Fi 6 network environment. A full-height bracket is pre-installed on the QXP-W6-AX200 and two low-profile brackets are also included.
2.8x Faster Connectivity
The QXP-W6-AX200 dual band Wi-Fi 6 PCIe card supports 802.11ax 160MHz dual band connectivity, 1024-QAM and up to 2400Mbps connection speed which is 2.8 times faster than Wi-Fi 5(802.11ac).
Easy Access with a Wireless NAS
With a QXP-W6-AX200 installed in your NAS, you can free yourself from Ethernet cables and access all your stored files and multimedia over a high-speed wireless connection. A full-height bracket is pre-installed on the QXP-W6-AX200 and two low-profile brackets are also included.
Easily Set Up a NAS Wireless Network Connection
After installing the QXP-W6-AX200 in your NAS, use Network & Virtual Switch or Qfinder Pro to set up the Wi-Fi connection, guest network environment or captive portal.
Upgrade Your Windows or Linux PC with High-speed Wireless Networking!
The QXP-W6-AX200 is not just for NAS, it can be installed in a Windows or Linux PC to provide Wi-Fi 6 connectivity for enabling faster downloading speeds and low-latency connectivity.
Dual Band Antenna with Better Wi-Fi Signals
The QXP-W6-AX200 features a new antenna design that provides better Wi-Fi signals and transmission speeds.
Supports dual band 802.11ax 2.4GHz & 5GHz and provides better signal strength compared to traditional antenna designs.
The smart antenna function provides superior WI-FI signal transmission.
The multiple angle tilt and magnetic base allows you to get the best signal strength direction and location.
Add Bluetooth 5.0 to Your Windows PC
When installed in a Windows PC, the QXP-W6-AX200 provides Bluetooth 5.0 connectivity. Please note that this requires connecting the QXP-W6-AX200 to an F_USB connector on your motherboard using the included USB cable.
2.8x Faster Connectivity
The QXP-W6-AX200 dual band Wi-Fi 6 PCIe card supports 802.11ax 160MHz dual band connectivity, 1024-QAM and up to 2400Mbps connection speed which is 2.8 times faster than Wi-Fi 5(802.11ac).
Easy Access with a Wireless NAS
With a QXP-W6-AX200 installed in your NAS, you can free yourself from Ethernet cables and access all your stored files and multimedia over a high-speed wireless connection. A full-height bracket is pre-installed on the QXP-W6-AX200 and two low-profile brackets are also included.
Easily Set Up a NAS Wireless Network Connection
After installing the QXP-W6-AX200 in your NAS, use Network & Virtual Switch or Qfinder Pro to set up the Wi-Fi connection, guest network environment or captive portal.
Upgrade Your Windows or Linux PC with High-speed Wireless Networking!
The QXP-W6-AX200 is not just for NAS, it can be installed in a Windows or Linux PC to provide Wi-Fi 6 connectivity for enabling faster downloading speeds and low-latency connectivity.
Dual Band Antenna with Better Wi-Fi Signals
The QXP-W6-AX200 features a new antenna design that provides better Wi-Fi signals and transmission speeds.
Supports dual band 802.11ax 2.4GHz & 5GHz and provides better signal strength compared to traditional antenna designs.
The smart antenna function provides superior WI-FI signal transmission.
The multiple angle tilt and magnetic base allows you to get the best signal strength direction and location.
Add Bluetooth 5.0 to Your Windows PC
When installed in a Windows PC, the QXP-W6-AX200 provides Bluetooth 5.0 connectivity. Please note that this requires connecting the QXP-W6-AX200 to an F_USB connector on your motherboard using the included USB cable.
| Ports & interfaces | |
| Connectivity technology The technology that enables connectivity of the device, e.g. wired or wireless. | Wireless |
| Host interface Interface that enables a host controller to communicate with a driver. | PCI Express |
| Interface Interface ports to connect pieces of equipment. USB (Universal Serial Bus) has become the most popular wired interface to connect peripherals. USB 2.0 supports speeds up to 480 Mbit/s (USB 1: 12 Mbit/s). The interface FireWire is also known as the IEEE 1394 standard. Enhanced IDE (EIDE)is sometimes referred to as Fast ATA, Fast IDE or ATA-2. | WLAN / Bluetooth |
| Network | |
| Maximum data transfer rate The maximum speed with which data can be transmitted from one device to another. | 2400 Mbit/s |
| Wi-Fi Popular technology that allows an electronic device to exchange data or connect to the internet wirelessly using radio waves. |
 |
| Wi-Fi band The frequency bands the product features. | Dual-band (2.4 GHz / 5 GHz) |
| Top Wi-Fi standard Connection of this device is done via Wi-Fi in a high standard. | Wi-Fi 6 (802.11ax) |
| Wi-Fi standards The type of wireless local area network (LAN). It can be ad-hoc, where units in a network communicate peer-to-peer, or Infrastructure, where units communicate with each other via an access point A LAN interconnects computers in a small area e.g. home, school or office. | 802.11a,802.11b,802.11g,Wi-Fi 4 (802.11n),Wi-Fi 5 (802.11ac),Wi-Fi 6 (802.11ax) |
| Modulation Modulation is the process of varying one or more properties of a periodic waveform, called the carrier signal (High Frequency Signal), with a modulating signal which typically contains information to be transmitted. The aim of digital modulation is to transfer a digital bit stream over an analog bandpass channel, for example over the public switched telephone network (where a bandpass filter limits the frequency range to between 300 and 3400 Hz), or over a limited radio frequency band. The aim of analog modulation is to transfer an analog baseband (or lowpass) signal, for example an audio signal or TV signal, over an analog bandpass channel at a different frequency, for example over a limited radio frequency band or a cable TV network channel. | 1024-QAM |
| Security algorithms Security algorithms are used to provide authentication, cipher key generation, integrity and radio link privacy to users on mobile networks. The security algorithms supported are the ones that can be used with this product. | WEP,WPA-PSK,WPA2-PSK |
| Bluetooth Bluetooth is a low-power radio technology developed to replace the cables and wires currently used to link or connect electronic devices such as personal computers, printers, and a wide variety of handheld devices including mobile phones. Because it uses radio-wave connectivity, a Bluetooth-enabled device has a constant, established connection to whatever browser it uses. This saves the user the trouble of logging on to check for emails or news updates, for example. |
|
| Bluetooth version The type of bluetooth technology in the product e.g. Bluetooth Smart (v4.0). | 5.0 |
| Design | |
| Internal The product is built in. |
 |
| Antenna |
|
| Antenna design | External |
| System requirements | |
| Windows operating systems supported Windows vesions wich can be used with the device. | Windows 10 |
| Linux operating systems supported 8 RT. Linux (9.4, 9.5), Red Hat Enterprise Linux 5.0 (supported with a pre-built package); SUSE Linux (10.3, 11.0, 11, 11.1, 11.2), Fedora (9, 9.0, 10, 10.0, 11.0, 11, 12, 12.0), Ubuntu (8.04, 8.04.1, 8.04.2, 8.10, 9.04, 9.10, 10.04), Debian (5.0, 5.0.1, 5.0.2, 5.0.3) |
|
| Operational conditions | |
| Operating temperature (T-T) The minimum and maximum temperatures at which the product can be safely operated. | 0 - 40 °C |
| Packaging content | |
| Mounting brackets included |
|
| Resource CD |
|
| Quick installation guide |
|
| SKU | 570066 |
| MPN | QXP-W6-AX200 |
| Brand | QNAP |
| Product Condition | Brand New/Unused |
| Stock Availability | Available for Shipping |
| Product Use | General |
| Warranty Period | 1 Year Warranty |
| Warranty Contact | https://www.qnap.com/ |
