2-bay desktop NAS, Intel Celeron J6412 4C 2.0GHz, onboard 8GB RAM, 2 x HDMI 1.4b, 2x M.2 2280 PCIe slots, 2x 2.5GbE, 2x USB 3.2 Gen2 Type A
The TS-253E features 2.5GbE connectivity, 8GB RAM, and M.2 slots for NVMe SSD caching to deliver high performance for applications such as surveillance systems, virtual machines, file servers or backup servers. Dual HDMI outputs also provide direct multimedia playback and robust surveillance monitoring. QNAP will provide long-term availability and support for the TS-253E, providing a great choice for businesses requiring matching NAS models deployed in multiple locations.
Dual 2.5GbE ports
2.5 times faster network speed with existing CAT5e cables; supports port trunking to deliver up to 5Gbps.
Dual M.2 2280 PCIe slots
Attain greater NAS performance by installing M.2 2280 NVMe PCIe SSDs (sold separately) or Edge TPU.
8GB RAM onboard
System performance and multitasking is optimized with 8GB RAM.
Long-term model
The TS-253E will be available and supported by QNAP for an extended period, up to 2029.
Dual HDMI output
The dual-screen extension can be used for surveillance or 4K high-resolution video playback.
Expand storage capacity
Supports USB expansion enclosures (see the compatibility list).
< xml version="1.0" encoding="utf-8" >
| Name | Value |
|---|---|
| Bays | 2 x 3.5-inch SATA 6Gb/s |
| Buttons | Power, Reset, USB Auto Copy |
| Capacity | Disckless |
| CPU Architecture | 64-bit x86 |
| Dimensions (HxWxD) | 168.5 - 102 - 225 mm |
| Encryption Engine | Yes (AES-NI) |
| Fan | 1 x 70mm, 12VDC |
| Flash Memory | 4GB (Dual boot OS protection) |
| Floating Point Unit | Yes |
| Form Factor | Tower |
| Graphic Processors | Intel UHD Graphics |
| Hardware-accelerated Transcoding | Yes |
| HDMI Output | 2 x HDMI 1.4b ( up to 3840 x 2160 @ 30Hz ) |
| Hot-swappable | Yes |
| Jumbo Frame | Yes |
| Kensington Security Slot | Yes |
| LAN Port | 2 x 2.5 Gigabit Ethernet Port (2.5G/1G/100M) |
| LED Indicators | Power/Status, LAN, USB, HDD1-2 |
| M.2 Slot | 2 x M.2 2280 PCIe Gen 3 x2 |
| Operating Temperature | 0 - 40 DegC (32 DegF - 104 DegF) |
| Power Consumption: HDD Sleep Mode | 10.56 W |
| Power Consumption: Operating Mode, Typical | 18.09 W |
| Power Supply Unit | 60W/65W adapter, 100-240V |
| Processor/Memory | Intel Celeron J6412 4-core/4-thread processor, burst up to 2.6 GHz / 8 GB on board (non-expandable) |
| Raid | JBOD, Single, RAID 0, 1 |
| Relative Humidity | 5-95% RH non-condensing, wet bulb: 27 DegC (80.6 DegF) |
| Series | QNAP Home |
| SSD Cache Acceleration Support | Yes |
| Storage Temperature | -20 - 70 DegC (-4 DegF - 158 DegF) |
| System Warning | Buzzer |
| USB Port | 2 x USB 2.0 port, 2 x USB 3.2 Gen 2 (10Gbps) Port |
| Wake on LAN (WOL) | Yes |
| Warranty | 2 Years |
| Weight (Gross) | 2.32 kg |
| Weight (Net) | 1.28 kg |
| Storage | |
| Supported storage drive interfaces | M.2, Serial ATA III |
| Storage drive sizes supported The sizes of storage drives that can be used with the product. | 2.5,M.2 |
| Number of M.2 (M & B) slots | 2 |
| RAID support The device uses RAID, which is a storage technology that combines multiple disk drive components into a logical unit for the purposes of data redundancy and performance improvement. Data is distributed across the drives in one of several ways, referred to as RAID levels, depending on the specific level of redundancy and performance required. |
 |
| Storage drives installed Storage drives are built into the system. |
|
| Number of storage drives supported How many storage drives can be fit into the product at once. | 4 |
| Installed storage drive type Type of storage drives built into the device e.g. HDD (hard disk drive), SSD (solid-state drive). |
|
| Supported storage drive types The type of storage drives the device is compatible with. | HDD & SSD |
| Processor | |
| Processor manufacturer The manufacturer that produced the processor. | Intel |
| Processor family A family of processors is a group of processors produced by one company over a short period of time e.g. Intel Pentium processors. | Intel® Celeron® |
| Processor model The model number for the processor in a computer. | J6412 |
| Processor frequency The speed that the microprocessor executes each instruction or each vibration of the clock. The CPU requires a fixed number of clock ticks, or cycles, to execute each instruction. The faster the clocks rate, the faster the CPU, or the faster it can execute instructions. Clock Speeds are usually determined in MHz, 1 MHz representing 1 million cycles per second, or in GHz, 1 GHz representing 1 thousand million cycles per second. The higher the CPU speed, the better a computer will perform. | 2.6 GHz |
| Processor cores The number of central processing units ('cores') in a processor. Some processors have 1 core, others have 2 (e.g. Intel Core Duo) or more (e.g. the Intel Xeon E7-2850 has 10 cores). | 4 |
| Processor threads | 4 |
| Memory | |
| Internal memory A computer's memory which is directly accessible to the CPU. | 8 GB |
| Network | |
| Ethernet LAN An Ethernet LAN (Local Area Network) interface is present, for a wired conection via a cable. |
 |
| Jumbo frames support |
|
| Wake-on-LAN ready |
|
| Ports & interfaces | |
| USB port The device features a socket into which a USB cable can be plugged. |
|
| USB 2.0 ports quantity Number of USB 2.0 ports (connecting interfaces) in the device. USB 2.0 was released in April 2000 (now called "Hi-Speed"), adding higher maximum signaling rate of 480 Mbit/s (effective throughput up to 35 MB/s or 280 Mbit/s), USB 2.0 ports are usually black. | 2 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 2 |
| HDMI ports quantity The number of sockets (ports) for HDMI connections. HDMI (High-Definition Multimedia Interface) is a compact audio/video interface for transferring uncompressed video data and compressed/uncompressed digital audio data from a HDMI-compliant device ("the source device") to a compatible computer monitor, video projector, digital television, or digital audio device. HDMI is a digital replacement for existing analog video standards. | 2 |
| HDMI version | 1.4b |
| Ethernet LAN (RJ-45) ports Number of Ethernet LAN (RJ-45) ports (connecting interfaces) in the device. Ethernet LAN (RJ-45) ports allow a computer to connect to the ethernet. | 2 |
| Design | |
| Chassis type The type of rigid framework onto which is the hosuing for device components. | Tower |
| Cooling type The method used to cool the device or to cool the air around the device. | Active |
| Product colour The colour e.g. red, blue, green, black, white. | Black |
| Number of fans The quantity of fans (apparatus with rotating blades that creates a current of air for cooling or ventilation). | 1 fan(s) |
| LED indicators | LAN, Power, Status |
| Performance | |
| Type Characteristics of the device. | NAS |
| Buzzer |
|
| Reset button |
|
| On/off switch The button which is pressed to switch the device on or off. |
|
| Power | |
| Power supply unit (PSU) capacity | 90 W |
| Power consumption (max) The maximum amount of power used by the device. | 18.09 W |
| Power consumption (sleep) | 10.56 W |
| AC input voltage The voltage of the AC electricity that is inputted into the product. | 100 - 240 V |
| Packaging content | |
| External power adapter |
|
| Operational conditions | |
| Operating temperature (T-T) The minimum and maximum temperatures at which the product can be safely operated. | 0 - 40 °C |
| Operating relative humidity (H-H) | 5 - 95% |
| Storage temperature (T-T) The minimum and maximum temperatures at which the product can be safely stored. | -20 - 70 °C |
| Storage relative humidity (H-H) | 5 - 95% |
| SKU | 679504 |
| MPN | TS-253E-8G |
| Brand | QNAP |
| Product Condition | Brand New/Unused |
| NAS Form Factor | Freestanding |
| NAS Bays | 2.00 |
| Stock Availability | Available for Shipping |
| Product Use | General |
| Warranty Period | 2 Years Warranty |
| Warranty Contact | https://www.qnap.com/ |
