PNY GeForce RTX 4060 Ti 8GB VERTO Dual Fan DLSS 3 -OC Version
PNY GeForce RTX 4060 Ti 8GB VERTO Dual Fan DLSS 3
Overview
NVIDIA GeForce RTX 40 Series GPUs are beyond fast for gamers and creators. They re powered by the ultra-efficient NVIDIA Ada Lovelace architecture which delivers a quantum leap in both performance and AI-powered graphics. Experience lifelike virtual worlds with ray tracing and ultra-high FPS gaming with the lowest latency. Discover revolutionary new ways to create and unprecedented workflow acceleration.
KEY FEATURES
Powered by NVIDIA DLSS 3, ultra-efficient Ada Lovelace arch, and full ray tracing
Dedicated Ray Tracing Cores
Dedicated Tensor Cores
NVIDIA DLSS 3
Game Ready and NVIDIA Studio Drivers
NVIDIA GeForce Experience
NVIDIA Broadcast
NVIDIA G-SYNC
NVIDIA GPU Boost
PCI Express Gen 4
Microsoft DirectX 12 Ultimate
Vulkan RT APIs, Vulkan 1.3, OpenGL 4.6
HDCP 2.3
DisplayPort 1.4a, up to 4K at 240Hz or 8K at 60Hz with DSC, HDR
As specified in HDMI 2.1a: up to 4K 240Hz or 8K 60Hz with DSC, Gaming VRR, HDR
MINIMUM SYSTEM REQUIREMENTS
PCI Express-compliant motherboard with one dual width x16 graphics slot (x8 active)
One 8-pin supplementary power connectors
550 W or greater system power supply2
Microsoft Windows 11 64-bit, Windows 10 (November 2018 or later) 64-bit, Linux 64-bit
Internet connection
Product Specifications
PNY Part Number
VCG4060T8DFXPB1
UPC Code
751492777238
CUDA Cores
3072
Clock Speed
2310 MHz
Boost Speed
2535 MHz
Memory Speed (Gbps)
18
Memory Size
8GB GDDR6
Memory Interface
128-bit
Memory Bandwidth (GB/sec)
288
TDP
160 W
NVLink
Not Supported
Outputs
DisplayPort 1.4a (x3), HDMI 2.1
Multi-Screen
4
Resolution
7680 x 4320 @120Hz (Digital)3
Power Input
One 8-pin
Bus Type
PCI-Express 4.0 x16 (x8 active)
Card Dimensions
9.65 x 4.43 x 1.57 ; Dual Slot
Overview
NVIDIA GeForce RTX 40 Series GPUs are beyond fast for gamers and creators. They re powered by the ultra-efficient NVIDIA Ada Lovelace architecture which delivers a quantum leap in both performance and AI-powered graphics. Experience lifelike virtual worlds with ray tracing and ultra-high FPS gaming with the lowest latency. Discover revolutionary new ways to create and unprecedented workflow acceleration.
KEY FEATURES
Powered by NVIDIA DLSS 3, ultra-efficient Ada Lovelace arch, and full ray tracing
Dedicated Ray Tracing Cores
Dedicated Tensor Cores
NVIDIA DLSS 3
Game Ready and NVIDIA Studio Drivers
NVIDIA GeForce Experience
NVIDIA Broadcast
NVIDIA G-SYNC
NVIDIA GPU Boost
PCI Express Gen 4
Microsoft DirectX 12 Ultimate
Vulkan RT APIs, Vulkan 1.3, OpenGL 4.6
HDCP 2.3
DisplayPort 1.4a, up to 4K at 240Hz or 8K at 60Hz with DSC, HDR
As specified in HDMI 2.1a: up to 4K 240Hz or 8K 60Hz with DSC, Gaming VRR, HDR
MINIMUM SYSTEM REQUIREMENTS
PCI Express-compliant motherboard with one dual width x16 graphics slot (x8 active)
One 8-pin supplementary power connectors
550 W or greater system power supply2
Microsoft Windows 11 64-bit, Windows 10 (November 2018 or later) 64-bit, Linux 64-bit
Internet connection
Product Specifications
PNY Part Number
VCG4060T8DFXPB1
UPC Code
751492777238
CUDA Cores
3072
Clock Speed
2310 MHz
Boost Speed
2535 MHz
Memory Speed (Gbps)
18
Memory Size
8GB GDDR6
Memory Interface
128-bit
Memory Bandwidth (GB/sec)
288
TDP
160 W
NVLink
Not Supported
Outputs
DisplayPort 1.4a (x3), HDMI 2.1
Multi-Screen
4
Resolution
7680 x 4320 @120Hz (Digital)3
Power Input
One 8-pin
Bus Type
PCI-Express 4.0 x16 (x8 active)
Card Dimensions
9.65 x 4.43 x 1.57 ; Dual Slot
| Processor | |
| CUDA CUDA (aka Compute Unified Device Architecture) is a parallel computing platform and programming model created by NVIDIA and implemented by the graphics processing units (GPUs) that they produce. CUDA gives program developers direct access to the virtual instruction set and memory of the parallel computational elements in CUDA GPUs. |
 |
| CUDA cores | 4352 |
| Graphics processor family The category to which the graphics processor (GPU) belongs e.g. Southern Islands family of Radeon processors (made by AMD), GeForce 600 (made by NVIDIA). | NVIDIA |
| Graphics processor Also known as a graphics processing unit (GPU), this is a specialized electronic circuit designed to rapidly manipulate and alter memory to accelerate the creation of images in a frame buffer intended for output to a display. GPUs are used in embedded systems, mobile phones, personal computers, workstations, and game consoles. Modern GPUs are very efficient at manipulating computer graphics. | GeForce RTX 4060 |
| Processor frequency The clock rate is the fundamental rate in cycles per second (measured in hertz) at which a computer performs its most basic operations such as adding two numbers. There are more factors, like internal memory size, that influence a computer's actual response time. | 2310 MHz |
| Processor boost clock speed | 2550 MHz |
| Maximum resolution The maximum number of pixels that can be displayed in the image. It is usually quoted as width × height,: for example, "1024 × 768" means the width is 1024 pixels and the height is 768 pixels. | 7680 x 4320 pixels |
| Parallel processing technology support Parallel processing technology is the simultaneous use of more than one CPU or processor core to execute a program or multiple computational threads. Ideally, parallel processing makes programs run faster because there are more engines (CPUs or Cores) running it. In practice, it is often difficult to divide a program in such a way that separate CPUs or cores can execute different portions without interfering with each other. Most computers have just one CPU, but some models have several, and multi-core processor chips are becoming the norm. There are even computers with thousands of CPUs. | Not supported |
| Maximum displays per videocard | 4 |
| Memory | |
| Discrete graphics card memory | 8 GB |
| Graphics card memory type The type of memory used by the video card. Often a combination of dedicated memory (Video RAM or VRAM) and dynamic system memory is used. UMA stands for Unified Memory Architecture, and is a computer memory architecture that allows the graphics processing unit to share system memory. Other abreviations: RAM = Random Access Memory, SDRAM = synchronous dynamic RAM, DDR = double-data-rate. | GDDR6 |
| Memory bus Hardware and software that connects the main memory to the memory controller in computer systems. Originally, general-purpose buses like VMEbus and the S-100 bus were used, but to reduce latency, modern memory buses are designed to connect directly to DRAM chips, and thus are designed by chip standards bodies such as JEDEC. | 128 bit |
| Data transfer rate Rate at which data can be transferred. Usually expressed in units per second. May vary with network configurations. | 18 Gbit/s |
| Memory bandwidth (max) | 288 GB/s |
| Ports & interfaces | |
| Interface type | PCI Express x16 4.0 |
| HDMI ports quantity The number of sockets (ports) for HDMI connections. HDMI (High-Definition Multimedia Interface) is a compact audio/video interface for transferring uncompressed video data and compressed/uncompressed digital audio data from a HDMI-compliant device ("the source device") to a compatible computer monitor, video projector, digital television, or digital audio device. HDMI is a digital replacement for existing analog video standards. | 1 |
| HDMI version | 2.1 |
| DisplayPorts quantity Number of DisplayPorts. A DisplayPort is a digital display interface developed by the Video Electronics Standards Association (VESA). The interface is primarily used to connect a video source to a display device such as a computer monitor, though it can also be used to carry audio, USB, and other forms of data. | 3 |
| DisplayPort version | 1.4 |
| Performance | |
| TV tuner integrated Device has an in-built TV tuner. |
 |
| DirectX version DirectX is a collection of APIs (application programming interfaces) for easily handling tasks related to game programming on the Microsoft Windows operating system. | 12 Ultimate |
| OpenGL version OpenGL (Open Graphics Library) is a specification defining a cross-language cross-platform API for writing applications that produce 3D computer graphics (and 2D computer graphics as well). The interface consists of over 250 different function calls which can be used to draw complex three-dimensional scenes from simple primitives. | 4.6 |
| NVIDIA G-SYNC |
|
| Design | |
| Cooling type The method used to cool the device or to cool the air around the device. | Active |
| Number of fans The quantity of fans (apparatus with rotating blades that creates a current of air for cooling or ventilation). | 2 fan(s) |
| Product colour The colour e.g. red, blue, green, black, white. | Black |
| Power | |
| Supplementary power connectors | 1x 8-pin |
| Power consumption (max) The maximum amount of power used by the device. | 160 W |
| Weight & dimensions | |
| Depth The distance from the front to the back of something. | 245 mm |
| Height The measurement of the product from head to foot or from base to top. | 112.6 mm |
| Width The measurement or extent of something from side to side. | 40 mm |
| Packaging data | |
| Package width The distance from one side of the packaging to the other. | 325 mm |
| Package depth The distance from the front to the back of the packaging. | 172 mm |
| Package height The distance from the top to the bottom of the packaging. | 90 mm |
| Package type The type of product package e.g. box. | Box |
| SKU | 757010 |
| MPN | VCG4060T8DFXPB1-O |
| Brand | PNY |
| Product Condition | Brand New/Unused |
| GPU Series | GeForce RTX 4060 Ti |
| Graphics RAM Size | 8 GB |
| Stock Availability | Available for Shipping |
| Product Use | General |
| Warranty Period | 3 Years Warranty |
| Warranty Contact | https://www.pny.com/ |
