AI Performance: 275 TOPS
GPU: 2048 core NVIDIA Ampere architecture GPU with 64 Tensor Cores
GPU Max Frequency: 1.3 GHz
CPU: 12 core Arm Cortex A78AE v8.2 64 bit CPU 3MB L2 6MB L3
CPU Max Frequency: 2.2 GHz
DL Accelerator: 2x NVDLA v2
DLA Max Frequency: 1.6GHz
Vision Accelerator: 1x PVA v2
Memory: 64GB 256 bit LPDDR5 204.8GB/s
Storage: 64GB eMMC 5.1
Video Encode: 2x 4K60 (H.265) 4x 4K30 (H.265) 8x 1080p60 (H.265) 16x 1080p30 (H.265)
Video Decode: 1x 8K30 (H.265) 3x 4K60 (H.265) 7x 4K30 (H.265) 11x 1080p60 (H.265) 22x 1080p30 (H.265)
CSI Camera: 16 lane MIPI CSI 2 connector
PCIe: x16 PCIe slot supporting x8 PCIe Gen4 M.2 Key M slot with x4 PCIe Gen4 M.2 Key E slot with x1 PCIe Gen4
USB: USB Type C connector: 2x USB 3.2 Gen2 USB Type A connector: 2x USB 3.2 Gen2, 2x USB 3.2 Gen1 USB Micro B connector: USB 2.0
Networking: RJ45 connector with up to 10 GbE
Display: 1x DisplayPort 1.4a ( MST) connector
Other I/O: 40 pin header (UART, SPI, I2S, I2C, CAN, PWM, DMIC, GPIO) 12 pin automation header 10 pin audio panel header 10 pin JTAG header 4 pin fan header 2 pin RTC batter backup connector
Power: 15W 60W
Mechanical: 110mm x 110mm x 71.65mm (Height includes feet, carrier board, module, and thermal solution)
| Processor | |
| Processor manufacturer The manufacturer that produced the processor. | ARM |
| Processor model The model number for the processor in a computer. | Arm Cortex-A78AE |
| Processor cores The number of central processing units ('cores') in a processor. Some processors have 1 core, others have 2 (e.g. Intel Core Duo) or more (e.g. the Intel Xeon E7-2850 has 10 cores). | 64 |
| 64-bit computing The use of processors that have datapath widths, integer size, and memory addresses widths of 64 bits (eight octets). In 2003 64-bit CPUs were introduced to the (previously 32-bit) mainstream personal computer arena in the form of the x86-64 and 64-bit PowerPC processor architectures and in 2012 even into the ARM architecture targeting smartphones and tablet computers, first sold on September 20, 2013 in the iPhone 5S powered by the ARMv8-A Apple A7 SoC. |
 |
| Processor boost frequency The turbo boost is an automatic, managed accelleration of the processor when one of the cores is overloaded. | 2.2 GHz |
| Memory | |
| Maximum internal memory The maximum internal memory which is available in the product. | 64 GB |
| Internal memory type The type of internal memory such as RAM, GDDR5. | LPDDR5-SDRAM |
| Memory bandwidth (max) | 204.8 GB/s |
| Memory bus Hardware and software that connects the main memory to the memory controller in computer systems. Originally, general-purpose buses like VMEbus and the S-100 bus were used, but to reduce latency, modern memory buses are designed to connect directly to DRAM chips, and thus are designed by chip standards bodies such as JEDEC. | 256 bit |
| Internal storage capacity The amount e.g of data which can be stored inside the device. | 64 GB |
| Ports & interfaces | |
| Ethernet LAN An Ethernet LAN (Local Area Network) interface is present, for a wired conection via a cable. |
|
| Ethernet interface type | 10 Gigabit Ethernet, Gigabit Ethernet |
| USB version Universal Serial Bus (USB) is an industry standard developed in the mid-1990s that defines the interface used for connection, communication and power supply between computers and electronic devices. Every new version - for example 1.1, 2.0, 3.0 - is much faster than the previous one. | 2.0/3.2 Gen 2 (3.1 Gen 2) |
| USB ports quantity | 7 |
| USB 2.0 ports quantity Number of USB 2.0 ports (connecting interfaces) in the device. USB 2.0 was released in April 2000 (now called "Hi-Speed"), adding higher maximum signaling rate of 480 Mbit/s (effective throughput up to 35 MB/s or 280 Mbit/s), USB 2.0 ports are usually black. | 4 |
| UART |
|
| I2C interface |
|
| SPI interface |
|
| I2S interface |
|
| Expansion slots | |
| PCI version | 4.0 |
| Weight & dimensions | |
| Board dimensions | 100 x 87 mm |
| SKU | 730712 |
| MPN | 945-13730-0057-000 |
| Brand | nVidia |
| Product Condition | Brand New/Unused |
| Stock Availability | Available for Shipping |
| Product Use | General |
| Warranty Period | 1 Year Warranty |
| Warranty Contact | https://www.nvidia.com/ |
