| Performance | |
| Suitable location Locations in which the product can be used. | Processor |
| Type Characteristics of the device. | Cooler |
| Fan diameter The size of the fan, measured by the distance from one side of the fan to the other, via a straight line going through the middle of the fan. | 14 cm |
| Supported processor sockets The sockets (plugs) for processors that are supported (can be used) by the device. | Socket TR4, Socket SP3 |
| Compatible processor series A processor which is compatible with this device, belongs to a 'series' which is part of 'family' e.g Celeron D, Celeron G, Celeron M, or, in some cases, is the same as 'family'. | AMD Ryzen |
| Rotational speed (min) | 300 RPM |
| Rotational speed (max) | 1500 RPM |
| Rotational speed with LNA (max) | 1200 RPM |
| Noise level (high speed) How loud the device is when used at high speed. | 19.2 dB |
| Noise level with LNA (max) | 24.6 dB |
| Airflow | 140.2 m³/h |
| Airflow with LNA (max) | 115.5 m³/h |
| Bearing type | Self-Stabilising Oil-pressure Bearing (SSO) |
| Design | |
| Product colour The colour e.g. red, blue, green, black, white. | Aluminium, Beige |
| Material The material from which a thing is or can be made e.g. wood, plastic. | Copper |
| Number of fans The quantity of fans (apparatus with rotating blades that creates a current of air for cooling or ventilation). | 1 fan(s) |
| Number of fan blades | 7 |
| Fins material | Aluminium |
| Fan connector | 4-pin |
| Power | |
| Power supply The way in which the product is powered e.g. rechargeable battery, mains electricity connected via a plug and cable. | 1.56 W |
| Voltage | 12 V |
| Weight & dimensions | |
| Width The measurement or extent of something from side to side. | 150 mm |
| Depth The distance from the front to the back of something. | 78 mm |
| Height The measurement of the product from head to foot or from base to top. | 165 mm |
| Weight Weight of the product without packaging (net weight). If possible, the net weight is given including standard accessories and supplies. Please note that sometimes the manufacturer leaves out the weight of accessories and/or supplies. | 1.03 kg |
| Fan dimensions (W x D x H) | 140 x 150 x 25 mm |
| Heatsink weight | 865 g |
| Package width The distance from one side of the packaging to the other. | 226 mm |
| Package depth The distance from the front to the back of the packaging. | 113 mm |
| Package height The distance from the top to the bottom of the packaging. | 217 mm |
| Package weight Weight of the packaged product. | 1.5 kg |
| Packaging content | |
| Low-noise adaptor (LNA) |
 |
| Other features | |
| Heatsink dimensions (W x D x H) | 150 x 52 x 165 mm |
| Mean time to failure (MTTF) | 150000 h |
| Logistics data | |
| Harmonized System (HS) code | 84733080 |
| Master (outer) case gross weight | 13 kg |
| Products per master (outer) case | 8 pc(s) |
| SKU | 278187 |
| MPN | NH-U14S-TR4-SP3 |
| Brand | Noctua |
| Product Condition | Brand New/Unused |
| Stock Availability | Available for Shipping, In Stock at Warehouse |
