Manufacturer: Noctua. Noctuas DX line CPU coolers have become a default choice in premium grade quiet cooling solutions for Intel Xeon processors. The NH-U14S DX-3647 features a larger, custom-designed contact surface and supports both square and narrow type LGA3647 platforms. Based on the proven, 140mm size NH-U14S heatsink and equipped with Noctuas award-winning, PWM controlled NF-A15 140mm fan, it combines maximum performance and superb acoustics. Topped off with the professional SecuFirm2 mounting system and pre-applied NT-H1 thermal compound, the NH-U14S DX-3647 forms a complete premium quality package for quietly cooling LGA3647 based Xeon workstations and servers.
Would you like to know more? Check out the full product information page.
Would you like to know more? Check out the full product information page.
| Performance | |
| Suitable location Locations in which the product can be used. | Processor |
| Type Characteristics of the device. | Cooler |
| Fan diameter The size of the fan, measured by the distance from one side of the fan to the other, via a straight line going through the middle of the fan. | 12 cm |
| Supported processor sockets The sockets (plugs) for processors that are supported (can be used) by the device. | LGA 3647 (Socket P) |
| Compatible processor series A processor which is compatible with this device, belongs to a 'series' which is part of 'family' e.g Celeron D, Celeron G, Celeron M, or, in some cases, is the same as 'family'. | Intel® Xeon® |
| Rotational speed (min) | 450 RPM |
| Rotational speed (max) | 2000 RPM |
| Noise level (high speed) How loud the device is when used at high speed. | 22.6 dB |
| Airflow | 102.1 m³/h |
| Maximum air pressure | 2.34 mmH2O |
| Pulse-width modulation (PWM) support |
 |
| Bearing type | Self-Stabilising Oil-pressure Bearing (SSO) |
| Design | |
| Product colour The colour e.g. red, blue, green, black, white. | Beige, Nickel, Red |
| Material The material from which a thing is or can be made e.g. wood, plastic. | Cooper |
| Number of fans The quantity of fans (apparatus with rotating blades that creates a current of air for cooling or ventilation). | 2 fan(s) |
| Number of fan blades | 9 |
| Fins material | Aluminium |
| Fan connector | 4-pin |
| Power | |
| Power supply The way in which the product is powered e.g. rechargeable battery, mains electricity connected via a plug and cable. | 1.68 W |
| Rated voltage | 12 V |
| Weight & dimensions | |
| Width The measurement or extent of something from side to side. | 158 mm |
| Depth The distance from the front to the back of something. | 125 mm |
| Height The measurement of the product from head to foot or from base to top. | 97 mm |
| Weight Weight of the product without packaging (net weight). If possible, the net weight is given including standard accessories and supplies. Please note that sometimes the manufacturer leaves out the weight of accessories and/or supplies. | 1.02 kg |
| Fan dimensions (W x D x H) | 120 x 120 x 25 mm |
| Heatsink weight | 626 g |
| Package width The distance from one side of the packaging to the other. | 227 mm |
| Package depth The distance from the front to the back of the packaging. | 198 mm |
| Package height The distance from the top to the bottom of the packaging. | 160 mm |
| Package weight Weight of the packaged product. | 1.71 kg |
| Packaging content | |
| Cables included | Fan |
| Other features | |
| Heatsink dimensions (W x D x H) | 158 x 125 x 45 mm |
| Mean time to failure (MTTF) | 150000 h |
| Logistics data | |
| Harmonized System (HS) code | 84733080 |
| Master (outer) case width | 417 mm |
| Master (outer) case length | 481 mm |
| Master (outer) case height | 342 mm |
| Master (outer) case gross weight | 15.2 kg |
| Products per master (outer) case | 8 pc(s) |
| SKU | 324513 |
| MPN | NH-U12S-DX-3647 |
| Brand | Noctua |
| Product Condition | Brand New/Unused |
| Fan Size (mm) | N/A |
| Cooling Technology | Air |
| Stock Availability | Available for Shipping, In Stock at Warehouse |
| Warranty Period | 6 Years Warranty |
| Warranty Contact | https://noctua.at/ |
