Mikrotik RB912UAG-5HPnD, Motherboard, Router, Wi-Fi 4 (802.11n), IEEE 802.11a, IEEE 802.11n, IEEE 802.3af, AR9342, 600 MHz
The RB912UAG-5HPnD is a very versatile device. It is a small wireless router with an integrated high power wireless card and an additional miniPCIe slot for 802.11 wireless, or 3G card. The Gigabit port helps to utilize the full potential of 802.11n wireless speeds.
It has built in 16kV ESD protection on both the Ethernet and the MMCX ports
- RB912UAG-5HPnD-US (USA) is factory locked for 5170-5250MHz and 5725-5835MHz frequencies. This lock can not be removed.
- RB912UAG-5HPnD (International) supports 5150MHz-5875MHz range (Specific frequency range can be limited by country regulations).
It has built in 16kV ESD protection on both the Ethernet and the MMCX ports
- RB912UAG-5HPnD-US (USA) is factory locked for 5170-5250MHz and 5725-5835MHz frequencies. This lock can not be removed.
- RB912UAG-5HPnD (International) supports 5150MHz-5875MHz range (Specific frequency range can be limited by country regulations).
| Features | |
| Product type The sub-category of the product. | Motherboard |
| Device compatibility The other devices which this device can be used with. | Router |
| Voltage monitoring |
 |
| Temperature monitoring |
|
| Reset button |
|
| License level | 4 |
| Performance | |
| Top Wi-Fi standard Connection of this device is done via Wi-Fi in a high standard. | Wi-Fi 4 (802.11n) |
| Networking standards The way in which the network is working, e.g. IEEE 802.11a, IEEE 802.11b, IEEE 802.11g. | IEEE 802.11a, IEEE 802.11n, IEEE 802.3af |
| Processor model The model number for the processor in a computer. | AR9342 |
| Processor frequency The clock rate is the fundamental rate in cycles per second (measured in hertz) at which a computer performs its most basic operations such as adding two numbers. There are more factors, like internal memory size, that influence a computer's actual response time. | 600 MHz |
| Processor cores The number of central processing units ('cores') in a processor. Some processors have 1 core, others have 2 (e.g. Intel Core Duo) or more (e.g. the Intel Xeon E7-2850 has 10 cores). | 1 |
| Storage capacity The maximum storage capability of the product. | 64 MB |
| Storage media Used for the storage of data e.g. HDD (hard disk drive), SSD (solid-state drive). | Flash |
| Internal memory The amount of memory, usually measured in bytes (e.g. MB, GB), which is installed in the system's hardware. | 64 MB |
| Number of SIM cards | 1 |
| SIM card type | MiniSIM |
| Ports & interfaces | |
| Basic switching RJ-45 Ethernet ports quantity The number of basic switching RJ-45 Ethernet ports (sockets). | 1 |
| Basic switching RJ-45 Ethernet ports type The type/category of basic switching RJ-45 Ethernet ports (sockets). | Gigabit Ethernet (10/100/1000) |
| Power over Ethernet (PoE) ports quantity | 1 |
| USB port type | USB Type-A |
| USB ports quantity | 1 |
| SIM card slot Whether the device features a SIM card slot. |
|
| Power | |
| Power connector | DC-in-jack |
| Power consumption (max) The maximum amount of power used by the device. | 14 W |
| DC input voltage | 8 - 30 V |
| Power over Ethernet (PoE) voltage range | 8 - 30 V |
| Weight & dimensions | |
| Width The measurement or extent of something from side to side. | 105 mm |
| Depth The distance from the front to the back of something. | 105 mm |
| Weight Weight of the product without packaging (net weight). If possible, the net weight is given including standard accessories and supplies. Please note that sometimes the manufacturer leaves out the weight of accessories and/or supplies. | 67 g |
| SKU | 818059 |
| MPN | RB912UAG-5HPnD |
| Brand | MikroTik |
| Product Condition | Brand New/Unused |
| Product Use | General |
| Warranty Period | 1 Year Warranty |
| Warranty Contact | https://mikrotik.com/ |
