Matrox QuadHead2Go Q185 Multi-Monitor Controller Appliance / Q2G-DP4K2, Black, Metal, Regulatory/environmental compliance: EMC Class A: FCC, CE, KC, RCM, VCCI, 1000 Mbit/s, 10/100Base-T(X), 1 GB
Matrox® QuadHead2Go™ Q185 Multi-Monitor-Controller
Product Info:
Capable of driving four displays from one signal, the Matrox® QuadHead2Go™ Q155 multi-monitor controller appliance provides complete video wall scalability and flexibility. This system-independent appliance is designed to power any video wall configuration of any possible dimension, from any HDMI® video source-reliably delivering flawless image quality across expansive, artistic video wall displays, suited for digital signage in a wide range of industries. QuadHead2Go
Product Info:
Capable of driving four displays from one signal, the Matrox® QuadHead2Go™ Q155 multi-monitor controller appliance provides complete video wall scalability and flexibility. This system-independent appliance is designed to power any video wall configuration of any possible dimension, from any HDMI® video source-reliably delivering flawless image quality across expansive, artistic video wall displays, suited for digital signage in a wide range of industries. QuadHead2Go
| Design | |
| Product colour The colour e.g. red, blue, green, black, white. | Black |
| Housing material What the casing of the product is made of. | Metal |
| Built-in fan |
 |
| Rack mounting The type of mounting that can position devices in a shelving system (rack). |
 |
| Certification | Regulatory/environmental compliance: EMC Class A: FCC, CE, KC, RCM, VCCI |
| Features | |
| Ethernet LAN An Ethernet LAN (Local Area Network) interface is present, for a wired conection via a cable. |
|
| Ethernet LAN data rates The different speed levels of the Ethernet LAN connection. | 1000 Mbit/s |
| Cabling technology Type of cable technology performance. | 10/100Base-T(X) |
| Built-in processor Whether or not a processor is built into the device. |
|
| Internal storage capacity The amount e.g of data which can be stored inside the device. | 1 GB |
| Bundled software Software distributed with another product such as a piece of computer hardware or other electronic device, or a group of software packages which are sold together. A software suite is an example of bundled software, as is software which is pre-installed on a new computer. | Matrox PowerWall: https://www.matrox.com/graphics/en/products/video-wall/powerwall/ |
| HDCP High-bandwidth Digital Content Protection (HDCP) is a form of digital copy protection to prevent copying of digital audio and video content as it travels across connections. |
|
| Ports & interfaces | |
| HDMI output ports quantity | 4 |
| DisplayPorts quantity Number of DisplayPorts. A DisplayPort is a digital display interface developed by the Video Electronics Standards Association (VESA). The interface is primarily used to connect a video source to a display device such as a computer monitor, though it can also be used to carry audio, USB, and other forms of data. | 1 |
| DisplayPort version | 1.2 |
| RJ-45 ports quantity | 1 |
| Power | |
| Power consumption (max) The maximum amount of power used by the device. | 15 W |
| Power supply location Where the power supply is positioned. | External |
| Operational conditions | |
| Operating temperature (T-T) The minimum and maximum temperatures at which the product can be safely operated. | 0 - 45 °C |
| Storage temperature (T-T) The minimum and maximum temperatures at which the product can be safely stored. | -40 - 70 °C |
| Operating relative humidity (H-H) | 20 - 80% |
| Storage relative humidity (H-H) | 5 - 95% |
| Weight & dimensions | |
| Width The measurement or extent of something from side to side. | 14 mm |
| Depth The distance from the front to the back of something. | 18.1 mm |
| Height The measurement of the product from head to foot or from base to top. | 3.18 mm |
| Weight Weight of the product without packaging (net weight). If possible, the net weight is given including standard accessories and supplies. Please note that sometimes the manufacturer leaves out the weight of accessories and/or supplies. | 494 g |
| SKU | 812321 |
| MPN | Q2G-DP4K2 |
| Brand | Matrox |
| Product Condition | Brand New/Unused |
| Product Use | General |
| Warranty Period | 3 Years Warranty |
| Warranty Contact | https://www.matrox.com/ |
| Stock Availability | Available for Shipping |
