Gigabit Ethernet (10/100/1000), Front USB 2.0 Specification Hi-Speed Certified port (Type A), USB 2.0 Specification Hi-Speed Certified (Type B), 802.11b/g/n/ac + BLE
Size (mm - H x W x D)
513.7 x 479 x 450 mm
Weight
21.2 kg
Packaged Size (mm - H x W x D)
659 x 584 x 559 mm
Packaged Weight, kg
24.9 kg
Copying
Copy Speed
Up to:
Black: 44 cpm2 (A4)
Copy Speed Duplex
Up to:
Black: 23 spm2 (A4)
Time to First Copy
as fast as:
Black: 6.5 seconds
Reduce / Enlarge Range
25 - 400 %
Faxing
Modem Speed
ITU T.30, V.34 Half-Duplex, 33.6 Kbps
Fax Transmission Speed
< 3 seconds per page
Printing
Print Speed
Up to:
Black: 44 ppm2 (A4)
Print Speed Duplex
Up to:
Black: 23 spm2 (A4)
Time to First Page
As fast as:
Black: 6 seconds
Print Resolution
Black: 1200 x 1200 dpi, 1200 IQ (1200 x 600 dpi)
Duplex
2-sided:
Integrated Duplex
Printable Area
metric: 4.2 mm of the top, bottom, right and left edges (within)
Print technology
Indicates the method used to print by this product.
Laser
Printing
Producing a paper copy of information stored on a computer.
Mono printing
Duplex printing
Feature of computer printers and multifunction printers (MFPs) that allows the printing of a sheet of paper on both sides (automatically or manually)
Maximum resolution
Maximum printing resolution.
1200 x 1200 DPI
Print speed (black, normal quality, A4/US Letter)
The print speed of a printer for black & white A4 pages, normal quality. The exact speed varies depending on the system configuration, software program, and document complexity.
44 ppm
Duplex print speed (black, normal quality, A4/US Letter)
23 ppm
Time to first page (black, normal)
6 s
Copying
Duplex copying
Copying
Description of copying function (colour or monochrome).
Mono copying
Copy speed (black, normal quality, A4)
44 cpm
Time to first copy (black, normal)
6.5 s
Copier resize
25 - 400%
Scanning
Duplex scanning
Feature of computer scanners and multifunction printers (MFPs) that allows the automatic scanning of a sheet of paper on both sides.
Scanning
To convert a document or picture into digital form for storage or processing on a computer, by scanning it using a scanner.
Colour scanning
Optical scanning resolution
How many pixels a scanner can see. Most commonly, this is measured in dots per inch (dpi).For example, a typical flatbed scanner will use a scanning head with 300 sensors per inch, so it can sample 300 dots per inch (dpi) in one direction. To scan in the other direction, it will move the scanning head along the page, stopping 300 times per inch, so it can scan 300 dpi in the other direction as well. This scanner would have an optical resolution of 300 x 300 dpi. Some manufacturers stop the scanning head more frequently as it moves down the page, so their machines have resolutions of 300 x 600 dpi or 300x1200 dpi.
600 x 600 DPI
Scanner type
Indicates the type of scanner this product is.
ADF scanner
Scan to
E-mail, FTP, Network folder, USB
Image formats supported
The type of image files that the device can use/display e.g. gif, JPEG (jpg).
JPEG, JPG, TIFF
Document formats supported
The type of document formats that can be read/produced with this device e.g. .docx, .pdf.
PDF
Fax
Duplex faxing
Faxing
To send an exact copy of a document made by electronic scanning and transmitted as data by telecommunications links.
Mono faxing
Fax transmission speed
3 sec/page
Modem speed
The speed at which data is transferred by a modem.
33.6 Kbit/s
Features
Maximum duty cycle
The maximum number of prints/copies made by a printer/copier in a fixed period.
120000 pages per month
Duplex functions
The product has the ability to print, scan etc. on both sides of a sheet of paper.
Copy, Fax, Print, Scan
Number of print cartridges
The amount of print cartridges. A print cartridge is a container holding a quantity of ink which is inserted into a inkjet printer mechanism.
1
Printing colours
The colours that can be produced by the printer.
Black
Page description languages
PCL 5, PCL 6, PCLm, PDF 1.7, PPDS, PostScript 3
Input & output capacity
Total number of input trays
2
Total input capacity
650 sheets
Total output capacity
250 sheets
Maximum number of input trays
2
Maximum input capacity
2300 sheets
Maximum output capacity
Maximum number of sheets this product can hold in all available standard and optional output trays.
250 sheets
Paper handling
Maximum ISO A-series paper size
The maximum paper size the device can handle, defined by ISO A-series.
A4
Paper tray media types
Envelopes
ISO A-series sizes (A0...A9)
Different sizes of paper from A0 (big) to A9 (small). A4 is the most common size used for printing documents.
Direct printing
With direct printing it is possible to print your photographs or other documents directly to a printer from a compatible device, without the use of a computer.
USB port
The device features a socket into which a USB cable can be plugged.
USB connector
What type of USB connector is built into the device.
USB Type-A / USB Type-B
USB 2.0 ports quantity
Number of USB 2.0 ports (connecting interfaces) in the device. USB 2.0 was released in April 2000 (now called "Hi-Speed"), adding higher maximum signaling rate of 480 Mbit/s (effective throughput up to 35 MB/s or 280 Mbit/s), USB 2.0 ports are usually black.
2
Optional connectivity
Ethernet, Wireless LAN
Network
Wi-Fi
Popular technology that allows an electronic device to exchange data or connect to the internet wirelessly using radio waves.
Ethernet LAN
An Ethernet LAN (Local Area Network) interface is present, for a wired conection via a cable.
Cabling technology
Type of cable technology performance.
10/100/1000Base-T(X)
Ethernet LAN data rates
The different speed levels of the Ethernet LAN connection.
10,100,1000 Mbit/s
Wi-Fi standards
The type of wireless local area network (LAN). It can be ad-hoc, where units in a network communicate peer-to-peer, or Infrastructure, where units communicate with each other via an access point A LAN interconnects computers in a small area e.g. home, school or office.
Maximum internal memory
The maximum amount of memory inside a product, usually measured in bytes e.g megabytes (MB) or gigabytes (GB).
2048 MB
Internal memory
The amount of memory, usually measured in bytes (e.g. MB, GB), which is installed in the system's hardware.
2048 MB
Built-in processor
Whether or not a processor is built into the device.
Processor cores
The number of central processing units ('cores') in a processor. Some processors have 1 core, others have 2 (e.g. Intel Core Duo) or more (e.g. the Intel Xeon E7-2850 has 10 cores).
2
Sound pressure level (printing)
55 dB
Sound pressure level (duplex printing)
55 dB
Sound pressure level (copying)
57 dB
Sound pressure level (scanning)
52 dB
Sound pressure level (standby)
15 dB
Design
Product colour
The colour e.g. red, blue, green, black, white.
Black, Grey
Market positioning
Under which category can the device be positioned in the market, e.g. camera phone.
Home & office
Built-in display
A display which is part of the product, so you do not need to attach another display.
Display diagonal
Size of the display for this product, measured diagonally, usually in inches.
10.9 cm (4.3")
Control type
The way in which the device is controlled.
Touch
Colour display
Power
Power consumption (max)
The maximum amount of power used by the device.
649 W
Power consumption (printing)
649 W
Power consumption (ready)
13.4 W
Power consumption (standby)
The amount of electricity that is consumed when the product is on standby.
0.1 W
Power consumption (sleep)
1 W
Energy Star Typical Electricity Consumption (TEC)
0.58 kWh/week
System requirements
Windows operating systems supported
Windows vesions wich can be used with the device.
Mac operating systems supported
Mac operating systems e.g. OS X can be used with the device.
Linux operating systems supported
8 RT. Linux (9.4, 9.5), Red Hat Enterprise Linux 5.0 (supported with a pre-built package); SUSE Linux (10.3, 11.0, 11, 11.1, 11.2), Fedora (9, 9.0, 10, 10.0, 11.0, 11, 12, 12.0), Ubuntu (8.04, 8.04.1, 8.04.2, 8.10, 9.04, 9.10, 10.04), Debian (5.0, 5.0.1, 5.0.2, 5.0.3)
Operational conditions
Operating relative humidity (H-H)
15 - 80%
Storage temperature (T-T)
The minimum and maximum temperatures at which the product can be safely stored.
10 - 32 °C
Operating altitude
0 - 2896 m
Weight & dimensions
Width
The measurement or extent of something from side to side.
479 mm
Depth
The distance from the front to the back of something.
450 mm
Height
The measurement of the product from head to foot or from base to top.
513.7 mm
Weight
Weight of the product without packaging (net weight). If possible, the net weight is given including standard accessories and supplies. Please note that sometimes the manufacturer leaves out the weight of accessories and/or supplies.
21.2 kg
Packaging data
Package width
The distance from one side of the packaging to the other.
584 mm
Package depth
The distance from the front to the back of the packaging.
559 mm
Package height
The distance from the top to the bottom of the packaging.
