Gigabit Ethernet (10/100/1000), Front USB 2.0 Specification Hi-Speed Certified port (Type A), USB 2.0 Specification Hi-Speed Certified (Type B), 802.11b/g/n/ac + BLE
Size (mm - H x W x D)
307.7 x 399 x 389.4 mm
Weight
15.2 kg
Packaged Size (mm - H x W x D)
422 x 470 x 430 mm
Packaged Weight, kg
17.2 kg
Printing
Print Speed
Up to:
Black: 47 ppm2 (A4)
Print Speed Duplex
Up to:
Black: 24 spm2 (A4)
Time to First Page
As fast as:
Black: 6 seconds
Print Resolution
Black: 1200 x 1200 dpi, 1200 IQ (1200 x 600 dpi)
Duplex
2-sided:
Integrated Duplex
Printable Area
metric: 4.2 mm of the top, bottom, right and left edges (within)
Paper Handling
Media Types Supported
Paper Labels, Card Stock, Plain Paper, Envelopes, Refer to the Paper & Specialty Media Guide
Print technology
Indicates the method used to print by this product.
Laser
Duplex printing
Feature of computer printers and multifunction printers (MFPs) that allows the printing of a sheet of paper on both sides (automatically or manually)
Maximum resolution
Maximum printing resolution.
1200 x 1200 DPI
Print speed (black, normal quality, A4/US Letter)
The print speed of a printer for black & white A4 pages, normal quality. The exact speed varies depending on the system configuration, software program, and document complexity.
47 ppm
Duplex print speed (black, normal quality, A4/US Letter)
24 ppm
Time to first page (black, normal)
6 s
Features
Maximum duty cycle
The maximum number of prints/copies made by a printer/copier in a fixed period.
175000 pages per month
Printing colours
The colours that can be produced by the printer.
Black
Page description languages
HTML Direct Image Space, PCL 5, PCL 6, PCLm, PDF 1.7, PPDS, PostScript 3
Input & output capacity
Total number of input trays
2
Total input capacity
650 sheets
Total output capacity
250 sheets
Maximum number of input trays
2
Maximum input capacity
2300 sheets
Maximum output capacity
Maximum number of sheets this product can hold in all available standard and optional output trays.
250 sheets
Paper handling
Maximum ISO A-series paper size
The maximum paper size the device can handle, defined by ISO A-series.
A4
Paper tray media types
Card stock, Envelopes
ISO A-series sizes (A0...A9)
Different sizes of paper from A0 (big) to A9 (small). A4 is the most common size used for printing documents.
A4, A5, A6
ISO B-series sizes (B0...B9)
B5
ISO C-series sizes (C0...C9)
C5
JIS B-series sizes (B0...B9)
B5
Envelopes sizes
7 3/4, 9
Paper tray media weight
60 - 120 g/m²
Ports & interfaces
Direct printing
With direct printing it is possible to print your photographs or other documents directly to a printer from a compatible device, without the use of a computer.
USB port
The device features a socket into which a USB cable can be plugged.
USB 2.0 ports quantity
Number of USB 2.0 ports (connecting interfaces) in the device. USB 2.0 was released in April 2000 (now called "Hi-Speed"), adding higher maximum signaling rate of 480 Mbit/s (effective throughput up to 35 MB/s or 280 Mbit/s), USB 2.0 ports are usually black.
2
USB connector
What type of USB connector is built into the device.
USB Type-A / USB Type-B
Optional connectivity
Ethernet, USB 2.0, Wireless LAN
Network
Wi-Fi
Popular technology that allows an electronic device to exchange data or connect to the internet wirelessly using radio waves.
Ethernet LAN
An Ethernet LAN (Local Area Network) interface is present, for a wired conection via a cable.
Cabling technology
Type of cable technology performance.
10/100/1000Base-T(X)
Ethernet LAN data rates
The different speed levels of the Ethernet LAN connection.
10,100,1000 Mbit/s
Wi-Fi standards
The type of wireless local area network (LAN). It can be ad-hoc, where units in a network communicate peer-to-peer, or Infrastructure, where units communicate with each other via an access point A LAN interconnects computers in a small area e.g. home, school or office.
Security algorithms
Security algorithms are used to provide authentication, cipher key generation, integrity and radio link privacy to users on mobile networks. The security algorithms supported are the ones that can be used with this product.
Internal memory
The amount of memory, usually measured in bytes (e.g. MB, GB), which is installed in the system's hardware.
1024 MB
Maximum internal memory
The maximum amount of memory inside a product, usually measured in bytes e.g megabytes (MB) or gigabytes (GB).
1024 MB
Built-in processor
Whether or not a processor is built into the device.
Sound pressure level (printing)
56 dB
Sound pressure level (duplex printing)
55 dB
Design
Market positioning
Under which category can the device be positioned in the market, e.g. camera phone.
Home & office
Product colour
The colour e.g. red, blue, green, black, white.
Black, Grey
Built-in display
A display which is part of the product, so you do not need to attach another display.
Colour display
Display diagonal
Size of the display for this product, measured diagonally, usually in inches.
10.9 cm (4.3")
Certification
ENERGY STAR, ICES-003 Class B, BSMI Class B, VCCI Class B, US FDA, UL 60950-1, FCC Class B, cUL CAN/CSA-C22.2 60950-1, NOM, CB EN/IEC 60950-1, CB EN/IEC 60825-1, CE DoC (EN 62368-1 Class B, EN 62311, CE EN/IEC 60950-1, CE EN/IEC 60825-1, EN 61000-3, EN 55022 Class B, EuP, EN 55032 Class B, UL), EFTA (CE), KCC, CCC, CECP, CEL, A-tick DoC, UL-AR, KC mark, UL GS mark, EC 1275, ISO 532B, ECMA-370, TED, SII, TER
Power
Power consumption (printing)
669 W
Power consumption (ready)
7.7 W
Energy Star Typical Electricity Consumption (TEC)
0.61 kWh/week
System requirements
Windows operating systems supported
Windows vesions wich can be used with the device.
Linux operating systems supported
8 RT. Linux (9.4, 9.5), Red Hat Enterprise Linux 5.0 (supported with a pre-built package); SUSE Linux (10.3, 11.0, 11, 11.1, 11.2), Fedora (9, 9.0, 10, 10.0, 11.0, 11, 12, 12.0), Ubuntu (8.04, 8.04.1, 8.04.2, 8.10, 9.04, 9.10, 10.04), Debian (5.0, 5.0.1, 5.0.2, 5.0.3)
Server operating systems supported
Windows Server 2000, Windows Server 2003, Windows Server 2003 R2, Windows Server 2003 x64, Windows Server 2008 R2, Windows Server 2012
Other operating systems supported
Novell Open Enterprise Server 11, Novell Open Enterprise Server 2
Operational conditions
Operating temperature (T-T)
The minimum and maximum temperatures at which the product can be safely operated.
10 - 32 °C
Operating relative humidity (H-H)
15 - 80%
Operating altitude
0 - 2896 m
Sustainability
Sustainability certificates
ENERGY STAR
Weight & dimensions
Width
The measurement or extent of something from side to side.
399 mm
Depth
The distance from the front to the back of something.
389.4 mm
Height
The measurement of the product from head to foot or from base to top.
307.7 mm
Weight
Weight of the product without packaging (net weight). If possible, the net weight is given including standard accessories and supplies. Please note that sometimes the manufacturer leaves out the weight of accessories and/or supplies.
15.2 kg
Packaging data
Package width
The distance from one side of the packaging to the other.
470 mm
Package depth
The distance from the front to the back of the packaging.
430 mm
Package height
The distance from the top to the bottom of the packaging.
