Specifications
Graphics Processing Unit (GPU) NVIDIA GeForce® RTX 4070 Ti SUPER
Bus Interface PCI Express 4.0
Memory Configuration 16G GDDR6X
Core Clock Base clock: 2340 MHz
Boost clock: 2610 MHz
Memory Speed 21 Gbps
Output Ports 1x HDMI(2.1), 3 x DisplayPort(1.4a)
Maximum Digital Resolution 7680x4320
Memory Interface Width 256-bit
(GB/sec) Memory Bandwidth 672
CUDA Cores 8448
HDCP Support Yes
Microsoft® DirectX® 1Microsoft DirectX® 12 Ultimate
NVIDIA RTX NVLink No
OpenGL® 4.6
Maximum Power Draw(W) 285 W
Dimensions
1 319 mm (length)
2 124 mm (height)
3 68.3 mm (thickness)
Package Contents WinFast RTX 4070 Ti SUPER HURRICANE 12G Graphics Card
Quick Installation Guide
16 Pin Power Cable x 1(2 x PCI/E 8pin to 16Pin)
GPU Support Holder
Requirements Microsoft Windows10,Windows 11 and Linux operation system (64 bit)
PCI-Express compliant motherboard with one four-width x16 graphics slot
Two 8-pin PCI-Express supplementary power connectors
8GB system memory (16GB or higher recommended)
1.5GB of available hard disk space
A DP or HDMI compatible monitor
Minimum 700W Power Supply
Graphics Processing Unit (GPU) NVIDIA GeForce® RTX 4070 Ti SUPER
Bus Interface PCI Express 4.0
Memory Configuration 16G GDDR6X
Core Clock Base clock: 2340 MHz
Boost clock: 2610 MHz
Memory Speed 21 Gbps
Output Ports 1x HDMI(2.1), 3 x DisplayPort(1.4a)
Maximum Digital Resolution 7680x4320
Memory Interface Width 256-bit
(GB/sec) Memory Bandwidth 672
CUDA Cores 8448
HDCP Support Yes
Microsoft® DirectX® 1Microsoft DirectX® 12 Ultimate
NVIDIA RTX NVLink No
OpenGL® 4.6
Maximum Power Draw(W) 285 W
Dimensions
1 319 mm (length)
2 124 mm (height)
3 68.3 mm (thickness)
Package Contents WinFast RTX 4070 Ti SUPER HURRICANE 12G Graphics Card
Quick Installation Guide
16 Pin Power Cable x 1(2 x PCI/E 8pin to 16Pin)
GPU Support Holder
Requirements Microsoft Windows10,Windows 11 and Linux operation system (64 bit)
PCI-Express compliant motherboard with one four-width x16 graphics slot
Two 8-pin PCI-Express supplementary power connectors
8GB system memory (16GB or higher recommended)
1.5GB of available hard disk space
A DP or HDMI compatible monitor
Minimum 700W Power Supply
| Processor | |
| CUDA CUDA (aka Compute Unified Device Architecture) is a parallel computing platform and programming model created by NVIDIA and implemented by the graphics processing units (GPUs) that they produce. CUDA gives program developers direct access to the virtual instruction set and memory of the parallel computational elements in CUDA GPUs. |
 |
| CUDA cores | 8448 |
| Graphics processor family The category to which the graphics processor (GPU) belongs e.g. Southern Islands family of Radeon processors (made by AMD), GeForce 600 (made by NVIDIA). | NVIDIA |
| Graphics processor Also known as a graphics processing unit (GPU), this is a specialized electronic circuit designed to rapidly manipulate and alter memory to accelerate the creation of images in a frame buffer intended for output to a display. GPUs are used in embedded systems, mobile phones, personal computers, workstations, and game consoles. Modern GPUs are very efficient at manipulating computer graphics. | GeForce RTX 4070 Ti SUPER |
| Processor frequency The clock rate is the fundamental rate in cycles per second (measured in hertz) at which a computer performs its most basic operations such as adding two numbers. There are more factors, like internal memory size, that influence a computer's actual response time. | 2340 MHz |
| Processor boost clock speed | 2610 MHz |
| Maximum resolution The maximum number of pixels that can be displayed in the image. It is usually quoted as width × height,: for example, "1024 × 768" means the width is 1024 pixels and the height is 768 pixels. | 7680 x 4320 pixels |
| Memory | |
| Discrete graphics card memory | 16 GB |
| Graphics card memory type The type of memory used by the video card. Often a combination of dedicated memory (Video RAM or VRAM) and dynamic system memory is used. UMA stands for Unified Memory Architecture, and is a computer memory architecture that allows the graphics processing unit to share system memory. Other abreviations: RAM = Random Access Memory, SDRAM = synchronous dynamic RAM, DDR = double-data-rate. | GDDR6X |
| Memory bus Hardware and software that connects the main memory to the memory controller in computer systems. Originally, general-purpose buses like VMEbus and the S-100 bus were used, but to reduce latency, modern memory buses are designed to connect directly to DRAM chips, and thus are designed by chip standards bodies such as JEDEC. | 256 bit |
| Data transfer rate Rate at which data can be transferred. Usually expressed in units per second. May vary with network configurations. | 21 Gbit/s |
| Memory bandwidth (max) | 672 GB/s |
| Ports & interfaces | |
| Interface type | PCI Express 4.0 |
| HDMI ports quantity The number of sockets (ports) for HDMI connections. HDMI (High-Definition Multimedia Interface) is a compact audio/video interface for transferring uncompressed video data and compressed/uncompressed digital audio data from a HDMI-compliant device ("the source device") to a compatible computer monitor, video projector, digital television, or digital audio device. HDMI is a digital replacement for existing analog video standards. | 1 |
| HDMI version | 2.1 |
| DisplayPorts quantity Number of DisplayPorts. A DisplayPort is a digital display interface developed by the Video Electronics Standards Association (VESA). The interface is primarily used to connect a video source to a display device such as a computer monitor, though it can also be used to carry audio, USB, and other forms of data. | 3 |
| DisplayPort version | 1.4a |
| Performance | |
| TV tuner integrated Device has an in-built TV tuner. |
 |
| DirectX version DirectX is a collection of APIs (application programming interfaces) for easily handling tasks related to game programming on the Microsoft Windows operating system. | 12 Ultimate |
| OpenGL version OpenGL (Open Graphics Library) is a specification defining a cross-language cross-platform API for writing applications that produce 3D computer graphics (and 2D computer graphics as well). The interface consists of over 250 different function calls which can be used to draw complex three-dimensional scenes from simple primitives. | 4.6 |
| HDCP High-bandwidth Digital Content Protection (HDCP) is a form of digital copy protection to prevent copying of digital audio and video content as it travels across connections. |
|
| Dual Link DVI A dual-link DVI interface sends data over both of the DVI links to the monitor, and this is how higher resolutions are achieved. With dual-link DVI, a resolution of 2048 x 1536 is possible. |
|
| Design | |
| Cooling type The method used to cool the device or to cool the air around the device. | Active |
| Number of fans The quantity of fans (apparatus with rotating blades that creates a current of air for cooling or ventilation). | 3 fan(s) |
| Power | |
| Minimum system power supply The lowest power that is needed. | 700 W |
| Supplementary power connectors | 2x 8-pin |
| Power consumption (max) The maximum amount of power used by the device. | 285 W |
| System requirements | |
| Windows operating systems supported Windows vesions wich can be used with the device. | Windows 10, Windows 11 |
| Linux operating systems supported 8 RT. Linux (9.4, 9.5), Red Hat Enterprise Linux 5.0 (supported with a pre-built package); SUSE Linux (10.3, 11.0, 11, 11.1, 11.2), Fedora (9, 9.0, 10, 10.0, 11.0, 11, 12, 12.0), Ubuntu (8.04, 8.04.1, 8.04.2, 8.10, 9.04, 9.10, 10.04), Debian (5.0, 5.0.1, 5.0.2, 5.0.3) |
|
| Weight & dimensions | |
| Length The measurement or extent of something from end to end. | 319 mm |
| Depth The distance from the front to the back of something. | 68.3 mm |
| Height The measurement of the product from head to foot or from base to top. | 124 mm |
| SKU | 813363 |
| MPN | 127B3000110 |
| Brand | Leadtek |
| Product Condition | Brand New/Unused |
| GPU Series | GeForce RTX 4070 Ti Super |
| Graphics RAM Size | 16 GB |
| Stock Availability | Available for Shipping |
| Product Use | General |
| Warranty Period | 3 Years Warranty |
| Warranty Contact | https://www.leadtek.com/ |
