Print technology
Indicates the method used to print by this product.
Laser
Printing
Producing a paper copy of information stored on a computer.
Colour printing
Duplex printing
Feature of computer printers and multifunction printers (MFPs) that allows the printing of a sheet of paper on both sides (automatically or manually)
Maximum resolution
Maximum printing resolution.
1200 x 1200 DPI
Print speed (black, normal quality, A4/US Letter)
The print speed of a printer for black & white A4 pages, normal quality. The exact speed varies depending on the system configuration, software program, and document complexity.
26 ppm
Print speed (colour, normal quality, A4/US Letter)
26 ppm
Print speed (black, draft quality, A4/US Letter)
26 ppm
Print speed (colour, draft quality, A4/US Letter)
26 ppm
Duplex print speed (black, normal quality, A4/US Letter)
13 ppm
Duplex print speed (colour, normal quality, A4/US Letter)
13 ppm
Warm-up time
Time needed before printing after power switched on.
29 s
Time to first page (black, normal)
9.5 s
Time to first page (colour, normal)
10.5 s
Print margins (top, bottom, right, left)
4.2 mm
N-in-1 print function
Skip blank page function
Auto tray switching function
Tray priority settings function
N-up printing
2,4,6,8,9,16,25
Barcode printing
Watermark printing
Economical printing
Whether or not the product is equipped with features that allow economical printing.
Secure printing
Poster printing function
Secure PDF printing function
Eco printing function
Copying
Duplex copying
Duplex copying mode
Auto
Copying
Description of copying function (colour or monochrome).
Colour copying
Maximum copy resolution
The greatest amount of detail that can be produced by a copy of a document.
600 x 600 DPI
Copy speed (black, normal quality, A4)
26 cpm
Copy speed (colour, normal quality, A4)
26 cpm
Time to first copy (black, normal)
8 s
Time to first copy (colour, normal)
10 s
Maximum number of copies
999 copies
Copier resize
25 - 400%
N-in-1 copy function
N-in-1 copy function (N=)
2,4
Copy programming function
ID-card copy function
Scanning
Duplex scanning
Feature of computer scanners and multifunction printers (MFPs) that allows the automatic scanning of a sheet of paper on both sides.
Duplex scanning mode
Auto
Scanning
To convert a document or picture into digital form for storage or processing on a computer, by scanning it using a scanner.
Colour scanning
Optical scanning resolution
How many pixels a scanner can see. Most commonly, this is measured in dots per inch (dpi).For example, a typical flatbed scanner will use a scanning head with 300 sensors per inch, so it can sample 300 dots per inch (dpi) in one direction. To scan in the other direction, it will move the scanning head along the page, stopping 300 times per inch, so it can scan 300 dpi in the other direction as well. This scanner would have an optical resolution of 300 x 300 dpi. Some manufacturers stop the scanning head more frequently as it moves down the page, so their machines have resolutions of 300 x 600 dpi or 300x1200 dpi.
600 x 600 DPI
Scanner type
Indicates the type of scanner this product is.
Flatbed & ADF scanner
Scan technology
Indicates the technology used to scan by this product
CIS/CCD
Scan to
E-mail, FTP, SMB, TWAIN, USB, WIA
Scan speed (colour)
23 ppm
Scan speed (black)
30 ppm
Duplex scan speed (colour)
16 ppm
Duplex scan speed (black)
24 ppm
Image formats supported
The type of image files that the device can use/display e.g. gif, JPEG (jpg).
JPEG, MMR, TIFF
Document formats supported
The type of document formats that can be read/produced with this device e.g. .docx, .pdf.
PDF,XPS
Greyscale levels
256
Scan drivers
TWAIN,WIA
Scan speed (ADF, A4)
30 ppm
Fax
Duplex faxing
Faxing
To send an exact copy of a document made by electronic scanning and transmitted as data by telecommunications links.
Mono faxing
Fax resolution (black)
400 x 400 DPI
Fax transmission speed
3 sec/page
Modem speed
The speed at which data is transferred by a modem.
33.6 Kbit/s
Fax memory
100 pages
Fax coding methods
JBIG, MH, MMR, MR
Features
Recommended duty cycle
500 - 2000 pages per month
Maximum duty cycle
The maximum number of prints/copies made by a printer/copier in a fixed period.
50000 pages per month
Duplex functions
The product has the ability to print, scan etc. on both sides of a sheet of paper.
Copy, Fax, Print, Scan
Digital sender
Device similar to a scanner which converts paper documents into digital information for emailing, archiving, document management and more.
Number of print cartridges
The amount of print cartridges. A print cartridge is a container holding a quantity of ink which is inserted into a inkjet printer mechanism.
4
Printing colours
The colours that can be produced by the printer.
Black, Cyan, Magenta, Yellow
Page description languages
Microsoft XPS,PCL 5c,PCL 6,PCL XL,PostScript 3
Number of printer fonts
93
All-In-One-multitasking
Replacement cartridges
TK-5240K, TK-5240C, TK-5240M, TK-5240Y
Input & output capacity
Total number of input trays
1
Total input capacity
250 sheets
Total output capacity
150 sheets
Paper tray 1 input capacity
250 sheets
Multi-Purpose tray
Multi-Purpose tray input capacity
50 sheets
Paper input type
Cassette, Paper tray
Auto document feeder (ADF)
Auto document feeder (ADF) input capacity
Number of sheets this product can hold in its ADF tray; expressed in sheets
50 sheets
Auto document feeder (ADF) output capacity
50 sheets
Maximum number of input trays
2
Maximum input capacity
550 sheets
Maximum output capacity
Maximum number of sheets this product can hold in all available standard and optional output trays.
150 sheets
Paper handling
Maximum ISO A-series paper size
The maximum paper size the device can handle, defined by ISO A-series.
A4
Maximum print size
The maximum size that an image can be printed with a good resolution.
216 x 356 mm
Paper tray media types
Letterhead, Plain paper, Pre-printed
Multi-purpose tray media types
Bond paper, Envelopes, Labels, Legal, Letter, Letterhead, Plain paper, Recycled paper, Thick paper, Thin paper
ISO A-series sizes (A0...A9)
Different sizes of paper from A0 (big) to A9 (small). A4 is the most common size used for printing documents.
A4,A5,A6
ISO B-series sizes (B0...B9)
B5,B6
Non-ISO print media sizes
Legal, Letter
Custom media width
70 - 216 mm
Custom media length
148 - 356 mm
Paper tray media weight
60 - 163 g/m²
Multi-Purpose Tray media weight
60 - 220 g/m²
Auto Document Feeder (ADF) media weight
50 - 160 g/m²
Duplex media weight
60 - 120 g/m²
Scan media weight
50 - 160 g/m²
Media thickness (min)
0.11 mm
Ports & interfaces
Standard interfaces
Most common industry-standard communication protocols ranging from RS-232, RS-422, RS-423, RS-485, and LVDS to USB.
Ethernet, USB 2.0, Wireless LAN
Direct printing
With direct printing it is possible to print your photographs or other documents directly to a printer from a compatible device, without the use of a computer.
USB port
The device features a socket into which a USB cable can be plugged.
USB 2.0 ports quantity
Number of USB 2.0 ports (connecting interfaces) in the device. USB 2.0 was released in April 2000 (now called "Hi-Speed"), adding higher maximum signaling rate of 480 Mbit/s (effective throughput up to 35 MB/s or 280 Mbit/s), USB 2.0 ports are usually black.
2
Network
Wi-Fi
Popular technology that allows an electronic device to exchange data or connect to the internet wirelessly using radio waves.
Ethernet LAN
An Ethernet LAN (Local Area Network) interface is present, for a wired conection via a cable.
Cabling technology
Type of cable technology performance.
10/100/1000Base-T(X)
Ethernet LAN data rates
The different speed levels of the Ethernet LAN connection.
10,100,1000 Mbit/s
Wi-Fi standards
The type of wireless local area network (LAN). It can be ad-hoc, where units in a network communicate peer-to-peer, or Infrastructure, where units communicate with each other via an access point A LAN interconnects computers in a small area e.g. home, school or office.
802.11b,802.11g,Wi-Fi 4 (802.11n)
Bluetooth
Bluetooth is a low-power radio technology developed to replace the cables and wires currently used to link or connect electronic devices such as personal computers, printers, and a wide variety of handheld devices including mobile phones. Because it uses radio-wave connectivity, a Bluetooth-enabled device has a constant, established connection to whatever browser it uses. This saves the user the trouble of logging on to check for emails or news updates, for example.
Near Field Communication (NFC)
Security algorithms
Security algorithms are used to provide authentication, cipher key generation, integrity and radio link privacy to users on mobile networks. The security algorithms supported are the ones that can be used with this product.
Email over SSL
SSL is an email encryption method. Email encryption protects the content from being read by any but the intended recipients.
Mobile printing technologies
Apps etc. which allow users to send a print job from a smartphone or tablet to a printer via a wireless network.
Apple AirPrint,Google Cloud Print,Kyocera Mobile Print,Mopria Print Service
Performance
Maximum internal memory
The maximum amount of memory inside a product, usually measured in bytes e.g megabytes (MB) or gigabytes (GB).
1536 MB
Memory slots
Number and type of memory expansion slots, including connector and memory module descriptions.
1
Card reader integrated
The device includes a card reader e.g. a card reader in the disk bay of a computer or thin client to permit log-on using smart/pin cards.
Internal memory
The amount of memory, usually measured in bytes (e.g. MB, GB), which is installed in the system's hardware.
512 MB
Compatible memory cards
Types of memory cards which can be used with this product.
SD,SDHC
Built-in processor
Whether or not a processor is built into the device.
Processor family
A family of processors is a group of processors produced by one company over a short period of time e.g. Intel Pentium processors.
ARM Cortex-A9
Processor frequency
The clock rate is the fundamental rate in cycles per second (measured in hertz) at which a computer performs its most basic operations such as adding two numbers. There are more factors, like internal memory size, that influence a computer's actual response time.
800 MHz
Processor cores
The number of central processing units ('cores') in a processor. Some processors have 1 core, others have 2 (e.g. Intel Core Duo) or more (e.g. the Intel Xeon E7-2850 has 10 cores).
1
Sound pressure level (printing)
49 dB
Sound pressure level (copying)
49 dB
Sound pressure level (standby)
30 dB
Sound pressure level (quiet mode)
44 dB
Design
Product colour
The colour e.g. red, blue, green, black, white.
Black, White
Market positioning
Under which category can the device be positioned in the market, e.g. camera phone.
Home & office
Built-in display
A display which is part of the product, so you do not need to attach another display.
Display
The description of display that can includes display type, resolution, size etc.
TFT
Display diagonal
Size of the display for this product, measured diagonally, usually in inches.
10.9 cm (4.3")
Display resolution
The number of distinct pixels in each dimension that can be displayed. It is usually quoted as width × height, with the units in pixels: for example, "1024 × 768" means the width is 1024 pixels and the height is 768 pixels. The higher the number of pixels, the sharper the image.
480 x 272 pixels
Touchscreen
A screen of a laptop, smartphone, etc., that responds to touch so you can control the interface using your fingers.
Control type
The way in which the device is controlled.
Touch
Colour display
Power
Power consumption (max)
The maximum amount of power used by the device.
1090 W
Power consumption (average operating)
375 W
Power consumption (printing)
375 W
Power consumption (copying)
375 W
Power consumption (ready)
41 W
Power consumption (sleep)
1 W
Power consumption (off)
0.2 W
Energy Star Typical Electricity Consumption (TEC)
1.024 kWh/week
AC input voltage
The voltage of the AC electricity that is inputted into the product.
220 - 240 V
AC input frequency
50/60 Hz
System requirements
Windows operating systems supported
Windows vesions wich can be used with the device.
Mac operating systems supported
Mac operating systems e.g. OS X can be used with the device.
Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.15 Catalina, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks
Linux operating systems supported
8 RT. Linux (9.4, 9.5), Red Hat Enterprise Linux 5.0 (supported with a pre-built package); SUSE Linux (10.3, 11.0, 11, 11.1, 11.2), Fedora (9, 9.0, 10, 10.0, 11.0, 11, 12, 12.0), Ubuntu (8.04, 8.04.1, 8.04.2, 8.10, 9.04, 9.10, 10.04), Debian (5.0, 5.0.1, 5.0.2, 5.0.3)
Operational conditions
Operating relative humidity (H-H)
10 - 80%
Storage temperature (T-T)
The minimum and maximum temperatures at which the product can be safely stored.
-20 - 40 °C
Operating temperature (T-T)
The minimum and maximum temperatures at which the product can be safely operated.
10 - 32.5 °C
Storage relative humidity (H-H)
10 - 90%
Operating altitude
0 - 3500 m
Non-operating altitude
0.6 - 15000 m
Certificates
Waste Electrical and Electronic Equipment (WEEE) compliance
Certification
TÜV/GS, CE, ISO 9001, ISO 14001
Sustainability
Sustainability certificates
Blue Angel, REACH, RoHS, EPEAT Silver, ENERGY STAR
Weight & dimensions
Width
The measurement or extent of something from side to side.
417 mm
Depth
The distance from the front to the back of something.
429 mm
Height
The measurement of the product from head to foot or from base to top.
495 mm
Weight
Weight of the product without packaging (net weight). If possible, the net weight is given including standard accessories and supplies. Please note that sometimes the manufacturer leaves out the weight of accessories and/or supplies.
26 kg
Packaging data
Package width
The distance from one side of the packaging to the other.
592 mm
Package depth
The distance from the front to the back of the packaging.
567 mm
Package height
The distance from the top to the bottom of the packaging.
637 mm
Package weight
Weight of the packaged product.
33 kg
Packaging content
Cartridge(s) included
Included cartridge capacity (black)
1200 pages
Included cartridge capacity (CMY)
1200 pages
Imaging unit included
Cables included
AC
Drivers included
Manual
Power cord included
Quick installation guide
Other features
Finishing option
Energy saving mode
Device has energy saving operating mode.
