CAS latency
Column Address Strobe (CAS) latency, or CL, is the delay time between the moment a memory controller tells the memory module to access a particular memory column on a RAM module, and the moment the data from the given array location is available on the module's output pins. In general, the lower the CAS latency, the better.
17
Internal memory
A computer's memory which is directly accessible to the CPU.
16 GB
Memory layout (modules x size)
How the overall memory of the product is put together, defined by the number of modules and the size.
1 x 16 GB
Internal memory type
The type of internal memory such as RAM, GDDR5.
DDR4
Memory clock speed
The frequency at which the memory (e.g. RAM) runs.
2400 MHz
Component for
What this product is used as a part of (component for).
PC/server
Memory form factor
Design of the memory e.g. 240-pin DIMM, SO-DIMM.
288-pin DIMM
Buffered memory type
Unregistered (unbuffered)
ECC
ECC means Error Correction Code, and it is memory that is able to detect and correct some memory errors without user intervention.
Memory ranking
2
Memory voltage
The voltage (V) of the memory in the device.
1.2 V
Module configuration
2048M x 64
Row cycle time
45.75 ns
Refresh row cycle time
350 ns
Row active time
32 ns
SPD profile
Halogen-free
Memory type
Type of memory in the device e.g. DDR3, SRAM (Static RAM).
PC4-19200
Product colour
The colour e.g. red, blue, green, black, white.
Green
Lead plating
Gold
Windows operating systems supported
Windows vesions wich can be used with the device.
Mac operating systems supported
Mac operating systems e.g. OS X can be used with the device.
Linux operating systems supported
8 RT. Linux (9.4, 9.5), Red Hat Enterprise Linux 5.0 (supported with a pre-built package); SUSE Linux (10.3, 11.0, 11, 11.1, 11.2), Fedora (9, 9.0, 10, 10.0, 11.0, 11, 12, 12.0), Ubuntu (8.04, 8.04.1, 8.04.2, 8.10, 9.04, 9.10, 10.04), Debian (5.0, 5.0.1, 5.0.2, 5.0.3)
RoHS compliance
The Restriction of Hazardous Substances (RoHS) Directive aims to restrict certain dangerous substances commonly used in electrical and electronic equipment. Any RoHS compliant product is tested for the presence of Lead (Pb), Cadmium (Cd), Mercury (Hg), Hexavalent chromium (Hex-Cr), Polybrominated biphenyls (PBB), and Polybrominated diphenyl ethers (PBDE). PBB and PBDE are flame retardants used in several plastics. For Cadmium and Hexavalent chromium, there must be less than 0.01% of the substance by weight at raw homogeneous materials level. For Lead, PBB, and PBDE, there must be no more than 0.1% of the material, when calculated by weight at raw homogeneous materials. Any RoHS compliant component must have 100 ppm or less of mercury and the mercury must not have been intentionally added to the component. In the EU, some military and medical equipment are exempt from RoHS compliance.
Operational conditions
Operating temperature (T-T)
The minimum and maximum temperatures at which the product can be safely operated.
0 - 85 °C
Storage temperature (T-T)
The minimum and maximum temperatures at which the product can be safely stored.
-55 - 100 °C
Weight & dimensions
Width
The measurement or extent of something from side to side.
133.3 mm
Height
The measurement of the product from head to foot or from base to top.
31.2 mm
Packaging data
Package type
The type of product package e.g. box.
