CAS latency
Column Address Strobe (CAS) latency, or CL, is the delay time between the moment a memory controller tells the memory module to access a particular memory column on a RAM module, and the moment the data from the given array location is available on the module's output pins. In general, the lower the CAS latency, the better.
11
Internal memory
A computer's memory which is directly accessible to the CPU.
8 GB
Memory layout (modules x size)
How the overall memory of the product is put together, defined by the number of modules and the size.
1 x 8 GB
Internal memory type
The type of internal memory such as RAM, GDDR5.
DDR3L
Memory clock speed
The frequency at which the memory (e.g. RAM) runs.
1600 MHz
Component for
What this product is used as a part of (component for).
PC/server
Memory form factor
Design of the memory e.g. 240-pin DIMM, SO-DIMM.
240-pin DIMM
Buffered memory type
Unregistered (unbuffered)
ECC
ECC means Error Correction Code, and it is memory that is able to detect and correct some memory errors without user intervention.
Memory bus
Hardware and software that connects the main memory to the memory controller in computer systems. Originally, general-purpose buses like VMEbus and the S-100 bus were used, but to reduce latency, modern memory buses are designed to connect directly to DRAM chips, and thus are designed by chip standards bodies such as JEDEC.
64 bit
Memory ranking
2
Memory voltage
The voltage (V) of the memory in the device.
1.35 V
Module configuration
1024M x 64
Memory type
Type of memory in the device e.g. DDR3, SRAM (Static RAM).
PC-12800
Product colour
The colour e.g. red, blue, green, black, white.
Green
Lead plating
Gold
Windows operating systems supported
Windows vesions wich can be used with the device.
Mac operating systems supported
Mac operating systems e.g. OS X can be used with the device.
Compatible products
Other products that can be used with this product.
Acer: Aspire T Series ATC-710, Aspire X Series AXC710-xxx, Veriton 2 Series VM2631-xxx, Veriton 2 Series VX2120-xxx, Veriton M Series M2120G-xxx, Veriton M Series M2631G-xxx, Veriton X Series X2120G-xxx; Dell: Inspiron 3650, OptiPlex 3040 MT/SFF, Vostro 3650; HP/Compaq: EliteDesk 705 G2 Series SFF/MT, Pavilion 550-132d, Pavilion 550-142d, ProDesk 400 G2.5
Operational conditions
Operating temperature (T-T)
The minimum and maximum temperatures at which the product can be safely operated.
0 - 85 °C
Weight & dimensions
Width
The measurement or extent of something from side to side.
133.3 mm
Other features
Chips organisation
x8
Number of pins
240
Rack mounting
The type of mounting that can position devices in a shelving system (rack).
