Flexible Port Partitioning (FPP) technology utilizes industry standard PCI SIG SR-IOV to efficiently divide your physical Ethernet device into multiple virtual devices, providing Quality of Service by ensuring each process is assigned to a Virtual Function and is provided a fair share of the bandwidth.
Virtual Machine Device Queues (VMDq) is a technology designed to offload some of the switching done in the VMM (Virtual Machine Monitor) to networking hardware specifically designed for this function. VMDq drastically reduces overhead associated with I/O switching in the VMM which greatly improves throughput and overall system performance
Single-Root I/O Virtualization (SR-IOV) involves natively (directly) sharing a single I/O resource between multiple virtual machines. SR-IOV provides a mechanism by which a Single Root Function (for example a single Ethernet Port) can appear to be multiple separate physical devices.
Ports & interfaces
Connectivity technology
The technology that enables connectivity of the device, e.g. wired or wireless.
Wired
Host interface
Interface that enables a host controller to communicate with a driver.
PCI Express
Interface
Interface ports to connect pieces of equipment. USB (Universal Serial Bus) has become the most popular wired interface to connect peripherals. USB 2.0 supports speeds up to 480 Mbit/s (USB 1: 12 Mbit/s). The interface FireWire is also known as the IEEE 1394 standard. Enhanced IDE (EIDE)is sometimes referred to as Fast ATA, Fast IDE or ATA-2.
Fiber
Ethernet LAN (RJ-45) ports
Number of Ethernet LAN (RJ-45) ports (connecting interfaces) in the device. Ethernet LAN (RJ-45) ports allow a computer to connect to the ethernet.
2
Fiber ports quantity
The number of sockets (ports) for fibers (cables).
2
Fiber optic connector
This terminates the end of an optical fiber, and enables quicker connection and disconnection than splicing. The connectors mechanically couple and align the cores of fibers so light can pass. Better connectors lose very little light due to reflection or misalignment of the fibers. In all there have been about 100 types of optic fiber connectors produced.
QSFP+
PCI version
3.0
PCI Card form factor
Design of the PCI Card.
Half-height (low-profile)
Network
Maximum data transfer rate
The maximum speed with which data can be transmitted from one device to another.
40000 Mbit/s
Networking standards
The way in which the network is working, e.g. IEEE 802.11a, IEEE 802.11b, IEEE 802.11g.
Ethernet LAN data rates
The different speed levels of the Ethernet LAN connection.
10000,40000 Mbit/s
Supported network protocols
Network protocols tested as compatible with this product e.g. FTP,HTML, POP.
TCP, UDP, IP
VLAN tagging
Maximum operating distance
The maximum distance from which you can operate the device.
10 m
LAN controller
Intel® XL710
Design
Component for
What this product is used as a part of (component for).
Server
Product colour
The colour e.g. red, blue, green, black, white.
Black, Green
Internal
The product is built in.
LED indicators
Certification
FCC B, UL, CE, VCCI, BSMI, CTICK, KCC
Power
Power consumption (typical)
Amount of power consumed by this model, often expressed in watts (W). Typical values that manufacturers give are power consumption when off, standby/suspended mode, typical use, maximum usage.
4.9 W
System requirements
Compatible operating systems
List of desktop operating systems tested as compatible with this product.
Linux operating systems supported
8 RT. Linux (9.4, 9.5), Red Hat Enterprise Linux 5.0 (supported with a pre-built package); SUSE Linux (10.3, 11.0, 11, 11.1, 11.2), Fedora (9, 9.0, 10, 10.0, 11.0, 11, 12, 12.0), Ubuntu (8.04, 8.04.1, 8.04.2, 8.10, 9.04, 9.10, 10.04), Debian (5.0, 5.0.1, 5.0.2, 5.0.3)
RedHat EL Linux 6.0
Server operating systems supported
Windows Server 2008 R2, Windows Server 2012, Windows Server 2012 R2
Operational conditions
Operating temperature (T-T)
The minimum and maximum temperatures at which the product can be safely operated.
0 - 55 °C
Storage temperature (T-T)
The minimum and maximum temperatures at which the product can be safely stored.
-40 - 70 °C
Storage relative humidity (H-H)
35 - 90%
Sustainability
Sustainability certificates
RoHS
Weight & dimensions
Width
The measurement or extent of something from side to side.
68.6 mm
Depth
The distance from the front to the back of something.
152.4 mm
Logistics data
Harmonized System (HS) code
85176990
Other features
Cable type
Type of cable e.g. electicity cable, optical cable.
QSFP+ Direct Attach Cabling up to 10m
Market segment
Server
Target market
Artificial Intelligence, High Performance Computing
Flow control support
Management protocols
SNMP, RMON
Number of VLANs
4096
Intel® Virtualization Technology (Intel® VT)
<b>Simplify Virtualization and Reduce Overheads</b>
Intel® Virtualization Technology (Intel® VT) helps make virtualization practical by eliminating performance overheads, reducing complexity, and improving security with hardware assistance. Virtualization allows multiple workloads to share a common set of resources so that a variety of workloads can co-locate while maintaining full isolation from each other.
VT-c
Intel Trusted Execution Technology
Embedded options available
Intel Virtual Machine Device Queues (VMDq)
PCI-SIG* SR-IOV Capable
On-chip QoS and Traffic Management
Intel Flexible Port Partitioning
Storage-over-ethernet
Speed & slot width
8.0 GT/s, x8 Lane
Message signal interrupt
Low halogen options available
Intelligent Offloads
iWARP/RDMA
Fiber Channel over Ethernet
Intel Ethernet Power Management
Intel Data Direct I/O Technology
Intel Virtualization Technology for Connectivity (VT-c)
<b>Simplify Virtualization and Reduce Overheads</b>
Intel® Virtualization Technology (Intel® VT) helps make virtualization practical by eliminating performance overheads, reducing complexity, and improving security with hardware assistance. Virtualization allows multiple workloads to share a common set of resources so that a variety of workloads can co-locate while maintaining full isolation from each other.
Interface type
PCIe v3.0 (8.0 GT/s)
Storage Over Ethernet
iSCSI, NFS
Conflict-Free
"Conflict free" means "DRC conflict free", which is defined by the U.S. Securities and Exchange Commission rules to mean products that do not contain conflict minerals (tin, tantalum, tungsten and/or gold) that directly or indirectly finance or benefit armed groups in the Democratic Republic of the Congo (DRC) or adjoining countries.
