Processor manufacturer
The manufacturer that produced the processor.
Intel
Processor family
A family of processors is a group of processors produced by one company over a short period of time e.g. Intel Pentium processors.
Intel® Xeon®
Processor frequency
The speed that the microprocessor executes each instruction or each vibration of the clock. The CPU requires a fixed number of clock ticks, or cycles, to execute each instruction. The faster the clocks rate, the faster the CPU, or the faster it can execute instructions. Clock Speeds are usually determined in MHz, 1 MHz representing 1 million cycles per second, or in GHz, 1 GHz representing 1 thousand million cycles per second. The higher the CPU speed, the better a computer will perform.
2.1 GHz
Processor cores
The number of central processing units ('cores') in a processor. Some processors have 1 core, others have 2 (e.g. Intel Core Duo) or more (e.g. the Intel Xeon E7-2850 has 10 cores).
8
Processor socket
Mechanical component(s) that provides mechanical and electrical connections between a microprocessor and a printed circuit board (PCB). This allows the processor to be replaced without soldering.
LGA 3647
Component for
What this product is used as a part of (component for).
Server/Workstation
Processor lithography
The process which is performed by the processor e.g. CPU (Central Processing Unit).
14 nm
Processor series
Intel Xeon Scalable Processors
Processor model
The model number for the processor in a computer.
4110
Processor threads
16
Processor operating modes
Operating modes for the processors that place restrictions on the type and scope of operations for certain processes run by the CPU. This design allows the operating system to run with more privileges than application software.
64-bit
Processor cache
11 MB
Processor cache type
L3
Box
Plastic or metal shell/container for components.
Processor boost frequency
The turbo boost is an automatic, managed accelleration of the processor when one of the cores is overloaded.
3 GHz
Processor codename
Skylake
Intel Volume Management Device (VMD)
Processor ARK ID
123547
Memory
Maximum internal memory supported by processor
768 GB
Memory types supported by processor
LPDDR4-SDRAM
Memory clock speeds supported by processor
2400 MHz
Memory channels
Hepta-channel
ECC
ECC means Error Correction Code, and it is memory that is able to detect and correct some memory errors without user intervention.
Graphics
On-board graphics adapter
Graphics hardware which is built into the motherboard or CPU, as opposed to a separate graphics adapter (video card). On-board graphics uses CPU and RAM for graphics processing.
Power
Thermal Design Power (TDP)
85 W
Features
Execute Disable Bit
Maximum number of PCI Express lanes
48
PCI Express slots version
3.0
Supported instruction sets
AVX,AVX 2.0,AVX-512,SSE4.2
Scalability
2S
Embedded options available
PCI Express CEM revision
3.0
Market segment
SRV
Harmonized System (HS) code
8542310001
Processor special features
Intel® Hyper Threading Technology (Intel® HT Technology)
<b>Improved Performance for Threaded Software</b>
Intel® Hyper-Threading Technology (Intel® HT Technology) makes efficient use of processor resources, enabling multiple threads to run on each core and increasing processor throughput. Available on Intel® Core™ and Intel® Xeon® processors, Intel HT Technology helps run demanding applications simultaneously, protect and manage systems, and provide headroom for business growth.
Intel® Turbo Boost Technology
<b>Higher Performance When You Need It Most</b>
Intel® Turbo Boost Technology 2.0 accelerates processor and graphics performance by increasing the operating frequency when operating below specification limits. The maximum frequency varies depending on workload, hardware, software, and overall system configuration.
2.0
Intel® AES New Instructions (Intel® AES-NI)
<b>Added Security with Faster Data Encryption</b>
The Intel® Advanced Encryption Standard New Instructions (Intel® AES-NI) enable fast and secure data encryption and decryption for better performance and less risk from timing and cache-based attacks than table-based software implementations. Intel AES-NI supports usages such as standard key lengths, standard modes of operation, and even some nonstandard or future variants.
Enhanced Intel SpeedStep Technology
Intel Trusted Execution Technology
Intel® Speed Shift Technology
Intel® Speed Shift Technology uses hardware-controlled P-states to deliver dramatically quicker responsiveness with single-threaded, transient (short duration) workloads, such as web browsing, by allowing the processor to more quickly select its best operating frequency and voltage for optimal performance and power efficiency.
Intel VT-x with Extended Page Tables (EPT)
Intel TSX-NI
Intel 64
Intel Virtualization Technology (VT-x)
<b>Simplify Virtualization and Reduce Overheads</b>
Intel® Virtualization Technology (Intel® VT) helps make virtualization practical by eliminating performance overheads, reducing complexity, and improving security with hardware assistance. Virtualization allows multiple workloads to share a common set of resources so that a variety of workloads can co-locate while maintaining full isolation from each other.
Intel Virtualization Technology for Directed I/O (VT-d)
<b>Simplify Virtualization and Reduce Overheads</b>
Intel® Virtualization Technology (Intel® VT) helps make virtualization practical by eliminating performance overheads, reducing complexity, and improving security with hardware assistance. Virtualization allows multiple workloads to share a common set of resources so that a variety of workloads can co-locate while maintaining full isolation from each other.
Intel TSX-NI version
1.00
Conflict-Free processor
"Conflict free" means "DRC conflict free", which is defined by the U.S. Securities and Exchange Commission rules to mean products that do not contain conflict minerals (tin, tantalum, tungsten and/or gold) that directly or indirectly finance or benefit armed groups in the Democratic Republic of the Congo (DRC) or adjoining countries.
Intel Turbo Boost Max Technology 3.0
Intel® Optane™ Memory Ready
AVX-512 Fused Multiply-Add (FMA) units
1
Mode-based Execute Control (MBE)
Intel® vPro™ Platform Eligibility
Operational conditions
Tcase
77 °C
Technical details
Born on date
Q3'17
Launch date
Q3'17
Processor cache
11264 KB
Product type
The sub-category of the product.
Processor
Status
Launched
Maximum memory
768 GB
Processor brand name
Intel Xeon Silver
Intel Xeon Silver Processor
Supported memory types
Types of memory which can be used with the product.
DDR4-2400
Last change
63903513
Product family
Intel Xeon Processors
Intel® Speed Shift Technology version
1.00
Intel® Volume Management Device (VMD) version
1.00
Memory speed (max)
2400 MHz
Mode-based Execute Control (MBE) version
1.00
Number of UPI links
2
Weight & dimensions
Package width
The distance from one side of the packaging to the other.
43 mm
Package depth
The distance from the front to the back of the packaging.
137 mm
Package height
The distance from the top to the bottom of the packaging.
112 mm
Package weight
Weight of the packaged product.
200 g
Processor package size
76.0 x 56.5 mm
Other features
Maximum internal memory
The maximum amount of memory inside a product, usually measured in bytes e.g megabytes (MB) or gigabytes (GB).
