Intel AES New Instructions (Intel AES NI) are a set of instructions that enable fast and secure data encryption and decryption. AES NI are valuable for a wide range of cryptographic applications, for example: applications that perform bulk encryption/decryption, authentication, random number generation, and authenticated encryption.
Intel Trusted Execution Technology for safer computing is a versatile set of hardware extensions to Intel processors and chipsets that enhance the digital office platform with security capabilities such as measured launch and protected execution. It enables an environment where applications can run within their own space, protected from all other software on the system.
Intel Virtualization Technology (VT x) allows one hardware platform to function as multiple "virtual platforms. It offers improved manageability by limiting downtime and maintaining productivity by isolating computing activities into separate partitions.
Processor
Processor manufacturer
The manufacturer that produced the processor.
Intel
Processor generation
1st Generation Intel® Xeon® Scalable
Processor model
The model number for the processor in a computer.
6138
Processor base frequency
2 GHz
Processor family
A family of processors is a group of processors produced by one company over a short period of time e.g. Intel Pentium processors.
Intel® Xeon® Gold
Processor cores
The number of central processing units ('cores') in a processor. Some processors have 1 core, others have 2 (e.g. Intel Core Duo) or more (e.g. the Intel Xeon E7-2850 has 10 cores).
20
Processor socket
Mechanical component(s) that provides mechanical and electrical connections between a microprocessor and a printed circuit board (PCB). This allows the processor to be replaced without soldering.
LGA 3647 (Socket P)
Component for
What this product is used as a part of (component for).
Server/workstation
Processor lithography
The process which is performed by the processor e.g. CPU (Central Processing Unit).
14 nm
Processor threads
40
Processor operating modes
Operating modes for the processors that place restrictions on the type and scope of operations for certain processes run by the CPU. This design allows the operating system to run with more privileges than application software.
64-bit
Processor boost frequency
The turbo boost is an automatic, managed accelleration of the processor when one of the cores is overloaded.
3.7 GHz
Processor cache
27.5 MB
Processor cache type
L3
Thermal Design Power (TDP)
125 W
Box
Plastic or metal shell/container for components.
Cooler included
The device comes with an integrated cooler.
Stepping
H0
Processor codename
Skylake
Processor code
SR3B5
Processor ARK ID
120476
Memory
Maximum internal memory supported by processor
768 GB
Memory types supported by processor
DDR4-SDRAM
Memory clock speeds supported by processor
2666 MHz
Memory channels
Hexa-channel
ECC
ECC means Error Correction Code, and it is memory that is able to detect and correct some memory errors without user intervention.
Graphics
On-board graphics card
Graphics hardware which is built into the motherboard or CPU, as opposed to a separate graphics adapter (video card). On-board graphics uses CPU and RAM for graphics processing.
Features
Execute Disable Bit
Market segment
Server
Maximum number of PCI Express lanes
48
PCI Express slots version
3.0
Supported instruction sets
AVX-512
Scalability
S4S
Embedded options available
PCI Express CEM revision
3.0
Export Control Classification Number (ECCN)
5A992C
Commodity Classification Automated Tracking System (CCATS)
G077159
Processor special features
Intel® Hyper Threading Technology (Intel® HT Technology)
<b>Improved Performance for Threaded Software</b>
Intel® Hyper-Threading Technology (Intel® HT Technology) makes efficient use of processor resources, enabling multiple threads to run on each core and increasing processor throughput. Available on Intel® Core™ and Intel® Xeon® processors, Intel HT Technology helps run demanding applications simultaneously, protect and manage systems, and provide headroom for business growth.
Intel® Turbo Boost Technology
<b>Higher Performance When You Need It Most</b>
Intel® Turbo Boost Technology 2.0 accelerates processor and graphics performance by increasing the operating frequency when operating below specification limits. The maximum frequency varies depending on workload, hardware, software, and overall system configuration.
2.0
Intel® AES New Instructions (Intel® AES-NI)
<b>Added Security with Faster Data Encryption</b>
The Intel® Advanced Encryption Standard New Instructions (Intel® AES-NI) enable fast and secure data encryption and decryption for better performance and less risk from timing and cache-based attacks than table-based software implementations. Intel AES-NI supports usages such as standard key lengths, standard modes of operation, and even some nonstandard or future variants.
Enhanced Intel SpeedStep Technology
Intel Trusted Execution Technology
Intel® Speed Shift Technology
Intel® Speed Shift Technology uses hardware-controlled P-states to deliver dramatically quicker responsiveness with single-threaded, transient (short duration) workloads, such as web browsing, by allowing the processor to more quickly select its best operating frequency and voltage for optimal performance and power efficiency.
Intel® Transactional Synchronization Extensions
Intel VT-x with Extended Page Tables (EPT)
Intel TSX-NI
Intel 64
Intel Virtualization Technology (VT-x)
<b>Simplify Virtualization and Reduce Overheads</b>
Intel® Virtualization Technology (Intel® VT) helps make virtualization practical by eliminating performance overheads, reducing complexity, and improving security with hardware assistance. Virtualization allows multiple workloads to share a common set of resources so that a variety of workloads can co-locate while maintaining full isolation from each other.
Intel Virtualization Technology for Directed I/O (VT-d)
<b>Simplify Virtualization and Reduce Overheads</b>
Intel® Virtualization Technology (Intel® VT) helps make virtualization practical by eliminating performance overheads, reducing complexity, and improving security with hardware assistance. Virtualization allows multiple workloads to share a common set of resources so that a variety of workloads can co-locate while maintaining full isolation from each other.
Intel TSX-NI version
1.00
Conflict-Free processor
"Conflict free" means "DRC conflict free", which is defined by the U.S. Securities and Exchange Commission rules to mean products that do not contain conflict minerals (tin, tantalum, tungsten and/or gold) that directly or indirectly finance or benefit armed groups in the Democratic Republic of the Congo (DRC) or adjoining countries.
Intel Turbo Boost Max Technology 3.0
Intel® Optane™ Memory Ready
AVX-512 Fused Multiply-Add (FMA) units
2
Intel® Volume Management Device (VMD)
Intel® Run Sure Technology
Mode-based Execute Control (MBE)
Intel® vPro™ Platform Eligibility
Operational conditions
Tcase
86 °C
Technical details
Launch date
Q3'17
Processor cache
28160 KB
Product type
The sub-category of the product.
Processor
Status
Launched
Maximum memory
768 GB
Processor brand name
Intel Xeon Gold
Intel Xeon Gold Processor
Supported memory types
Types of memory which can be used with the product.
DDR4-SDRAM
Last change
63903513
Product family
Intel Xeon Processors
Intel® Speed Shift Technology version
1.00
Intel® Run Sure Technology version
1.00
Intel® Volume Management Device (VMD) version
1.00
Memory speed (max)
2666 MHz
Mode-based Execute Control (MBE) version
1.00
Number of UPI links
3
Servicing status
ESU Notification Issued
End of servicing updates date
Sunday, December 31, 2023
Logistics data
Harmonized System (HS) code
85423119
Packaging data
Package type
The type of product package e.g. box.
Retail box
Weight & dimensions
Processor package size
76mm x 56.5mm
Other features
Maximum internal memory
The maximum amount of memory inside a product, usually measured in bytes e.g megabytes (MB) or gigabytes (GB).
