Intel Xeon Gold 6430, Intel Xeon Gold, LGA 4677 (Socket E), Intel, 2.1 GHz, 64 bit, Intel Xeon Scalable 4th Gen
Intel Trusted Execution Technology
Intel Trusted Execution Technology for safer computing is a versatile set of hardware extensions to Intel processors and chipsets that enhance the digital office platform with security capabilities such as measured launch and protected execution. It enables an environment where applications can run within their own space, protected from all other software on the system.
Intel Virtualization Technology for Directed I/O (VT d)
Intel Virtualization Technology for Directed I/O (VT d) continues from the existing support for IA 32 (VT x) and Itanium processor (VT i) virtualization adding new support for I/O device virtualization. Intel VT d can help end users improve security and reliability of the systems and also improve performance of I/O devices in virtualized environments.
Intel Virtualization Technology (VT x)
Intel Virtualization Technology (VT x) allows one hardware platform to function as multiple "virtual platforms. It offers improved manageability by limiting downtime and maintaining productivity by isolating computing activities into separate partitions.
Intel 64
Intel 64 architecture delivers 64 bit computing on server, workstation, desktop and mobile platforms when combined with supporting software.1 Intel 64 architecture improves performance by allowing systems to address more than 4 GB of both virtual and physical memory.
Cache
CPU Cache is an area of fast memory located on the processor. Intel Smart Cache refers to the architecture that allows all cores to dynamically share access to the last level cache.
Intel AES New Instructions
Intel AES New Instructions (Intel AES NI) are a set of instructions that enable fast and secure data encryption and decryption. AES NI are valuable for a wide range of cryptographic applications, for example: applications that perform bulk encryption/decryption, authentication, random number generation, and authenticated encryption.
Intel Turbo Boost Technology
Intel Turbo Boost Technology dynamically increases the processor's frequency as needed by taking advantage of thermal and power headroom to give you a burst of speed when you need it, and increased energy efficiency when you don
Intel Trusted Execution Technology for safer computing is a versatile set of hardware extensions to Intel processors and chipsets that enhance the digital office platform with security capabilities such as measured launch and protected execution. It enables an environment where applications can run within their own space, protected from all other software on the system.
Intel Virtualization Technology for Directed I/O (VT d)
Intel Virtualization Technology for Directed I/O (VT d) continues from the existing support for IA 32 (VT x) and Itanium processor (VT i) virtualization adding new support for I/O device virtualization. Intel VT d can help end users improve security and reliability of the systems and also improve performance of I/O devices in virtualized environments.
Intel Virtualization Technology (VT x)
Intel Virtualization Technology (VT x) allows one hardware platform to function as multiple "virtual platforms. It offers improved manageability by limiting downtime and maintaining productivity by isolating computing activities into separate partitions.
Intel 64
Intel 64 architecture delivers 64 bit computing on server, workstation, desktop and mobile platforms when combined with supporting software.1 Intel 64 architecture improves performance by allowing systems to address more than 4 GB of both virtual and physical memory.
Cache
CPU Cache is an area of fast memory located on the processor. Intel Smart Cache refers to the architecture that allows all cores to dynamically share access to the last level cache.
Intel AES New Instructions
Intel AES New Instructions (Intel AES NI) are a set of instructions that enable fast and secure data encryption and decryption. AES NI are valuable for a wide range of cryptographic applications, for example: applications that perform bulk encryption/decryption, authentication, random number generation, and authenticated encryption.
Intel Turbo Boost Technology
Intel Turbo Boost Technology dynamically increases the processor's frequency as needed by taking advantage of thermal and power headroom to give you a burst of speed when you need it, and increased energy efficiency when you don
| Processor | |
| Processor manufacturer The manufacturer that produced the processor. | Intel |
| Processor generation | Intel Xeon Scalable 4th Gen |
| Processor model The model number for the processor in a computer. | 6430 |
| Processor base frequency | 2.1 GHz |
| Processor family A family of processors is a group of processors produced by one company over a short period of time e.g. Intel Pentium processors. | Intel® Xeon® Gold |
| Processor cores The number of central processing units ('cores') in a processor. Some processors have 1 core, others have 2 (e.g. Intel Core Duo) or more (e.g. the Intel Xeon E7-2850 has 10 cores). | 32 |
| Processor socket Mechanical component(s) that provides mechanical and electrical connections between a microprocessor and a printed circuit board (PCB). This allows the processor to be replaced without soldering. | LGA 4677 (Socket E) |
| Processor threads | 64 |
| System bus rate A bus is a communication system that transfers data between components inside a computer, or between computers. The system bus rate is the speed at which data is transferred in this communication system. | 16 GT/s |
| Processor operating modes Operating modes for the processors that place restrictions on the type and scope of operations for certain processes run by the CPU. This design allows the operating system to run with more privileges than application software. | 64-bit |
| Processor boost frequency The turbo boost is an automatic, managed accelleration of the processor when one of the cores is overloaded. | 3.4 GHz |
| High priority cores | 12 |
| High priority core frequency | 2.2 GHz |
| Low priority cores | 20 |
| Low priority core frequency | 1.8 GHz |
| Processor cache | 60 MB |
| Thermal Design Power (TDP) | 270 W |
| Box Plastic or metal shell/container for components. |
 |
| Stepping | E5 |
| Processor codename | Sapphire Rapids |
| Processor ARK ID | 231737 |
| Memory | |
| Maximum internal memory supported by processor | 6 TB |
| Memory types supported by processor | DDR5-SDRAM |
| Memory channels | Octa-channel |
| ECC ECC means Error Correction Code, and it is memory that is able to detect and correct some memory errors without user intervention. |
|
| Graphics | |
| On-board graphics card Graphics hardware which is built into the motherboard or CPU, as opposed to a separate graphics adapter (video card). On-board graphics uses CPU and RAM for graphics processing. |
 |
| Discrete graphics card |
|
| On-board graphics card model "Graphic adapter" is the hardware that produces images on a display. "On-board" means that the graphics adapter is intergrated inside the motherboard. | Not available |
| Discrete graphics card model A graphics adapter (often known as a video card) generates images for a display. A discrete graphics adapter plugs into the motherboard, and usually produces much better graphics than an integrated graphics adapter. There are various models of discrete graphics adapters. | Not available |
| Features | |
| Execute Disable Bit |
|
| Market segment | Server |
| Use conditions | Server/Enterprise |
| Maximum number of PCI Express lanes | 80 |
| PCI Express slots version | 5.0 |
| Supported instruction sets | AMX, SSE4.2, AVX, AVX 2.0, AVX-512 |
| Scalability | 2S |
| Embedded options available |
|
| Export Control Classification Number (ECCN) | 5A992C |
| Commodity Classification Automated Tracking System (CCATS) | G180729 |
| Processor special features | |
| Intel® Hyper Threading Technology (Intel® HT Technology) <b>Improved Performance for Threaded Software</b> Intel® Hyper-Threading Technology (Intel® HT Technology) makes efficient use of processor resources, enabling multiple threads to run on each core and increasing processor throughput. Available on Intel® Core™ and Intel® Xeon® processors, Intel HT Technology helps run demanding applications simultaneously, protect and manage systems, and provide headroom for business growth. |
|
| Intel® Turbo Boost Technology <b>Higher Performance When You Need It Most</b> Intel® Turbo Boost Technology 2.0 accelerates processor and graphics performance by increasing the operating frequency when operating below specification limits. The maximum frequency varies depending on workload, hardware, software, and overall system configuration. | 2.0 |
| Intel® AES New Instructions (Intel® AES-NI) <b>Added Security with Faster Data Encryption</b> The Intel® Advanced Encryption Standard New Instructions (Intel® AES-NI) enable fast and secure data encryption and decryption for better performance and less risk from timing and cache-based attacks than table-based software implementations. Intel AES-NI supports usages such as standard key lengths, standard modes of operation, and even some nonstandard or future variants. |
|
| Intel Trusted Execution Technology |
|
| Intel® Speed Shift Technology Intel® Speed Shift Technology uses hardware-controlled P-states to deliver dramatically quicker responsiveness with single-threaded, transient (short duration) workloads, such as web browsing, by allowing the processor to more quickly select its best operating frequency and voltage for optimal performance and power efficiency. |
|
| Intel® Transactional Synchronization Extensions |
|
| Intel® Total Memory Encryption |
|
| Intel® Control-flow Enforcement Technology (CET) |
|
| Intel® Crypto Acceleration |
|
| Intel® Platform Firmware Resilience Support |
|
| Maximum Enclave Size Support for Intel® SGX | 128 GB |
| Intel VT-x with Extended Page Tables (EPT) |
|
| Intel® OS Guard <b>Protect Your Operating Environment</b> Intel® OS Guard, a hardware-based security feature that protects the operating system kernel, defends against malicious data or attack code located in areas of memory marked as user mode pages, preventing any application from taking over or compromising the OS kernel. |
|
| Intel Software Guard Extensions (Intel SGX) |
|
| Intel 64 |
|
| Intel Virtualization Technology (VT-x) <b>Simplify Virtualization and Reduce Overheads</b> Intel® Virtualization Technology (Intel® VT) helps make virtualization practical by eliminating performance overheads, reducing complexity, and improving security with hardware assistance. Virtualization allows multiple workloads to share a common set of resources so that a variety of workloads can co-locate while maintaining full isolation from each other. |
|
| Intel Virtualization Technology for Directed I/O (VT-d) <b>Simplify Virtualization and Reduce Overheads</b> Intel® Virtualization Technology (Intel® VT) helps make virtualization practical by eliminating performance overheads, reducing complexity, and improving security with hardware assistance. Virtualization allows multiple workloads to share a common set of resources so that a variety of workloads can co-locate while maintaining full isolation from each other. |
|
| AVX-512 Fused Multiply-Add (FMA) units | 2 |
| Intel® Boot Guard Intel® Device Protection Technology with Boot Guard helps protect the system’s pre-OS environment from viruses and malicious software attacks. |
|
| Intel® Deep Learning Boost (Intel® DL Boost) |
|
| Intel® Resource Director Technology (Intel® RDT) |
|
| Intel® Run Sure Technology |
|
| Mode-based Execute Control (MBE) |
|
| Intel® Optane™ DC Persistent Memory Supported |
|
| Intel® Speed Select Technology - Base Frequency (Intel® SST-BF) |
|
| Intel® QuickAssist Software Acceleration |
|
| Intel® On Demand Feature Activation |
|
| Intel® Data Streaming Accelerator (DSA) | 1 default devices |
| Intel® Advanced Matrix Extensions (AMX) |
|
| Operational conditions | |
| Tcase | 72 °C |
| DTS Max | 90 °C |
| Technical details | |
| Launch date | Q1'23 |
| Status | Launched |
| Supported memory types Types of memory which can be used with the product. | DDR5-SDRAM |
| Memory speed (max) | 4400 MHz |
| Number of UPI links | 3 |
| Package carrier | E1A |
| Logistics data | |
| Harmonized System (HS) code | 8542310001 |
| Packaging data | |
| Package type The type of product package e.g. box. | Retail box |
| Weight & dimensions | |
| Processor package size | 77.5 x 56.5 mm |
| Other features | |
| Maximum internal memory The maximum internal memory which is available in the product. | 4 TB |
| SKU | 750629 |
| MPN | BX807136430 |
| Brand | Intel |
| Product Condition | Brand New/Unused |
| Product Use | General |
