Processor manufacturer
The manufacturer that produced the processor.
Intel
Processor generation
Intel Xeon Scalable 5th Gen
Processor model
The model number for the processor in a computer.
4516Y+
Processor base frequency
2.2 GHz
Processor family
A family of processors is a group of processors produced by one company over a short period of time e.g. Intel Pentium processors.
Intel Xeon Silver
Processor cores
The number of central processing units ('cores') in a processor. Some processors have 1 core, others have 2 (e.g. Intel Core Duo) or more (e.g. the Intel Xeon E7-2850 has 10 cores).
24
Processor socket
Mechanical component(s) that provides mechanical and electrical connections between a microprocessor and a printed circuit board (PCB). This allows the processor to be replaced without soldering.
FCLGA4677
Processor threads
48
Intel® UPI Speed
16 GT/s
Processor operating modes
Operating modes for the processors that place restrictions on the type and scope of operations for certain processes run by the CPU. This design allows the operating system to run with more privileges than application software.
64-bit
Processor boost frequency
The turbo boost is an automatic, managed accelleration of the processor when one of the cores is overloaded.
3.7 GHz
Processor cache
45 MB
Thermal Design Power (TDP)
185 W
Box
Plastic or metal shell/container for components.
Stepping
R1
Processor codename
Emerald Rapids
Processor ARK ID
237556
Memory
Maximum internal memory supported by processor
4 TB
Memory types supported by processor
DDR5-SDRAM
Memory channels
Octa-channel
ECC
ECC means Error Correction Code, and it is memory that is able to detect and correct some memory errors without user intervention.
Graphics
On-board graphics card
Graphics hardware which is built into the motherboard or CPU, as opposed to a separate graphics adapter (video card). On-board graphics uses CPU and RAM for graphics processing.
Discrete graphics card
On-board graphics card model
"Graphic adapter" is the hardware that produces images on a display. "On-board" means that the graphics adapter is intergrated inside the motherboard.
Not available
Discrete graphics card model
A graphics adapter (often known as a video card) generates images for a display. A discrete graphics adapter plugs into the motherboard, and usually produces much better graphics than an integrated graphics adapter. There are various models of discrete graphics adapters.
Not available
Features
Execute Disable Bit
Market segment
Server
Use conditions
Server/Enterprise
Maximum number of PCI Express lanes
80
PCI Express slots version
5.0
Supported instruction sets
AMX, AVX, AVX 2.0, AVX-512, SSE4.2
Scalability
2S
Embedded options available
Export Control Classification Number (ECCN)
5A992C
Commodity Classification Automated Tracking System (CCATS)
740.17B1
Processor special features
Intel® Hyper Threading Technology (Intel® HT Technology)
<b>Improved Performance for Threaded Software</b>
Intel® Hyper-Threading Technology (Intel® HT Technology) makes efficient use of processor resources, enabling multiple threads to run on each core and increasing processor throughput. Available on Intel® Core™ and Intel® Xeon® processors, Intel HT Technology helps run demanding applications simultaneously, protect and manage systems, and provide headroom for business growth.
Intel® Turbo Boost Technology
<b>Higher Performance When You Need It Most</b>
Intel® Turbo Boost Technology 2.0 accelerates processor and graphics performance by increasing the operating frequency when operating below specification limits. The maximum frequency varies depending on workload, hardware, software, and overall system configuration.
2.0
Intel® AES New Instructions (Intel® AES-NI)
<b>Added Security with Faster Data Encryption</b>
The Intel® Advanced Encryption Standard New Instructions (Intel® AES-NI) enable fast and secure data encryption and decryption for better performance and less risk from timing and cache-based attacks than table-based software implementations. Intel AES-NI supports usages such as standard key lengths, standard modes of operation, and even some nonstandard or future variants.
Intel Trusted Execution Technology
Intel® Speed Shift Technology
Intel® Speed Shift Technology uses hardware-controlled P-states to deliver dramatically quicker responsiveness with single-threaded, transient (short duration) workloads, such as web browsing, by allowing the processor to more quickly select its best operating frequency and voltage for optimal performance and power efficiency.
Intel® Transactional Synchronization Extensions
Intel® Total Memory Encryption
Intel® Control-flow Enforcement Technology (CET)
Intel® Crypto Acceleration
Intel® Platform Firmware Resilience Support
Maximum Enclave Size Support for Intel® SGX
64 GB
Intel VT-x with Extended Page Tables (EPT)
Intel® OS Guard
<b>Protect Your Operating Environment</b>
Intel® OS Guard, a hardware-based security feature that protects the operating system kernel, defends against malicious data or attack code located in areas of memory marked as user mode pages, preventing any application from taking over or compromising the OS kernel.
Intel Software Guard Extensions (Intel SGX)
Intel 64
Intel Virtualization Technology (VT-x)
<b>Simplify Virtualization and Reduce Overheads</b>
Intel® Virtualization Technology (Intel® VT) helps make virtualization practical by eliminating performance overheads, reducing complexity, and improving security with hardware assistance. Virtualization allows multiple workloads to share a common set of resources so that a variety of workloads can co-locate while maintaining full isolation from each other.
Intel Virtualization Technology for Directed I/O (VT-d)
<b>Simplify Virtualization and Reduce Overheads</b>
Intel® Virtualization Technology (Intel® VT) helps make virtualization practical by eliminating performance overheads, reducing complexity, and improving security with hardware assistance. Virtualization allows multiple workloads to share a common set of resources so that a variety of workloads can co-locate while maintaining full isolation from each other.
AVX-512 Fused Multiply-Add (FMA) units
2
Intel® Boot Guard
Intel® Device Protection Technology with Boot Guard helps protect the system’s pre-OS environment from viruses and malicious software attacks.
Intel® Deep Learning Boost (Intel® DL Boost) on CPU
Intel® Resource Director Technology (Intel® RDT)
Intel® Volume Management Device (VMD)
Mode-based Execute Control (MBE)
Intel® Total Memory Encryption - Multi Key
Intel® QuickAssist Software Acceleration
Intel® On Demand Feature Activation
Intel® QuickAssist Technology (QAT)
1 default devices
Intel® Dynamic Load Balancer (DLB)
1 default devices
Intel® Data Streaming Accelerator (DSA)
1 default devices
Intel® In-memory Analytics Accelerator (IAA)
1 default devices
Intel® Advanced Matrix Extensions (AMX)
Intel® Speed Select Technology – Core Power
Operational conditions
Tcase
81 °C
DTS Max
90 °C
Technical details
Launch date
Q4'23
Status
Launched
Number of UPI links
2
Package carrier
E1B
Servicing status
Baseline Servicing
Logistics data
Harmonized System (HS) code
8542310001
Weight & dimensions
Processor package size
77.5 x 56.5 mm
Other features
Maximum internal memory
The maximum internal memory which is available in the product.
