Intel X710T4L, Internal, PCI Express
iWARP/RDMA
iWARP delivers converged, low latency fabric services to data centers through Remote Direct Memory Access (RDMA) over Ethernet. The key iWARP components that deliver low latency are Kernel Bypass, Direct Data Placement, and Transport Acceleration.
Intel Data Direct I/O Technology
Intel Data Direct I/O Technology is a platform technology that improves I/O data processing efficiency for data delivery and data consumption from I/O devices. With Intel DDIO, Intel Server Adapters and controllers talk directly to the processor cache without a detour via system memory, reducing latency, increasing system I/O bandwidth, and reducing power consumption.
PCI SIG* SR IOV Capable
Single Root I/O Virtualization (SR IOV) involves natively (directly) sharing a single I/O resource between multiple virtual machines. SR IOV provides a mechanism by which a Single Root Function (for example a single Ethernet Port) can appear to be multiple separate physical devices.
Flexible Port Partitioning
Flexible Port Partitioning (FPP) technology utilizes industry standard PCI SIG SR IOV to efficiently divide your physical Ethernet device into multiple virtual devices, providing Quality of Service by ensuring each process is assigned to a Virtual Function and is provided a fair share of the bandwidth.
Virtual Machine Device Queues (VMDq)
Virtual Machine Device Queues (VMDq) is a technology designed to offload some of the switching done in the VMM (Virtual Machine Monitor) to networking hardware specifically designed for this function. VMDq drastically reduces overhead associated with I/O switching in the VMM which greatly improves throughput and overall system performance
iWARP delivers converged, low latency fabric services to data centers through Remote Direct Memory Access (RDMA) over Ethernet. The key iWARP components that deliver low latency are Kernel Bypass, Direct Data Placement, and Transport Acceleration.
Intel Data Direct I/O Technology
Intel Data Direct I/O Technology is a platform technology that improves I/O data processing efficiency for data delivery and data consumption from I/O devices. With Intel DDIO, Intel Server Adapters and controllers talk directly to the processor cache without a detour via system memory, reducing latency, increasing system I/O bandwidth, and reducing power consumption.
PCI SIG* SR IOV Capable
Single Root I/O Virtualization (SR IOV) involves natively (directly) sharing a single I/O resource between multiple virtual machines. SR IOV provides a mechanism by which a Single Root Function (for example a single Ethernet Port) can appear to be multiple separate physical devices.
Flexible Port Partitioning
Flexible Port Partitioning (FPP) technology utilizes industry standard PCI SIG SR IOV to efficiently divide your physical Ethernet device into multiple virtual devices, providing Quality of Service by ensuring each process is assigned to a Virtual Function and is provided a fair share of the bandwidth.
Virtual Machine Device Queues (VMDq)
Virtual Machine Device Queues (VMDq) is a technology designed to offload some of the switching done in the VMM (Virtual Machine Monitor) to networking hardware specifically designed for this function. VMDq drastically reduces overhead associated with I/O switching in the VMM which greatly improves throughput and overall system performance
| Ports & interfaces | |
| Host interface Interface that enables a host controller to communicate with a driver. | PCI Express |
| Ethernet LAN (RJ-45) ports Number of Ethernet LAN (RJ-45) ports (connecting interfaces) in the device. Ethernet LAN (RJ-45) ports allow a computer to connect to the ethernet. | 4 |
| PCI version | 3.0 |
| Network | |
| Maximum operating distance The maximum distance from which you can operate the device. | 100 m |
| LAN controller | Intel X710-TM4 |
| Design | |
| Internal The product is built in. |
 |
| System requirements | |
| Compatible operating systems List of desktop operating systems tested as compatible with this product. | https://www.intel.com/content/www/us/en/support/articles/000025890/network-and-i-o/ethernet-products.html |
| Logistics data | |
| Harmonized System (HS) code | 85176990 |
| Other features | |
| Cable type Type of cable e.g. electicity cable, optical cable. | RJ45 Category 6, Category 6A, Category 5e up to 100m |
| Market segment | Server |
| Target market | Artificial Intelligence, High Performance Computing |
| Intel Virtual Machine Device Queues (VMDq) |
|
| PCI-SIG* SR-IOV Capable |
|
| On-chip QoS and Traffic Management |
|
| Intel Flexible Port Partitioning |
|
| Speed & slot width | 8.0 GT/s, x8 Lane |
| Intelligent Offloads |
|
| iWARP/RDMA |
 |
| Intel Data Direct I/O Technology |
|
| Intel Virtualization Technology for Connectivity (VT-c) <b>Simplify Virtualization and Reduce Overheads</b> Intel® Virtualization Technology (Intel® VT) helps make virtualization practical by eliminating performance overheads, reducing complexity, and improving security with hardware assistance. Virtualization allows multiple workloads to share a common set of resources so that a variety of workloads can co-locate while maintaining full isolation from each other. |
|
| Interface type | PCIe v3.0 (8.0GT/s) |
| Storage Over Ethernet | iSCSI, NFS |
| Launch date | Q3'20 |
| Network interface card cable medium | Copper |
| Network interface card type | Server |
| Product brief URL | https://www.intel.com/content/www/us/en/products/docs/network-io/ethernet/network-adapters/ethernet-adapter-x710-t2l-t4l-brief.html |
| Product type The sub-category of the product. | Network Interface Card |
| Status | Launched |
| Processor family A family of processors is a group of processors produced by one company over a short period of time e.g. Intel Pentium processors. | 700 Network Adapters (up to 40GbE)-700 Network Adapters (up to 40GbE) |
| Export Control Classification Number (ECCN) | 5A991 |
| Commodity Classification Automated Tracking System (CCATS) | NA |
| Controller type | Intel® Ethernet Controller X710-TM4 |
| Cabling type | RJ45 Category 6, Category 6A, Category 5e up to 100m |
| Bracket height | Low-Profile (LP) / Full-Height (FH) |
| Product series | 700 Series Network Adapters (up to 40GbE) |
| SKU | 750758 |
| MPN | X710T4L |
| Brand | Intel |
| Product Condition | Brand New/Unused |
| Stock Availability | Available for Shipping |
| Product Use | General |
| Warranty Period | 1 Year Warranty |
| Warranty Contact | https://www.intel.com.au/ |
