Intel Server System LR1304SPCFG1R
Intel LR1304SPCFG1R. Motherboard chipset: Intel C236, Motherboard form factor: Micro ATX, Maximum internal memory supported by processor: 64 GB. Market segment: SRV. Chassis type: Rack (1U), Heat sink: F1UE3PASSHS. Power supply: 450 W, Power supply type: AC. Packaging content: This product is an indirect replacement for LR1304SPCFG1.PLEASE NOTE: LR1304SPCFG1R does not...
| Processor | |
| Motherboard chipset The chipset connects the microprocessor to the rest of the motherboard. | Intel® C236 |
| Motherboard form factor Design of the motherboard (ATX, BTX etc). | Micro ATX |
| Maximum internal memory supported by processor | 64 GB |
| Memory | |
| Number of DIMM slots The number of places where DIMMs can be connected. A DIMM or dual in-line memory module comprises a series of dynamic random-access memory integrated circuits. These modules are mounted on a printed circuit board and designed for use in personal computers, workstations and servers. DIMMs began to replace SIMMs (single in-line memory modules) as the predominant type of memory module as Intel P5-based Pentium processors began to gain market share. | 16 |
| Storage | |
| Number of storage drives supported How many storage drives can be fit into the product at once. | 4 |
| Number of 3.5" bays A drive bay is a standard-area for adding hardware to a computer. Most drive bays are fixed to the inside of a case, but some can be removed. A 3.5" drive bay is for floppy disks. | 4 |
| Ports & interfaces | |
| USB ports quantity | 9 |
| Ethernet LAN (RJ-45) ports Number of Ethernet LAN (RJ-45) ports (connecting interfaces) in the device. Ethernet LAN (RJ-45) ports allow a computer to connect to the ethernet. | 2 |
| Serial ports quantity The number of serial ports in a computer or peripheral. A serial port is a serial communication physical interface through which information transfers in or out one bit at a time. The term "serial port" usually identifies hardware more or less compliant to the RS-232 standard, intended to interface with a modem or with a similar communication device. In modern computers and peripherals, serial ports have largely been replaced by USBs and other interfaces. | 1 |
| Number of SATA connectors | 8 |
| Features | |
| Trusted Platform Module (TPM) version | 2.0 |
| Intel Node Manager |
 |
| Backplanes | Included |
| Market segment | SRV |
| Harmonized System (HS) code | 8471500150 |
| ARK ID | 99764 |
| Processor special features | |
| Intel I/O Acceleration Technology |
|
| Intel Rapid Storage Technology enterprise |
|
| Intel Remote Management Module Support |
|
| Intel Intelligent Power Node Manager |
|
| Connector for Intel I/O Expansion Module x8 Gen 3 | 1 |
| Internal I/O Expansion Module x8 Gen 3 | 1 |
| Design | |
| Chassis type The type of rigid framework onto which is the hosuing for device components. | Rack (1U) |
| Rack rails |
 |
| Rack-Friendly board |
|
| Heat sink included |
|
| Heat sink | F1UE3PASSHS |
| Power | |
| Power supply type The type of power supply which this product uses. | AC |
| Power supply The way in which the product is powered e.g. rechargeable battery, mains electricity connected via a plug and cable. | 450 W |
| Redundant power supply (RPS) support Additional power supply which can run a computer if the main power supply fails. |
|
| Number of power supply units | 2 |
| Packaging data | |
| Packaging content | This product is an indirect replacement for LR1304SPCFG1.PLEASE NOTE: LR1304SPCFG1R does not include a hard drive, contains 16GB RAM, and contains some additional configuration changes.---- Prior Product Configuration ----(1) E3-1230 v6 (1) Intel Server Board S1200SPOR(1) Riser card assembly (AXX1UPCIEX16R2)(2) 450W redundant power supply(1) Power Distribution Board(4) 3.5 inch Hot-swap drive bays(4) 3.5 inch Hot-swap drive trays (FXX35HSCAR)(1) 12Gb SAS Backplane (FR1304S3HSBP)(1) SATA data cable(1) Backplane 12C cable(1) SATA ODD data cable(1) SAS Data cable(3) System fans(1) Standard control panel assembly(1) Front Q/O Pannel assembly (1 x VGA & 2 x USB)(1) SATA Optical drive bay with filler panel(2) Chassis handles -installed(1) 16GB DDR4 DIMM |
| Other features | |
| CPU configuration (max) | 1 |
| On-board graphics adapter Graphics hardware which is built into the motherboard or CPU, as opposed to a separate graphics adapter (video card). On-board graphics uses CPU and RAM for graphics processing. |
|
| 3.5" HDD support | Hot-swap 3.5" HDD or 2.5" SSD |
| Chassis dimensions | 438.4 x 605.5 x 43.2 mm (17.3 x 23.8 x 1.7") |
| Expected discontinuance date | Q3'20 |
| Extended warranty available for purchase (select countries) |
|
| Included riser slot 1 configuration(s) | 1x PCIe Gen3 x8 |
| Last change | 63903513 |
| Launch date | Q1'17 |
| Number of storage drives supported (internal) | 1 |
| Optical drive supported |
|
| Redundant fans |
|
| Riser slot 1 number of lanes | 8 |
| Status | Launched |
| Supported RAID configuration | Software RAID RSTe (0,1,10,5) and ESRT2 (0,1,10) |
| Supported board | Intel Server Board S1200SPOR |
| Supported storage drives form factor (internal) | M.2 SSD |
| Target market | Small and Medium Business |
| Maximum memory | 64 GB |
| Product type The sub-category of the product. | System |
| Product family | 1U server system |
| SKU | 446132 |
| MPN | LR1304SPCFG1R |
| Brand | Intel |
| Product Condition | Brand New/Unused |
| Product Use | General |
