Hikvision D6065UN 65" 4K UHD Digital Signage Display

Display
LED backlighting type Backlighting is the illumination of a screen e.g. LCD (liquid crystal display). There are several types of backlighting with LEDs, e.g. full array, edge lit.	Direct-LED
Display diagonal Size of the display for this product, measured diagonally, usually in inches.	165.1 cm (65")
Display technology The technology used in the display e.g. plasma, LED.	LED
Display resolution The number of distinct pixels in each dimension that can be displayed. It is usually quoted as width × height, with the units in pixels: for example, "1024 × 768" means the width is 1024 pixels and the height is 768 pixels. The higher the number of pixels, the sharper the image.	3840 x 2160 pixels
Display brightness Brightness is the amount of radiating light emitted from the screen. The brightness rating is measured in candellas per square meter, commonly known as 'nits'.	500 cd/m²
HD type Type of supported High Definition (e.g. Full HD, 4K Ultra HD).	4K Ultra HD
Touchscreen A screen of a laptop, smartphone, etc., that responds to touch so you can control the interface using your fingers.
Native aspect ratio The aspect ratio is the ratio of the width of an image to its height. The native aspect ratio is the one which the projector/display is particularly designed for. Images shown in native aspect ratio will utilize the entire resolution of the display and achieve maximum brightness. Images shown in other than native aspect ratio will always have less resolution and less brightness than images shown in native aspect ratio.	16:9
Response time The response time is the time difference between the moment that a source (for example a video card) sends a signal and that equipment (for example a monitor) receives or display the signal. (Used abbreviations: R/F = Rise and Fall.)	8 ms
Contrast ratio (typical) The difference in light intensity between the brightest white and the darkest black.	1200:1
Viewing angle, horizontal Maximum horizontal angle at which a display can be viewed with acceptable visual performance.	178°
Viewing angle, vertical Maximum vertical angle at which a display can be viewed with acceptable visual performance.	178°
Display number of colours	1.07 billion colours
Pixel pitch This is the parameter of a picture tube, which specifies the shortest distance between two dots of the same colour. The principle is: the smaller the dot pitch, the better sharpness of image.	0.372 x 0.372 mm
Active display area (W x H)	1428.48 x 803.52 mm
Colour depth	8 bit
Native refresh rate	60 Hz
Colour gamut	72%

Ports & interfaces
HDMI ports quantity The number of sockets (ports) for HDMI connections. HDMI (High-Definition Multimedia Interface) is a compact audio/video interface for transferring uncompressed video data and compressed/uncompressed digital audio data from a HDMI-compliant device ("the source device") to a compatible computer monitor, video projector, digital television, or digital audio device. HDMI is a digital replacement for existing analog video standards.	2
HDMI version	2.0
DVI port Digital Visual Interface (DVI) is a video display interface to connect a video source to a display device, such as a computer monitor.
DVI-I ports quantity This is the amount of DVI-I interfaces. Digital Visual Interface (DVI) is a video display interface developed by the Digital Display Working Group (DDWG). The digital interface is used to connect a video source to a display device, such as a computer monitor. DVI-I is DVI integrated, which means it can support digital and analog.	1
DisplayPorts quantity Number of DisplayPorts. A DisplayPort is a digital display interface developed by the Video Electronics Standards Association (VESA). The interface is primarily used to connect a video source to a display device such as a computer monitor, though it can also be used to carry audio, USB, and other forms of data.	2
DisplayPorts in	1
DisplayPorts out	1
USB port The device features a socket into which a USB cable can be plugged.
USB ports quantity	2
USB version Universal Serial Bus (USB) is an industry standard developed in the mid-1990s that defines the interface used for connection, communication and power supply between computers and electronic devices. Every new version - for example 1.1, 2.0, 3.0 - is much faster than the previous one.	2.0
Ethernet LAN (RJ-45) ports Number of Ethernet LAN (RJ-45) ports (connecting interfaces) in the device. Ethernet LAN (RJ-45) ports allow a computer to connect to the ethernet.	1
PC Audio in The socket (port) for the PC audio input.
Card reader integrated A card reader is a device that enables reading and, in some cases, writing data to and from a memory card.
Compatible memory cards Types of memory cards which can be used with this product.	MicroSD (TransFlash)
PC Audio out

Audio
Built-in speaker(s) The device contains speaker(s) to produce sound.
Number of built-in speakers	2
RMS rated power RMS (Root mean square) is a measure of the continuous power required by a device, in particular audio amplifiers and loudspeakers.	20 W

Design
Product design The creation of a plan or convention for the construction of an object or a system.	Digital signage flat panel
Placement supported Where the product can be placed e.g. indoor/outdoor, horizontal/vertical.	Indoor
Orientation	Horizontal
Product colour The colour e.g. red, blue, green, black, white.	Black
VESA mounting
Mounting type Type of mounting e.g. wall mounting.	Wall

Performance
Purpose What the product is used for.	Commercial
Operating hours (hours/days)	24/7
Automatic brightness control

Power
Power consumption (typical) Amount of power consumed by this model, often expressed in watts (W). Typical values that manufacturers give are power consumption when off, standby/suspended mode, typical use, maximum usage.	179 W
Power consumption (standby) The amount of electricity that is consumed when the product is on standby.	0.4 W
Energy efficiency class (SDR)	G
Energy efficiency class (HDR)	Not available
Energy consumption (SDR) per 1000 hours	195.6 kWh
AC input voltage The voltage of the AC electricity that is inputted into the product.	100 - 240 V
Energy efficiency scale	A to G

Computer system
Built-in processor Whether or not a processor is built into the device.
Processor manufacturer The manufacturer that produced the processor.	ARM
Processor family A family of processors is a group of processors produced by one company over a short period of time e.g. Intel Pentium processors.	ARM Cortex
Processor model The model number for the processor in a computer.	A73
Processor architecture	ARM Cortex-A53+Cortex-A73
Processor frequency The speed that the microprocessor executes each instruction or each vibration of the clock. The CPU requires a fixed number of clock ticks, or cycles, to execute each instruction. The faster the clocks rate, the faster the CPU, or the faster it can execute instructions. Clock Speeds are usually determined in MHz, 1 MHz representing 1 million cycles per second, or in GHz, 1 GHz representing 1 thousand million cycles per second. The higher the CPU speed, the better a computer will perform.	1.7 GHz
Processor cores The number of central processing units ('cores') in a processor. Some processors have 1 core, others have 2 (e.g. Intel Core Duo) or more (e.g. the Intel Xeon E7-2850 has 10 cores).	4
Internal memory A computer's memory which is directly accessible to the CPU.	3 GB
Internal storage capacity The amount e.g of data which can be stored inside the device.	32 GB
Operating system installed Type of operating system on a device e.g. IOS on Apple devices, Android for mobile devices.	Android 8.0

Weight & dimensions
Display width	1462.3 mm
Display depth	93.4 mm
Display height	837.3 mm
Display weight	27.8 kg

Packaging data
Package width The distance from one side of the packaging to the other.	1616 mm
Package depth The distance from the front to the back of the packaging.	187 mm
Package height The distance from the top to the bottom of the packaging.	998 mm
Package weight Weight of the packaged product.	36.8 kg

Packaging content
Remote control included Component of an electronics device, most commonly a television set, DVD player and home theater systems originally used for operating the device wirelessly from a short line-of-sight distance.
Cables included	AC
Warranty card

Operational conditions
Operating temperature (T-T) The minimum and maximum temperatures at which the product can be safely operated.	0 - 40 °C
Operating relative humidity (H-H)	20 - 80%
Storage temperature (T-T) The minimum and maximum temperatures at which the product can be safely stored.	-20 - 60 °C
Storage relative humidity (H-H)	10 - 90%

Network
Ethernet LAN An Ethernet LAN (Local Area Network) interface is present, for a wired conection via a cable.
Wi-Fi Popular technology that allows an electronic device to exchange data or connect to the internet wirelessly using radio waves.

Other features
Manual
Power supply type The type of power supply which this product uses.	Internal
