| Performance | |
| Suitable location Locations in which the product can be used. | Processor |
| Type Characteristics of the device. | Cooler |
| Fan diameter The size of the fan, measured by the distance from one side of the fan to the other, via a straight line going through the middle of the fan. | 9.2 cm |
| Supported processor sockets The sockets (plugs) for processors that are supported (can be used) by the device. | LGA 1150 (Socket H3), LGA 1151 (Socket H4), LGA 1155 (Socket H2), LGA 1200 (Socket H5), LGA 1366 (Socket B), LGA 2011 (Socket R), LGA 2011-v3 (Socket R), LGA 2066, Socket AM2, Socket AM2+, Socket AM3, Socket AM3+, Socket AM4, Socket FM1, Socket FM2, Socket FM2+ |
| Rotational speed (min) | 500 RPM |
| Rotational speed (max) | 2000 RPM |
| Noise level (high speed) How loud the device is when used at high speed. | 23.9 dB |
| Minimum airflow (imperial) | 33 cfm |
| Minimum air pressure | 2.31 mmH2O |
| Pulse-width modulation (PWM) support |
 |
| Bearing type | Hydraulic |
| Quantity per pack | 1 pc(s) |
| Design | |
| Product colour The colour e.g. red, blue, green, black, white. | Black |
| Radiator material | Copper |
| Number of fans The quantity of fans (apparatus with rotating blades that creates a current of air for cooling or ventilation). | 1 fan(s) |
| Number of fan blades | 7 |
| Number of heat pipes | 4 |
| Fan connector | 4-pin |
| Power | |
| Power consumption (typical) Amount of power consumed by this model, often expressed in watts (W). Typical values that manufacturers give are power consumption when off, standby/suspended mode, typical use, maximum usage. | 0.72 W |
| Rated voltage | 12 V |
| Rated current | 0.06 A |
| Weight & dimensions | |
| Width The measurement or extent of something from side to side. | 92 mm |
| Depth The distance from the front to the back of something. | 84 mm |
| Height The measurement of the product from head to foot or from base to top. | 137 mm |
| Weight Weight of the product without packaging (net weight). If possible, the net weight is given including standard accessories and supplies. Please note that sometimes the manufacturer leaves out the weight of accessories and/or supplies. | 595 g |
| Fan dimensions (W x D x H) | 92 x 92 x 25 mm |
| Fan thickness | 2.5 cm |
| Heat pipes diameter | 6 mm |
| Packaging content | |
| Package type The type of product package e.g. box. | Box |
| Cables included | 4-pin, SATA |
| Mounting kit |
|
| Screws included |
|
| Thermal pad included |
|
| SKU | 316603 |
| MPN | MCH4-GMX-C40P |
| Brand | DeepCool |
| Product Condition | Brand New/Unused |
| Cooling Technology | Air |
| Warranty Period | 1 Year Warranty |
| Warranty Contact | https://www.deepcool.com/ |
