Dahua Technology VTO3221E P, 5.84 cm (2.3"), OLED, H.264, Aluminium, IP65, IK08
Dahua Technology VTO3221E-P. Display diagonal: 5.84 cm (2.3"), Display technology: OLED, Video formats supported: H.264. Megapixel (approx.): 2 MP, Sensor type: CMOS, Optical sensor size: 25.4 / 2.9 mm (1 / 2.9"). Voice codecs: G.711. Product colour: Aluminium, International Protection (IP) code: IP65, IK code: IK08. Ethernet interface type: Fast Ethernet, Ethernet LAN data rates: 10,100 Mbit/s, Cabling technology: 10/100Base-T(X)
| Technical details | |
| Connectivity technology The technology that enables connectivity of the device, e.g. wired or wireless. | Wired |
| Colour The main colour of the product. |
 |
| Speakerphone Device has a microphone and loudspeaker provided separately from those in the handset. This device allows multiple persons to participate in a conversation. The loudspeaker broadcasts the voice or voices of those on the other end of the telephone line, while the microphone captures all voices of those using the speakerphone. |
 |
| Maximum number of cameras supported The total number of cameras that can be used with the product. | 1 |
| Built-in speaker(s) The device contains speaker(s) to produce sound. |
|
| Door station control |
|
| Voice codecs | G.711 |
| VoIP protocols | TCP/IP |
| Wall mountable The product can be mounted on (attached to ) a wall. |
|
| Built-in microphone Microphone that is found inside the product. |
|
| Automatic gain control |
|
| Motion detection function |
|
| Noise-canceling |
|
| RFID reader |
|
| Display | |
| Display diagonal Size of the display for this product, measured diagonally, usually in inches. | 5.84 cm (2.3") |
| Display technology The technology used in the display e.g. plasma, LED. | OLED |
| Touchscreen A screen of a laptop, smartphone, etc., that responds to touch so you can control the interface using your fingers. |
|
| Video formats supported The type of video formats that can be used by this device. | H.264 |
| Design | |
| Product colour The colour e.g. red, blue, green, black, white. | Aluminium |
| International Protection (IP) code The IP code classifies and rates the degree of protection provided against the intrusion (including body parts such as hands and fingers), dust, accidental contact, and water by mechanical casings and electrical enclosures. It is published by the International Electrotechnical Commission (IEC). The digits (characteristic numerals) indicate conformity with the conditions summarized in the tables below. Where there is no protection rating with regard to one of the criteria, the digit is replaced with the letter X. an electrical socket rated IP22 is protected against insertion of fingers and will not be damaged or become unsafe during a specified test in which it is exposed to vertically or nearly vertically dripping water. Another example is the Sony Xperia Z Ultra, one of the first cellular phones to be IP-rated; it is rated at IP58 and marketed as "dust resistant" and can be "immersed in 1.5 meter of freshwater for up to 30 minutes". | IP65 |
| IK code | IK08 |
| Housing material What the casing of the product is made of. | Aluminium |
| Control type The way in which the device is controlled. | Buttons |
| Placement supported Where the product can be placed e.g. indoor/outdoor, horizontal/vertical. | Vertical |
| Proper use The intended application of the product. | Outdoor |
| Network | |
| Ethernet interface type | Fast Ethernet |
| Ethernet LAN data rates The different speed levels of the Ethernet LAN connection. | 10,100 Mbit/s |
| Ethernet LAN (RJ-45) ports Number of Ethernet LAN (RJ-45) ports (connecting interfaces) in the device. Ethernet LAN (RJ-45) ports allow a computer to connect to the ethernet. | 1 |
| Cabling technology Type of cable technology performance. | 10/100Base-T(X) |
| Power over Ethernet (PoE) The device supports Power over Ethernet (PoE), which is one of several standardized or ad-hoc systems which pass electrical power along with data on Ethernet cabling. This allows a single cable to provide both data connection and electrical power to devices such as wireless access points or IP cameras. |
|
| Supported network protocols Network protocols tested as compatible with this product e.g. FTP,HTML, POP. | TCP/IP |
| Networking standards The way in which the network is working, e.g. IEEE 802.11a, IEEE 802.11b, IEEE 802.11g. | IEEE 802.3af |
| Camera | |
| Megapixel (approx.) The number (in millions) of light-sensitive picture elements known as pixels actually used by the camera's image sensor (CCD) to record light, and which are reflected to the final number of recorded pixels stored on the memory card. | 2 MP |
| Sensor type A sensor is a convertor than measures a physical quality (light, temperature etc.) and displays this electronically on a device. | CMOS |
| Optical sensor size Optical sensors are electronic detectors that convert light, or a change in light, into an electronic signal. They are used in many industrial and consumer applications e.g. lamps that turn on automatically in response to darkness. Optical sensors come in many sizes. | 25.4 / 2.9 mm (1 / 2.9") |
| Viewing angle, horizontal Maximum horizontal angle at which a display can be viewed with acceptable visual performance. | 140° |
| Viewing angle, vertical Maximum vertical angle at which a display can be viewed with acceptable visual performance. | 82° |
| Night vision | |
| Night vision Night vision is technology which allows you to see in low light conditions. |
|
| Power | |
| Outdoor unit power type | DC |
| AC adapter output voltage | 12 V |
| AC adapter output current | 2 A |
| Power consumption (typical) Amount of power consumed by this model, often expressed in watts (W). Typical values that manufacturers give are power consumption when off, standby/suspended mode, typical use, maximum usage. | 7 W |
| Power consumption (standby) The amount of electricity that is consumed when the product is on standby. | 2 W |
| Operational conditions | |
| Operating temperature (T-T) The minimum and maximum temperatures at which the product can be safely operated. | -40 - 60 °C |
| Operating relative humidity (H-H) | 20 - 95% |
| Weight & dimensions | |
| Width The measurement or extent of something from side to side. | 98 mm |
| Depth The distance from the front to the back of something. | 32 mm |
| Height The measurement of the product from head to foot or from base to top. | 200 mm |
| Weight Weight of the product without packaging (net weight). If possible, the net weight is given including standard accessories and supplies. Please note that sometimes the manufacturer leaves out the weight of accessories and/or supplies. | 1.5 kg |
| Software | |
| Operating system installed Type of operating system on a device e.g. IOS on Apple devices, Android for mobile devices. | Linux |
| Packaging data | |
| Outdoor unit included |
|
| Logistics data | |
| Quantity per pack | 1 pc(s) |
| Minimum order quantity | 1 pc(s) |
| SKU | 722879 |
| MPN | DHI-VTO3221E-P |
| Brand | Dahua |
| Product Condition | Brand New/Unused |
| Stock Availability | Available for Shipping |
| Product Use | General |
| Warranty Period | 3 Years Warranty |
| Warranty Contact | https://www.dahuasecurity.com/ |
