Smart Full HD Wi-Fi Camera with built-in Smart Home Hub (DCS-8330LH)
AI-based IVA Motion Detection: Intelligent Video Analytics (IVA) for smarter motion detection
Built-in Smart Home Hub: Connects to mydlink Smart DIY devices
Premium Full HD Clarity with 151° View: True Full HD 1080p resolution @ 30 fps with night vision
Multiple Recording Options: Record events with microSD2, mydlink Cloud1, or continuous recording to your NAS via ONVIF Profile S support
Smart Door/ Window Sensor (DCH-B112)
Open/close detection for your doors and windows
Sensor Bypass Button allows you to open doors and windows without triggering an alert
Tamper detection for greater peace of mind
Smart Motion Sensor (DCH-B122)
Get motion detection alerts on your phone
Tamper detection for greater peace of mind
Features
Product colour
The colour e.g. red, blue, green, black, white.
White
Built-in speaker(s)
The device contains speaker(s) to produce sound.
Built-in microphone
Microphone that is found inside the product.
Alert notification type
Phone line
Number of telephone numbers supported (max)
2
Certification
FCC, IC, CE, RCM, Zigbee 3.0, Amazon Echo Plus
Central control unit
Central control unit interface
The interface type of the main unit of the system, e.g. IR wireless.
RF Wireless
Central control unit connectivity technology
The technology used by the control unit to connect with the system.
ZigBee/Bluetooth/Wi-Fi
Wi-Fi (central control unit)
Wi-Fi standards
The type of wireless local area network (LAN). It can be ad-hoc, where units in a network communicate peer-to-peer, or Infrastructure, where units communicate with each other via an access point A LAN interconnects computers in a small area e.g. home, school or office.
802.11g, Wi-Fi 4 (802.11n)
Wi-Fi frequency
2.4 GHz
USB port
The device features a socket into which a USB cable can be plugged.
USB connector type
The type of USB connector/port that this product has.
Micro-USB A
Ethernet LAN
An Ethernet LAN (Local Area Network) interface is present, for a wired conection via a cable.
Supported network protocols
Network protocols tested as compatible with this product e.g. FTP,HTML, POP.
Security camera
Whether or not the set includes a camera, a device for taking still or moving pictures or photographs.
Camera interface
The place where the camera connects to other devices e.g. USB port.
Wireless
Camera connectivity technology
Wi-Fi
Maximum resolution
The maximum number of pixels that can be displayed in the image. It is usually quoted as width × height,: for example, "1024 × 768" means the width is 1024 pixels and the height is 768 pixels.
1920 x 1080 pixels
Sensor type
A sensor is a convertor than measures a physical quality (light, temperature etc.) and displays this electronically on a device.
CMOS
Optical sensor size
Optical sensors are electronic detectors that convert light, or a change in light, into an electronic signal. They are used in many industrial and consumer applications e.g. lamps that turn on automatically in response to darkness. Optical sensors come in many sizes.
25.4 / 2.7 mm (1 / 2.7")
Progressive scan
Also referred to as noninterlaced scanning, this is a way of displaying, storing, or transmitting moving images in which all the lines of each frame are drawn in sequence. This is in contrast to interlaced video used in traditional analog television systems where only the odd lines, then the even lines of each frame (each image called a video field) are drawn alternately.Progressive scan is used for DVDs and HDTV (high defintion television).
Supported video modes
The video modes that can be displayed by the device.
1080p
Frame rate
30 fps
Camera motion detection
Night vision
Night vision is technology which allows you to see in low light conditions.
Night vision distance
5 m
LED type
IR
Audio formats supported
The audio formats which this device or software can read/use e.g. MP3, MP4.
LC-AAC
Viewing angle, horizontal
Maximum horizontal angle at which a display can be viewed with acceptable visual performance.
126°
Viewing angle, vertical
Maximum vertical angle at which a display can be viewed with acceptable visual performance.
63°
Viewing angle, diagonal
151°
Power consumption (typical)
Amount of power consumed by this model, often expressed in watts (W). Typical values that manufacturers give are power consumption when off, standby/suspended mode, typical use, maximum usage.
7 W
Camera security algorithms
WPA, WPA2
Camera operating temperature (T-T)
0 - 40 °C
Camera operating relative humidity (H-H)
20 - 80%
Camera storage temperature (T-T)
-20 - 70 °C
Camera storage relative humidity (H-H)
5 - 95%
Camera dimensions (WxDxH)
74.4 x 108.8 x 83.9 mm
Camera weight
140 g
Camera certification
CE, LVD, RCM, FCC Class B, IC, NCC/BSMI
Sensors
Door/window sensor
Whether the unit has a feature monitoring doors and windows to give instant alerts when entries are breached.
Door/window sensor connectivity technology
Wi-Fi
Door/window sensor battery voltage
3 V
Door/window sensor status LED indicator
Motion sensor
Device that detects moving objects, particularly people. A motion detector is often integrated as a component of a system that automatically performs a task or alerts a user of motion in an area. Motion detectors form a vital component of security, automated lighting control, home control, energy efficiency, and other useful systems.
