| Ports & interfaces | |
| Basic switching RJ-45 Ethernet ports quantity The number of basic switching RJ-45 Ethernet ports (sockets). | 24 |
| Network | |
| Networking standards The way in which the network is working, e.g. IEEE 802.11a, IEEE 802.11b, IEEE 802.11g. | IEEE 802.1d,IEEE 802.1p,IEEE 802.1q,IEEE 802.1w,IEEE 802.1x,IEEE 802.3,IEEE 802.3ab,IEEE 802.3ad,IEEE 802.3af,IEEE 802.3u,IEEE 802.3x,IEEE 802.3z |
| Copper ethernet cabling technology | 1000BASE-T,100BASE-TX,10BASE-T |
| Data transmission | |
| Switching capacity The data transfer capacity of the switch per second. | 12.8 Gbit/s |
| MAC address table The MAC address is the 'Media Access Control Address'. It is a unique address given to a network interface controller (NIC) in a device. A MAC address table shows the addresses in a table format. | 16000 entries |
| Maximum data transfer rate | 1 Gbit/s |
| Packet buffer memory | 32 MB |
| Protocols | |
| Data link protocols | Ethernet, Fast Ethernet, Gigabit Ethernet |
| Supported network protocols Network protocols tested as compatible with this product e.g. FTP,HTML, POP. | RFC 1157 SNMP, RFC 1112/2236 IGMPv1/2 IGMPv3, RFC 1757/2021/2819 RMON (4 Groups), RFC 1493 Bridge MIB, RFC 1213 MIB II, RFC 793 TCP, RFC 826 ARP, RFC 854 Telnet, and DiffServ, RFC 1724 RIP v1/2, RFC 1850 OSPF*, DVMRP, RFC 2934 PIM-DM, PIM-SM*, RFC 2932 Multicast Routing, RFC 2787 VRRP, RFC 2096 IP Forwarding Table, RFC 2618/2620 RADIUS Client, RFC 2863 IF MIB, RFC 2674 802.1p MIB, RFC 2668 802.3 MAU MIB, RFC 2665 ether-like MIB, SSH, SSL, TACACS+ |
| Design | |
| Safety List of regulatory safety standards for all countries in which this product has been certified. | CSA International, CB Report |
| Power | |
| Power consumption (typical) Amount of power consumed by this model, often expressed in watts (W). Typical values that manufacturers give are power consumption when off, standby/suspended mode, typical use, maximum usage. | 395.2 W |
| Operational conditions | |
| Operating temperature (T-T) The minimum and maximum temperatures at which the product can be safely operated. | 0 - 40 °C |
| Storage temperature (T-T) The minimum and maximum temperatures at which the product can be safely stored. | -40 - 70 °C |
| Operating relative humidity (H-H) | 10 - 85% |
| Storage relative humidity (H-H) | 5 - 95% |
| Weight & dimensions | |
| Weight Weight of the product without packaging (net weight). If possible, the net weight is given including standard accessories and supplies. Please note that sometimes the manufacturer leaves out the weight of accessories and/or supplies. | 6.02 kg |
| Other features | |
| Management platform | Web/CLI/SNMP |
| Data transfer rate Rate at which data can be transferred, usually measured in units per second. May vary with network configurations. | 1000 Mbit/s |
| Dimensions (WxDxH) Dimensions of the product (Width x Depth x Height). | 309 x 440.9 x 43.9 mm |
| I/O ports An interface on a device to which you can connect another device. | (24) 10/100 Mbps Ports, (2) Combo SFP/1000BASE-T Ports, & (2) Built-in 1000BASE-T Uplinks & 802.3af PoE |
| Packet transfer speed Rate at which data can be transferred by packet. | 14880pps (10M), 148800pps (100M), 1488000pps (1000M) |
| Power requirements | 100 - 240 VAC, 50/60 Hz |
| Electromagnetic emissions | CE Class A, FCC Class A, VCCI Class A, C-Tick Class A |
| SKU | 282947 |
| MPN | DES-3828P |
| Brand | D-Link |
| Product Condition | Brand New/Unused |
| Stock Availability | Available for Shipping, In Stock at Warehouse |
